Configuration 4: R8csi <—ISDN—> R8si Gateway
<—ppp—> R8csi
3 C-LAN Administration
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
132
Switch 1 Task — Assign Signaling Group and administered NCA TSC
This task assigns a signaling group and an administered NCA TSC for the ISDN
connection to Switch 2.
Begin
Steps>
> Open the Signaling Groups form — enter ch sig n
> Enter values
> Press the Next Page key
change signaling-group next
    Page 1 of 5
 SIGNALING GROUP
Group Number: 1
Associated Signaling? y
 Max number of NCA TSC: 5_
 Primary D-Channel: 01b0924 Max number of CA TSC: 23
   Trunk Group for NCA TSC: 12
 Trunk Group for Channel Selection: 12__
 Supplementary Service Protocol: a__
Field Conditions/Comments
Associated Signaling? Specifies Facility-Associated Signaling (FAS) — the
D-channel carries signaling only for the B-channels on
the same DS1 interface.
Primary D-Channel Specifies D-Channel signaling on port 24 of the DS1
circuit pack located at 01b09.
Max number of NCA
TSC
Maximum number of simultaneous non-call-associated
Temporary Signaling Connections. The TSCs carry
signaling for features not associated with a specific
call; for example, signals to turn on Leave Word
Calling.
Max number of CA
TSC
Maximum number of simultaneous call-associated
TSCs that can exist in the signaling group. Typically,
this is the number of ISDN-PRI trunk group members
controlled by this signaling group.
Trunk Group for NCA
TSC
The ISDN-PRI trunk group number whose incoming
call-handling table will be used to handle incoming
NCA-TSCs through this signaling group.
Trunk Group for
Channel Selection
Supplementary
Service Protocol
a indicates AT&T protocol; b indicates QSIG protocol.
