Adjuncts
20-38The S203A Speakerphone
20
Applications
The S203A Speakerphone can be used with the DEFINITY Communications
System Generic 1, Generic 2, and Generic 3, the DEFINITY ECS, System 75, and
System 85. Its Auto-Answer and Auto-Disconnect capabilities make it very
suitable for environments where hands-free mode of answering is desirable. Such
scenarios include hospital emergency rooms, laboratories, nursing homes,
storerooms, and warehouses.
Physical Description
NOTE:
The following dimensions are approximate.
Dimensions
Width = 4-3/4 inches
Depth (front to back) = 6-1/8 inches
Height = 2-1/4 inches
Features
Speakerphone with light
This non-locking switch turns the S203A on and off. The green light goes on when
the speakerphone is on.
Mute/Auto Answer with light
This button toggles between the Mute and Auto-Answer features. When the
speakerphone is on, the button functions as a Mute button; the red light is on.
When the speakerphone is off, the button functions as the Enable/Disable button
for the Auto-Answer feature; when the Auto-Answer feature is enabled, the light
flashes.
Two Volume buttons
These two nonlocking buttons are labeled with arrows. Between these two buttons
is a row of 10 green lights that indicate the loudness. When the S203A is on, each
depression of an up/down button causes the loudspeaker volume to be raised or
lowered and an light on the right end of the string of illuminated lights to be turned
on or off.
