TABLE 1
Inductance Percent L Test SRF(MHz) Resistance
L(μH) Tolerance Frequency Min. RDC(Ω)±30% IDC1(A) IDC2(A)
1.5 N 100KHz/0.25V 93 26m 4.00 3.20 1R5
2.2 N 100KHz/0.25V 73 34m 3.20 2.70 2R2
3.3 M,N 100KHz/0.25V 55 40m 2.80 2.60 3R3
4.7 M,N 100KHz/0.25V 43 58m 2.40 2.00 4R7
5.6 M,N 100KHz/0.25V 37 66m 2.20 1.90 5R6
6.8 M,N 100KHz/0.25V 30 85m 2.00 1.80 6R8
10 M,N 100KHz/0.25V 18 0.125 1.70 1.40 100
※ □ specify the inductance tolerance,M(±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： drop 30% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ Typ.)
Rated DC Current： The less value whith is IDC1 or IDC2.
MNR-6020-SERIES Page-2/8
MNR-6020-1R5□
Marking
Rated DC CurrentMAGLAYERS
PT/NO.
MNR-6020-5R6□
MNR-6020-100□
MNR-6020-2R2□
MNR-6020-4R7□
MNR-6020-6R8□
MNR-6020-3R3□
MAG.LAYERS
