Quick Install Guide
XVW-P30
Wireless Range Extender

After entering the password it will take approximately 30 seconds
to fi nish the setup. After 30 seconds, check the Status LED on the
wireless range extender.

If it is solid green, the wireless range extender has been successfully
installed and is now working. If it is fl ashing blue/green there was a
problem with the setup process, most likely the password was not
entered correctly or the wrong wireless router was selected. Reset/
Factory Default the wireless range extender again and re-install.
Parameter:
Default Value
Default IP address:
192.168.0.11
Default user name:
admin
Default password:
admin

Connect a Client Device
The XVW-P30 is now confi gured and extending your wireless network.
Connecting a Client Device

Connecting a Wireless Client Device: Connect the client device
to the SSID used to confi gured the XVW-P30. This will require the
passphrase used when confi guring the XVW-P30.

Connecting an Ethernet Only Device: Simply set the IP Address to
be obtained through DHCP and connect the device to LAN1 or LAN2
