Switch-Node 3 Administration
231
Administration for Network Connectivity
555-233-504 — Issue 1 — April 2000 CID: 77730
4 Networking Example
Group 13 — member
assignments
Uniform Dialing Paln
AAR Digit Analysis
display trunk-group 13 Page 4 of 10
TRUNK GROUP
Administered Members (min/max): 0/0
GROUP MEMBER ASSIGNMENTS Total Administered Members: 0
Port Code Sfx Name Night Sig Grp
1: 01a1101 TN464 e 1
2: 01a1102 TN464 e 1
3: 01a1103 TN464 e 1
4: 01a1104 TN464 e 1
5:
6:
change udp x
Page 1 of 2
UNIFORM DIALING PLAN
Ext Codes: ddxx
dd Type dd Type dd Type dd Type dd Type
0x: _______ ___ 1x: udpcode 221 2x: udpcode 222 3x: local__ ___ 4x: udpcode 224
00: _______ ___ 10: _______ ___ 20: _______ ___ 30: _______ ___ 40: _______ ___
01: _______ ___ 11: _______ ___ 21: _______ ___ 31: _______ ___ 41: _______ ___
02: _______ ___ 12: _______ ___ 22: _______ ___ 32: _______ ___ 42: _______ ___
03: _______ ___ 13: _______ ___ 23: _______ ___ 33: _______ ___ 43: _______ ___
04: _______ ___ 14: _______ ___ 24: _______ ___ 34: _______ ___ 44: _______ ___
05: _______ ___ 15: _______ ___ 25: _______ ___ 35: _______ ___ 45: _______ ___
06: _______ ___ 16: _______ ___ 26: _______ ___ 36: _______ ___ 46: _______ ___
07: _______ ___ 17: _______ ___ 27: _______ ___ 37: _______ ___ 47: _______ ___
08: _______ ___ 18: _______ ___ 28: _______ ___ 38: _______ ___ 48: _______ ___
09: _______ ___ 19: _______ ___ 29: _______ ___ 39: _______ ___ 49: _______ ___
display aar analysis 1 Page 1 of 2
AAR DIGIT ANALYSIS TABLE
Percent Full: 6
Dialed Total Route Call Node ANI
String Min Max Pattern Type Num Reqd
221 7 7 101 aar 1 n
222 7 7 101 aar 2 n
224 7 7 101 aar 4 n
