Technical Specifications

NSN0703
Part Number
NSN0703
Imperial Dimensions
0.75 inch diameter x 0.125 inch thick
Metric Dimensions
19.05mm diameter x 3.175mm thick
Material
Sintered Neodymium-Iron-Boron (NdFeB)
Shape
Disc
Plating
Ni-Cu-Ni (Nickel)
Magnetization Direction
Thickness
Grade
N40
Pull Force
8.02[3638]
Surface Field
2904
Maximum Operating Temperature
80 Deg C (176 Deg F)
Dimensional Tolerance
+/-0.005"
Magnet Quantity
6
Brand
Magcraft
Packaging
Magpak Tube
UPC
875661000030
Remanent Flux Density Br (kG (T))
12.5-12.8 [1.25-1.28]
Coercivity HcB (kOe (kA/m))
≥11.3 [≥923]
Intrinsic Coercivity HcJ (kOe (kA/m))
≥12.0 [≥995]
Maximum Energy Product Bhmax (MGOe (kJ/m3))
38-41 [302-326]
Density ρ (g/cm3)
≥7.45
Compression Strength (Mpa)
600-1200
Bending Strength (Mpa)
150-380
Vickers Hardness (HV)
460-660
Recoil Permeability (μrec)
1.05
Electrical Resistance (Ω·mm2/m)
1.25-1.55
Curie Temperature Tc (°C)
310
Thermal Expansion Coefficient 100°C // (x10^-6/K)
6
Thermal Expansion Coefficient 100°C ⊥
(x10^-6/K)
-1
These disc magnets are 0.750 inch (19.1mm) diameter and 0.125 inch (3.2mm) thick. They are magnetized
through the thickness. They are composed of grade 40 neodymium iron boron magnetic material and are
plated in nickel-copper-nickel for a shiny corrosion resistant finish. Their individual pull force is
approximately 8 lbs. Maximum working temperature is 176 F (80 C).
Specifications
6
Package of
Page 1 of 1
Magcraft
1934 Old Gallows Rd, STE 350
Vienna, VA 22101, USA
© 2015 National Imports LLC dba Magcraft. All
Rights Reserved. National Imports LLC reserves
the right to change specifications without notice.
2/21/2015
