Networking Screens  A Screens Reference
Administration for Network Connectivity
CID: 77730 555-233-504 — Issue 1 — April 2000
280
Signaling Group
The Signaling Group screen defines the signaling parameters for ISDN-PRI, H.323, and ATM signaling groups.
Type ISDN-PRI The ISDN-PRI Signaling Group screen identifies groups of DS1 interface B-channels
for which a given D-channel or D-channel pair carries associated signaling
information. The Non-Facility Associated Signaling (NFAS) feature allows a
D-channel to convey signaling information for B-channels that are located on DS1
facilities other than the one containing the D-channel. With NFAS, a signaling group
does not necessarily correspond to a single DS1 interface. The Signaling Group
screen is administered to show how B-channels and D-channels are related.
The Signaling Group screen also supports Facility Associated Signaling (FAS). The
screen establishes the fact that a D-channel carries signaling information for all
B-channels on its associated DS1 interface, and for no others.
In addition, the screen administers Temporary Signaling Connections (TSC) used in
support of DCS Over ISDN-PRI D-channel (includes ISDN-PRI D-channel DCS
AUDIX).
Screen for ISDN-PRI Non-Facility Associated Signaling
Screen for ISDN-PRI Facility Associated Signaling
  Page 1 of 5
  SIGNALING GROUP
Group Number: 2 Group Type: isdn-pri
 Associated Signaling? n Max number of NCA TSC: 0
 Primary D-Channel:  Max number of CA TSC: 0
 Secondary D-Channel:  Trunk Group for NCA TSC:
 Trunk Group for Channel Selection:  X-Mobility/Wireless Type: NONE
 Supplementary Service Protocol: a
 Trunk Brd Interface ID  Trunk Brd Interface ID
 1:  11:
 2:  12:
 3:  13:
 4:  14:
 5:  15:
 6:  16:
 7:  17:
 8:  18:
 9:  19:
 10:  20:
  Page 1 of 5
  SIGNALING GROUP
Group Number: 2 Group Type: isdn-pri
 Associated Signaling? y Max number of NCA TSC: 0
 Primary D-Channel:  Max number of CA TSC: 0
  Trunk Group for NCA TSC:
 Trunk Group for Channel Selection:  X-Mobility/Wireless Type: NONE
 Supplementary Service Protocol: a
