4 Networking Example
ethernet data module
IP Interface
Processor Channel Assignments
.
add data 1191
  Page 1 of X
 DATA MODULE
 Data Extension: 1191
  Name: ethernet on link 1_____________   BCC: 2
 Type: ethernet
 Port: 01c1517_
 Link: 1_
 Network uses 1’s for Broadcast Addresses? y
change ip-interfaces  Page 1 of 2
IP Interfaces
 Network regions are interconnected?  n
 En-  Net
 abled Type Slot Code Sfx Node Name Subnet Mask  Gateway Addr  Rgn
 y
 C-LAN 01c15 TN799 B ethernet1 255.255.255.0  192.168.200.1_ 1
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
 _ _____ _____ _____ _ _________ 255.255.255.0 ___.___.___.___ _
change communications-interface processor-channels
  Page 1 of X
PROCESSOR CHANNEL ASSIGNMENT
Proc Gtwy Interface Destination Session Mach
Chan Enable Appl. To Mode Link/Chan Node Port Local/Remote ID
 1: y
 audix__  s 1 5002 intuity  0____ _1_ 1__ 1_
 2: y
 gtwy-tcp 4_ _ 2 2___ _________  _____ _2_ 59_ __
3: y
 gateway_  s 1 5031 intuity _ 0____ _3_ 3__ __
4: y gtwy-tcp 2_ s 1 5021 intuity  0____ _2_ 2__ __
:
:
10: y
 mis___ _  s 1 5001 cms______ 0____ _1_ 1__ __
11: y
 dcs___ _    2 11__ _________  _____ _11 11_ 2_
12: y
 gateway_  _  2  12__ _________  _____ _12 12_ __
13: y gtwy-tcp 15  _  2 13__ _________  _____ _13 13_ __
14: y
 dcs___ _  s  4 5003 ppp41____  0____ _14 14_ 4_
15: y
 gtwy-tcp 13  s  4 5004 ppp41____  0____ _15 15_ __
16: y gateway_  s  4  5005 ppp41_ __  0____ _16 16_ __
 :
 64: _  _______   _ ___ ____ _________  0
____ ___ ___ __
