Switch-Node 2 Administration
225
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
4 Networking Example
AAR Digit Analysis
Routing Patterns
Data Modules
procr-intf data module
change aar analysis 1  Page 1 of 2
 AAR DIGIT ANALYSIS TABLE
  Percent Full: 6
 Dialed Total Route Call Node ANI
 String Min Max Pattern Type Num Reqd
 221  7 7 101  aar 1  n
 223  7 7 101  aar 3 n
 224  7 7 101  aar 4  n
display route-pattern 101
 Pattern Number: 101
 Grp. FRL NPA Pfx Hop Toll No. Del Inserted  IXC
 No. Mrk Lmt List Digits  Digits
 1:12 0 3  user
 2:   user
 3:   user
 4:   user
 5:   user
 6:   user
add data-module 2992  Page 1 of 1
 DATA MODULE
 Data Extension: 2992_
  Name: x.25 on link 2 to node 1__
   Type: procr-intf   COS: 1   Maintenance Extension: 2002
Physical Channel: 02_  COR: 1   Destination Number: 7221993
   ITC: Restricted  TN: 1  Establish Connection? y
   Link: 2_ DTE/DCE: dce  Connected Data Module:
__________
   Enable Link: n
ABBREVIATED DIALING
 List1: _______________
SPECIAL DIALING OPTION: ________________
ASSIGNED MEMBER (Station with a data extension button for this data module)
 Ext Name
 1.
