User's Manual
Table Of Contents
- ==============
- MAIN MENU
- ==============
- DEFINITY® ECS and System 75 and System 85 Terminals and Adjuncts Reference
- Contents
- 1 Introduction
- 2 General Information
- 3 Exposed Port Protection
- 4 Adjunct Power
- 5 Administration
- 6 Voice Terminal Features
- 7 The 6400 Series Telephones
- The 6402 and 6402D Telephones
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Appropriate Circuit Packs and Distance Limitations
- Power Requirements
- Administration
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 6402 and 6402D Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 6408+ and 6408D+ Telephones
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Appropriate Circuit Packs and Distance Limitations
- Power Requirements
- Administration
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 6408 Telephones and Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 6416D+ and 6416D+M Telephones
- All 6416D+ and 6416D+M Telephones
- Only the Modular 6416D+M Telephone
- Applications
- All 6416D+ and 6424D+M Telephones
- Applications for the Modular 6416D+M Telephone Only
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Appropriate Circuit Packs and Distance Limitations
- Power Requirements
- Administration
- Button Numbering
- Administering the Analog Adjunct on the Modular 6416D+M Telephone
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 6416D+ and 6416D+M Telephones and Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 6424D+ and 6424D+M Telephone
- All 6424D+ and 6424D+M Telephones
- Only the Modular 6424D+M
- Applications
- All 6424D+ and 6424D+M Telephones
- Applications for the Modular 6424D+M Telephones Only
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Appropriate Circuit Packs and Distance Limitations
- Power Requirements
- Administration
- Button Numbering
- Administering the Analog Adjunct on the Modular 6424D+M Telephone
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 6424D+ and 6424D+M Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 6402 and 6402D Telephones
- 8 The 7100 Series Voice Terminals
- 9 The 7200 Series Voice Terminals
- 10 The 7300 Series Voice Terminals
- 11 The 7400 Series Voice Terminals
- The 7401D and 7401 Plus Voice Terminals
- Applications
- Special Operational Characteristics
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 7401D Equipment PECs and Comcodes
- 7401 Plus Equipment with PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7402 Plus Voice Terminal
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 7402 Plus Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7403D Voice Terminal
- The 7404D Voice Terminal
- The 7405D Voice Terminal
- The 7406D, 7406BIS, and 7406 Plus Voice Terminals
- Applications
- Physical Description
- Dimensions
- Feature Buttons
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatibility
- 7406D/7406BIS Equipment PECs and Comcodes
- 7406 Plus Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7407D, Enhanced 7407D, and 7407 Plus Voice Terminals
- Applications
- Special Operational Characteristics
- Switch Options for the 7407D and Enhanced 7407D
- DIP Switch Options for the 7407 Plus
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 7407D/Enhanced 7407D Equipment PECs and Comcodes
- 7407 Plus Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7410D and 7410 Plus Voice Terminals
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 7410D Equipment with PECs and Comcodes
- 7410 Plus Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7434D Voice Terminal
- The 7444 Voice Terminal
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 7444 Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 7401D and 7401 Plus Voice Terminals
- 12 The 8400 Series Voice Terminals
- The 8403 Voice Terminal
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Color Options
- Wiring Information
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 8403 Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 8405B, 8405B Plus, 8405D, and 8405D Plus Voice Terminals
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 8405 Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 8410 Voice Terminal
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 8410 Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 8411 Voice Terminal
- Applications
- Physical Features
- Dimensions
- Features
- Other Physical Features
- PassageWay and Analog Adjunct Connections
- Wiring Information
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Administering the Analog Adjunct
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 8411 Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 8434 and 8434DX Voice Terminals
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Wiring Information
- Distance Limitations
- Power Requirements
- Switch Administration
- Aliasing
- Button Numbering
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 8434 and 8434DX Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The 8403 Voice Terminal
- 13 CALLMASTER Voice Terminals
- The CALLMASTER, CALLMASTER II, CALLMASTER III, CALLMASTER IV, CALLMASTER V, and CALLMASTER VI Voi...
- Applications
- Special Operational Characteristics
- The Recorder Interface
- Physical Description
- Dimensions
- Features
- LOG IN and RELEASE buttons
- Self-Test
- Display
- Other Physical Features
- Wiring Information on the CALLMASTER IV
- Wiring Note for the CALLMASTER VI
- Distance Limitations
- Distance Limitations for the CALLMASTER V and CALLMASTER VI
- Power Requirements
- Switch Administration
- Button Numbering
- Power Failure Operation
- FCC Registration
- CALLMASTER Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The CALLMASTER, CALLMASTER II, CALLMASTER III, CALLMASTER IV, CALLMASTER V, and CALLMASTER VI Voi...
- 14 The 500 and 2500 Series Telephones
- The 500 Series Telephone
- The 2500 Series Telephones
- The 2500 DMGC Telephone
- The 2500 YMGK Telephone
- The 2500 MMGL and 2500 YMGL, 2500 MMGM and 2500 YMGM, and 2554 MMGM and 2554 YMGM Telephones
- Applications
- Physical Description
- Dimensions
- Features on the 2500 YMGL, 2500 YMGM, and 2554 YMGM Telephones
- Other Physical Features (on All of these 2500 and 2554 Telephones)
- Distance Limitations
- Power Requirements
- Switch Administration
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 2500 MMGL and 2500 YMGL Equipment PECs
- Additional Documents
- The 2500 MMGN and 2500 YMGP and 2554 MMGN and 2554 YMGP Telephones
- Applications
- Physical Description
- Dimensions
- Features on the 2500 YMGP and 2554 YMGP Telephones
- Other Physical Features (on All of these 2500 and 2554 Telephones)
- Distance Limitations
- Power Requirements
- Switch Administration
- Power Failure Operation
- FCC Registration
- UL and CSA Approval
- Hearing Aid Compatible
- 2500 MMGN and 2500 YMGP Equipment PECs
- Additional Documents
- 15 The 6200 Series Telephones
- 16 The 8100 Series Telephones
- The 8101 and 8101M Telephones
- The 8102 and 8102M Telephones
- Applications
- Physical Description
- Dimensions
- Feature Buttons
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Administration of Hidden Features
- Power Failure Operation
- Ringer Equivalency Numbers
- FCC Registration
- Hearing Aid Compatible
- 8102 and 8102M Telephones PECs and Comcodes
- Adjuncts
- Additional Documents
- The 8110 and 8110M Telephones
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Switch Administration
- Administration of Hidden Features
- Power Failure Operation
- Ringer Equivalency Numbers
- FCC Registration
- Hearing Aid Compatible
- 8110 and 8110M Telephones Equipment PECs and Comcodes
- Adjuncts
- Additional Documents
- 17 ISDN Voice Terminals
- The ISDN 7505 Modular Terminal
- The ISDN 7506 Voice Terminal
- The ISDN 7507 Display Terminal
- The ISDN 8503 Voice Terminal
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Distance Limitations
- Power Requirements
- Phantom or Auxiliary Power
- Terminating Resistors
- Switch Administration
- Power Failure Operation
- FCC Registration
- Hearing Aid Compatible
- 8503T Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The ISDN 8510 Voice/Data Terminal
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Data Features
- Distance Limitations
- Power Requirements
- Phantom or Auxiliary Power
- Terminating Resistors
- Switch Administration
- Button Numbering
- The Service Profiler ID (SPID)
- Hidden/Craft Features
- Power Failure Operation
- FCC Registration
- Hearing Aid Compatible
- 8510T Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- The ISDN 8520T Voice/Data Terminal
- Applications
- Physical Description
- Dimensions
- Features
- Other Physical Features
- Data Features
- Distance Limitations
- Power Requirements
- Auxiliary Power Supply
- Terminating Resistor
- Switch Administration
- Button Numbering
- The Service Profiler ID (SPID)
- Hidden/Craft Features
- Power Failure Operation
- FCC Registration
- Hearing Aid Compatible
- 8520T Equipment PECs and Comcodes
- Adjuncts
- Headsets
- Additional Documents
- 18 Cordless and Wireless Telephones
- The MDC 9000 Cordless Telephone
- Applications
- Physical Features
- Dimensions
- Handset Features
- Charging Base Features
- Display Information
- Out-of-Range Indication
- Distance and Installation Limitations (for the Charging Base)
- Switch Administration
- Aliasing
- Button Numbering
- FCC Registration
- Hearing Aid Compatibility
- MDC 9000 Equipment PECs and Comcodes
- Additional Documents
- The MDW 9000 Wireless Telephone
- Applications
- Physical Features
- Dimensions
- Handset Features
- Charging Cradle Features
- Radio Module Features
- Display Information
- Out-of-Range Indication
- Distance and Installation Limitations
- Switch Administration
- Aliasing
- Button Numbering
- FCC Registration
- Hearing Aid Compatibility
- UL and CSA Approval
- MDW 9000 Equipment PECs and Comcodes
- Additional Documents
- The MDW 9031DCP Wireless Pocket Phone
- Applications
- Physical Features
- Dimensions
- Handset Features
- Battery Charger Features
- Radio Module Features
- Out-of-Range Indication
- Distance and Installation Limitations
- Switch Administration
- Aliasing
- Button Numbering
- FCC Registration
- Hearing Aid Compatibility
- UL and CSA Approval
- MDW 9031DCP Equipment PECs and Comcodes
- Additional Documents
- The MDC 9000 Cordless Telephone
- 19 Other Voice Terminals
- 20 Adjuncts
- Call Coverage Modules
- Digital Display Modules
- Function Key Modules
- The 801A Expansion Module
- The XM24 Expansion Module
- The 100A Tip/Ring Module
- Headset Adapters
- The Z34A Message Waiting Indicator
- The 4A, S101A, and S102A Speakerphones
- The S201A and S202A Speakerphones
- The S203A Speakerphone
- The 107-Type Loudspeaker
- The 7404D (Voice Terminal) Messaging Cartridge
- The 2870A1 Automatic Dialer
- 21 Data Modules
- The 7400A Data Module
- The 7400B and 7400B Plus Data Module
- The 7400D Low-Speed Asynchronous Data Module
- The 8400B Plus Data Module
- The 7500B Data Module
- The ISDN Asynchronous Data Module (ADM)
- The Digital Terminal Data Module (DTDM)
- The Z702AL1 Data Service Unit (DSU)
- The 703A Data Service Unit (DSU)
- The DEFINITY High Speed Link
- The Processor Data Module (PDM)
- The Trunk Data Module (TDM)
- The Modular Processor Data Module (MPDM)
- General Features of the MPDM
- Functional elements
- Mounting
- Power
- Switches
- Lights
- Features of the AUDIX/CMS MPDM Package
- Functional Elements
- Features of the Video Teleconferencing MPDM
- Functional Elements
- Option Settings
- Features of the High Speed Synchronous MPDM
- Optional Interface Cards
- Functional Elements
- Optional Settings
- MPDM PECs and Comcodes
- Additional Documents
- The Modular Trunk Data Module (MTDM)
- The 3270 Data Module
- The Asynchronous Data Unit (ADU)
- The Multiple Asynchronous Data Unit (MADU)
- DCIU Interface Units
- The 2500-Series DSU
- 22 PC Platforms (PC/PBX and PC/ISDN) and Application Software
- 23 Blank Templates for Model Design
DEFINITYEnterpriseCommunicationsServerandSystem75andSystem85
Terminals and Adjuncts Reference
555-015-201
Issue 11
December 1999
ISDN Voice Terminals
17-37The ISDN 8510 Voice/Data Terminal
17
Recommended power supplies are the 1151A1 and 1151A2 with
Battery Holdover, and MSP-1 (local) Power Supplies and the 1145A
and 1145B1 Bulk Power Supplies.
Terminating Resistors
The terminating resistor jumpers are located on the upper left side on the bottom
of the terminal. Above the pins, on the plastic housing, you will see the label
TERM RESISTOR and a diagram of the correct settings.
These jumpers enable (ON) or bypass (OFF) the terminating resistor. The set is
shipped with the jumpers in the OFF position bypassing the terminating resistor.
You must verify that the jumper settings are set correctly for your configuration.
NOTE:
The terminating resistor jumpers must be set
only
by qualified service
personnel.
■ The terminating resistor jumpers must be set to OFF when the set is in a
point-to-point configuration and the terminating resistor is in the closet or a
440A4 is connected on the line. When set to OFF, each of the two
terminating resistor jumpers covers the two top pins in each set. (The
bottom pin in each set is left uncovered.)
■ The terminating resistor jumpers must be set to ON when the set is in a
point-to-point configuration and the terminating resistor is
not
in the closet
or a 440A4 is
not
connected to the line. When set to ON, each of the two
terminating resistor jumpers covers the two lower pins in each set. (The top
pin in each set is left uncovered.)
■ The terminating resistor jumpers must be set to OFF when the set is in a
multipoint configuration and the terminating resistor is in the closet, a
440A4 is connected on the line, or the jumper is set to ON in one of the
other sets on the line. When set to OFF, each of the two terminating
resistor jumpers covers the two top pins in each set. (The bottom pin in
each set is left uncovered.)
■ The terminating resistor jumpers must be set to ON when the set is in a
multipoint configuration and the terminating resistor is
not
in the closet, a
440A4 is not connected on the line, or the jumper is not set to ON in any of
the other sets on the line. When set to ON, each of the two terminating
resistor jumpers covers the two lower pins in each set. (The top pin in each
set is left uncovered.)
Switch Administration
Use the following information for administering an ISDN 8510T voice terminal.
■ An 8510T voice terminal connected to a DEFINITY G2 should be aliased
as a 7507 voice terminal.
