User's Manual

DEFINITYEnterpriseCommunicationsServerandSystem75andSystem85
Terminals and Adjuncts Reference
555-015-201
Issue 11
December 1999
The 6400 Series Telephones
7-27The 6416D+ and 6416D+M Telephones
7
Applications for the Modular 6416D+M
Telephone Only
If the Modular 6416D+M telephone is being used with a DEFINITY switch, the
manner in which the telephone and the analog adjunct interact depends on the
switch release to which your telephone is connected. (Your system manager can
give you more information about the switch release.)
■ On DEFINITY releases prior to Release 8.1, going back to Release 6.1, the
analog adjunct shares the telephone line with the telephone. Therefore,
while the telephone is being used, you
cannot use the analog adjunct at the
same time, or vice versa.
■ On the DEFINITY Release 8.1 and later, the telephone and the analog
adjunct can be assigned separate telephone lines, and thus the telephone
and analog adjunct can be used
simultaneously .
Physical Features
Dimensions
NOTE:
The dimensions described here for the 6416D+ and 6416D+M telephones
are approximate.
Width = 10.35 inches (26.35 cm)
Depth (front to back) = 8.5 inches (21.59 cm)
Height (with deskstand and handset in place) = 4.75 inches (12.07 cm)
Features
Six Fixed Feature Buttons
The 6416D+ and 6416D+M telephones have the following six fixed feature
buttons:
■ SPEAKER button
■ MUTE button
■ HOLD button
■ REDIAL button
■ TRANSFER/TEST button
■ CONFERENCE (labeled CONF)/RING button
