S-7

Wall Plates & Specialties

These products listed to UL514, Cover Plates for Flush-Mounted Wiring Devices, CSA Certified.

Duplex Receptacle & Decorator Openings

Wall Plates

Duplex Receptacle & Decorator Openings

Standard Size Plastic & Metal

Nylon Thermoset Metal

TradeMaster

Description Color Plates Smooth Material Smooth

Duplex Receptacle Openings

One Gang Ivory TP8-I SP8-I

White TP8-W SP8-W Aluminum SA8

Brown TP8 SP8 Brass SB8

Gray TP8-GRY SP8-GRY Polished Brass SB8-PB

Black TP8-BK 430S/S SL8

Red TP8-RED 302S/S SS8

Light Almond TP8-LA SP8-LA Brushed Bronze SB8-BZ

Blue TP8-BL Chrome SB8-CH

Orange TP8-OR

Two Gang Ivory TP82-I SP82-I

White TP82-W SP82-W Aluminum SA82

Brown TP82 SP82 Brass SB82

Gray TP82-GRY SP82-GRY Polished Brass SB82-PB

Black TP82-BK 430S/S SL82

Red TP82-RED 302S/S SS82

Light Almond TP82-LA SP82-LA Brushed Bronze SB82-BZ

Orange TP82-OR Chrome SB82-CH

Three Gang Ivory SP83-I

White SP83-W Brass SB83

Brown SP83 Polished Brass SB83-PB

Gray SP83-GRY

Light Almond SP83-LA 302S/S SS83

Four Gang Ivory SP84-I

White SP84-W Polished Brass SB84-PB

Brown SP84

Gray SP84-GRY 302S/S SS84

Five Gang

302S/S SS85

Six Gang

302S/S SS86

Decorator Openings

One Gang Ivory TP26-I SP26-I

White TP26-W SP26-W Aluminum SA26

Brown TP26 SP26 Brass SB26

Gray TP26-GRY SP26-GRY Polished Brass SB26-PB

Black TP26-BK SP26-BK 430S/S SL26

Red TP26-RED 302S/S SS26

Light Almond TP26-LA SP26-LA Brushed Bronze SB26-BZ

Blue TP26-BL Chrome SB26-CH

Orange TP26-OR

Summary of content (3 pages)

PAGE 1
Wall Plates & Specialties Wall Plates Duplex Receptacle & Decorator Openings Standard Size Plastic & Metal Nylon Description Color TradeMaster Plates Thermoset Metal ® Smooth Material Smooth Aluminum Brass Polished Brass 430S/S 302S/S Brushed Bronze Chrome SA8 SB8 SB8-PB SL8 SS8 SB8-BZ SB8-CH Aluminum Brass Polished Brass 430S/S 302S/S Brushed Bronze Chrome SA82 SB82 SB82-PB SL82 SS82 SB82-BZ SB82-CH Brass Polished Brass SB83 SB83-PB 302S/S SS83 Polished Brass SB84-PB 302S/S SS84 302
PAGE 2
Wall Plates & Specialties Wall Plates Specifications Application Pass & Seymour/Legrand’s broad line of Standard Size Plastic and Metal Wall Plates features the most complete range of types, sizes, colors, and finishes available. Choose from more than 1,900 standard plates in non-combustible thermoset plastic material, self-extinguishing nylon material, screwless polycarbonate material, or attractively finished metal, for residential, commercial, institutional, and industrial applications.
PAGE 3
Wall Plates & Specialties Wall Plates Specifications Standard Size Wall Plates ■ ■ ■ Standard size wall plates for all applications. Best fit for surface mount boxes. Dimensions 1 gang 2.75" x 4.5" 2 gang 4.56" x 4.5" 3 gang 6.375" x 4.5" 4 gang 5 gang 6 gang 8.125" x 4.5" 10" x 4.5" 11.812" x 4.5" Available in plastic and metal only. 7 gang 8 gang 13.62" x 4.5" 15.44" x 4.5" STANDARD TradeMaster® Wall Plates ■ Extra 3/16" width and height than Standard size wall plates.
