TABLE 1
Inductance Percent Test Resistance Rated DC Current
L(μH) Tolerance Frequency
RDC(Ω) Max.
IDC1(A) IDC2(A)
2.2 N 100kHz/0.25V 41m 0.85 2.30 2R2
3.3 N 100kHz/0.25V 54m 0.75 2.10 3R3
4.7 N 100kHz/0.25V 78m 0.63 1.65 4R7
MSCDRI-2D18LD-6R8□ 6.8 N 100kHz/0.25V 0.106 0.52 1.32 6R8
MSCDRI-2D18LD-100□ 10 M,N 100kHz/0.25V 0.18 0.43 1.00 100
MSCDRI-2D18LD-150□ 15 N 100kHz/0.25V 0.22 0.35 0.80 150
22 M,N 100kHz/0.25V 0.32 0.30 0.68 220
33 M,N 100kHz/0.25V 0.46 0.24 0.56 330
47 M,N 100kHz/0.25V 0.66 0.20 0.48 470
※ □ specify the inductance tolerance,M(±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo：drop 35% Max.) @ ambient temp. 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDRI-2D18LD-SERIES Page-2/8
Marking
MAGLAYERS
PT/NO.
MSCDRI-2D18LD-3R3□
MSCDRI-2D1 8LD-2R2□
MSCDRI-2D18LD-4R7□
MSCDRI-2D18LD-220□
MSCDRI-2D18LD-330□
MSCDRI-2D18LD-470□
MAG.LAYERS
