Logic SCSI to PCI Host Adapter User's Guide
Table Of Contents
- Ultra160 SCSI to PCI Host Adapters
- Preface
- Contents
- Chapter1 Quick Installation Procedures
- Chapter2 Detailed Host Adapter Installation
- Chapter3 Ultra160 SCSI to PCI Host Adapter Characteristics
- 3.1 Ultra160 SCSI to PCI Boards
- 3.2 Host Adapter Characteristics
- 3.3 Cabling SCSI Devices
- 3.4 Technical Specifications
- AppendixA Glossary of Terms and Abbreviations
- Index
- Customer Feedback
Ultra160 SCSI to PCI Host Adapters 1-1
Chapter 1
Quick Installation
Procedures
This chapter contains general information about Ultra160 SCSI
controllers and host adapters. It provides quick host adapter installation
instructions for experienced computer users and instructions for SCSI
bus setup. It also provides quick installation instructions for Windows NT
or Windows 2000 device drivers. This chapter describes these topics:
• Section 1.1, “General Description,” page 1-1
• Section 1.2, “Obtaining Windows NT/Windows 2000 Drivers,”
page 1-2
• Section 1.3, “Quick Host Adapter Installation,” page 1-3
• Section 1.4, “Quick Windows NT/Windows 2000 Driver Installation,”
page 1-4
1.1 General Description
LSI Logic provides high-performance, cost-effective Ultra160 SCSI
controllers and host adapters. The LSI Logic controllers and their
associated host adapters that support Ultra160 SCSI are:
Installing any of these adapters into your PCI system allows you to
connect SCSI devices over a SCSI bus. You can use the Ultra160 SCSI
boards in PCI computer systems with either a standard or Low Profile
PCI (LPPCI) bracket type.
Controllers Host Adapters
LSI53C1000 LSI20160, LSI20160L
LS53C1010 LSI21040, LSI21003, LSI22903, LSI22915A, 6200U3LP
