Introduction Owner's Manual Playback INSTRUCCIONES EN ESPAÑOL INCLUIDAS. Recording NEED HELP FAST? READ YOUR QUICK GUIDE AND/OR OWNER'S MANUAL FIRST FOR QUICK TIPS THAT MAKE USING YOUR MAGNAVOX PRODUCT MORE ENJOYABLE. IF YOU HAVE READ YOUR INSTRUCTIONS AND STILL NEED ASSISTANCE, YOU MAY ACCESS OUR ONLINE HELP AT HTTP://WWW.FUNAI-CORP.COM OR CALL 1-800-605-8610 WHILE WITH YOUR PRODUCT. Basic Setup THANK YOU FOR CHOOSING MAGNAVOX.
PRECAUTIONS WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
PRECAUTIONS information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig.
PRECAUTIONS Installation Location For safety and optimum performance of this unit: • Install the unit in a horizontal and stable position. Do not place anything directly on top of the unit. Do not place the unit directly on top of the TV. • Shield it from direct sunlight and keep it away from devices of intense heat. Avoid dusty or humid places. Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes on the sides of the unit.
PRECAUTIONS Cleaning the cabinet • Use a soft cloth slightly moistened with a mild detergent solution. Do not use a solution containing alcohol, spirits, ammonia or abrasive. • When a disc becomes dirty, clean it with a cleaning cloth. Wipe the disc from the center to out. Do not wipe in a circular motion. • Do not use solvents such as benzine, thinner, commercially available cleaners, detergent, abrasive cleaning agents or antistatic spray intended for analog records.
CONTENTS Introduction Recording PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Symbols Used in this Owner's Manual . . . . . . . . . . . . . . .9 FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . 10 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONTENTS Introduction Editing 58 60 60 61 74 74 75 75 76 76 78 79 80 81 82 83 84 86 87 88 89 90 91 92 Recording Function Setup Playback LIST OF SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 SETUPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FEATURES This unit not only plays back the contents on internal HDD, DVD, or CD, but also offers features for you to record on HDD or DVD and edit them after that. The following features are offered with this unit. Recording Playback This unit allows you to record on the HDD, a DVD+RW/RW (rewritable) and a DVD+R/-R (one-time write). You can choose any one for your convenience. Even if you choose DVD-RW/-R, these discs will automatically be recorded in the DVD+VR mode.
FEATURES Introduction Compatibility Symbols Used in this Owner's Manual Others To specify for which media type each function is, we put the following symbols at the beginning of each item to operate. * DVD-RW/-R recorded in VR mode or non compatible recording format are not playable. * DVD-RW recorded in the mode other than +VR is not recordable on this unit unless you erase all contents in the disc (refer to page 90). * DVD-R recorded in the mode other than +VR is not recordable on this unit.
FUNCTIONAL OVERVIEW Front Panel 1 2 3* 4 14 5 6 7 8* 9 10 13 12 11 (*) The unit can also be turned on by pressing these buttons. 1. STANDBY-ON y button Press to turn the unit on and off. 2. Disc tray Place a disc when opening the disc tray. 3. OPEN/CLOSE A button* Press to open or close the disc tray. 4. Display Refer to “Front Panel Display” on page 14. 5. HDD button Press to select the HDD output mode. 6. DVD button Press to select the DVD output mode. 7.
FUNCTIONAL OVERVIEW Introduction Rear Panel 1 2 IN 3 4 VIDEO VIDEO IN OUT L Y L PB/CB Connections OUT R ANTENNA AUDIO IN (E1) IN R S-VIDEO AUDIO OUT 11 10 9 8 OUT PR/CR COMPONENT VIDEO OUT COAXIAL S-VIDEO 7 6 DIGITAL AUDIO OUTPUT PCM/BITSTREAM 5 Recording 8. AUDIO OUT jacks Use to connect a TV monitor, AV receiver or other device with a RCA audio cable. 9. S-VIDEO IN jack (E1) Use to connect the S-video output of external device with an S-video cable. 10.
FUNCTIONAL OVERVIEW Remote Control Installing the Batteries in the Remote Control Install the batteries (AAAx2) matching the polarity indicated inside battery compartment of the remote control. 1 Open the cover. 2 Insert batteries. Using a Remote Control Keep in mind the following when using the remote control: • Make sure that there are no obstacles between the remote control and the infrared sensor window on the unit.
FUNCTIONAL OVERVIEW Recording Playback Editing Function Setup Others Español EN E2H00UD.indd 13 Basic Setup 20. CLEAR button • Press to clear the information once entered, to clear the marker settings, or to cancel the programming for CD, etc. 21. SETUP button • Press to display the main menu. • During playback, press and hold for more than 3 seconds to switch the progressive scanning mode to the interlace mode. 22. Cursor K / L / { / B buttons • Press to select items or settings. 23.
FUNCTIONAL OVERVIEW Front Panel Display 2 1 PM 3 DTV BS CS DR CD VCR DB HDD DVD 4 5 1. PM 4. Current status of the unit : Appears in the afternoon with the clock display. : Appears when playback is paused. 2. DTV : Appears when playing back a disc. : Appears when the channel is in DTV mode. : Appears when the timer programming or OTR has been set and is proceeding. 3. Title / track / file and chapter mark : Appears when indicating a title / track / file number. 5.
Introduction ANTENNA CABLE CONNECTION This section describes how to connect your unit to an antenna, cable box, etc. 1 2 Disconnect the power cord of your TV from the AC outlet. Disconnect RF coaxial cable from antenna input jack of your TV. Connections rear of your TV VHF / UHF antenna 2 1 disconnect disconnect or RF coaxial cable 3 ANT. IN Basic Setup cable TV company Connect cables to the unit. Make the basic connection as illustrated below.
RF MODULATOR CONNECTION If your TV has antenna in jack only, it is still possible to connect this unit to your TV by using a commercially available stereo audio/video RF modulator. In this case, follow the instructions below. 1) Disconnect the power cords of the devices from the AC outlet. 2) Make the connection as illustrated below. 3) Set your RF modulator’s channel 3/4 switch to either 3 or 4, whichever the TV channel is least used in your area.
1) Disconnect the power cords of the devices from the AC outlet. 2) Make the connection as illustrated below. 3) Plug in the power cords of the devices to the AC outlet. Introduction CONNECTION TO A CABLE / SATELLITE BOX e.g.) This connection is for TV loop through only VIDEO IN Connections rear of your TV satellite dish AUDIO IN R L or ANT.
CONNECTION TO A TV Make one of the following connections, depending on the capabilities of your existing device.
Introduction CONNECTION TO AN AUDIO SYSTEM • When you change the connections, all devices should be turned off. • Refer to the manual accompanying external devices for more information.
BEFORE YOU START After you have completed all the connections, you must find the viewing channel (external input channel) on your TV. Finding the Viewing Channel on Your TV STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 DISC MENU SETUP 1 2 3 After you have made all the necessary connections, press [STANDBY-ON y] to turn on the unit. Turn on your TV.
BEFORE YOU START Guide to On-Screen Display / Menu HDD / DVD Information / Menu 6 Connections The on-screen display changes in the following order as you press [DISPLAY]. 7 OFF 1/ 5 1/ 5 0:01:00 / 1:23:45 DVD Video DTV Program Guide (only in DTV mode) CH 10 2 5 3 5 4 5 KABC A Day of Memories 5 DTV 6.1 English 1/2 A quarter-century ago, which may now qualify as the good old days of newspapering, run-of-paper sales accounted for 80 percent of the industry's advertising revenues.
BEFORE YOU START Title/File Name Information Title Name Information Title Name My Title 1 File Name Information File Name My File 1 1. Displays title/file name. Main Menu Press [SETUP] to display the main menu. Then use [K / L] to select a menu and press [OK] to display the menu. These menus provide entries to all main functions of the unit. Setup 1 2 3 4 5 4 6 4 7 4 General Setting Timer Programming Title List Disc Edit HDD Menu Dubbing CD Playback Mode 1.
BEFORE YOU START Disc Edit Edit Disc Name Erase Disc Make Edits Compatible Disc Protect OFF ON Disc Edit 1 2 3 4 Edit Disc Name Erase Disc Finalize Disc Protect OFF ON Disc Edit 1 3 2 4 3 Edit Disc Name Finalize Disc Protect OFF ON Random Play Program Play PBC (Video CD only) Slide Show HDD Menu Delete All Titles Delete All Unprotected Titles Dubbing 11 1 2 12 HDD DVD DVD HDD Playback 9 1 10
BEFORE YOU START Switching HDD / DVD Mode Because this unit is a combination of HDD and DVD recorder, you must first select which component (output mode) you wish to operate. HDD mode DVD mode Press [HDD] to activate the HDD component. Press [DVD] to activate the DVD component. STANDBY-ON DTV/TV SOURCE DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE .
You need to follow these steps when you turn on this unit for the first time. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 Use [K / L] to select your desired language, then press [OK]. Initial Setup OSD Language English Français Español 0 DISC MENU SETUP o OK s B TITLE RETURN p Initial Setup Recording B j 3 Use [K / L] to select the type of broadcasting signal, then press [OK].
CHANNEL SETTING If you have changed antenna connection, we recommend that you program available channels in your area with the following procedures. Auto Channel Scan STANDBY-ON DTV/TV SOURCE DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 SETUP DISC MENU o OK s B RETURN TITLE p B j F i h g 1 2 3 4 Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. “General Setting” menu will appear.
CHANNEL SETTING STANDBY-ON DISPLAY OPEN/CLOSE A .@/: ABC DEF 2 3 JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 SETUP DISC MENU o OK s B “General Setting” menu will appear. Use [K / L] to select “Channel”, then press [OK]. “Channel” menu will appear. Use [K / L] to select “Manual Channel Preset”, then press [OK]. Auto Channel Preset Manual Channel Preset TV Audio Select • If you are adding or deleting analog TV/CATV channels, go to to continue.
CHANNEL SETTING 5 6 ANALOG Select the channel number to add or delete. • Use [CHANNEL / ] to cycle through only the memorized channels. • Use [{ / B] to cycle through all the channels including the ones not memorized. • Use [the Number buttons] to select a channel directly. • When a memorized channel is selected, “Add” is checked and highlighted as a default. • When an unmemorized channel is selected “Delete” is checked and highlighted as a default.
Introduction SETTING THE CLOCK Set the clock before you try the timer programming. If a PBS (public broadcasting station) is available in your area, follow “Auto Clock Setting” below. If not, follow “Manual Clock Setting” on page 30. Auto Clock Setting SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 5 6 TUV WXYZ 7 8 9 SPACE CLEAR . Use [K / L] to select “Clock”, then press [OK]. “Clock” menu will appear. Use [K / L] to select “Auto Clock Setting”, then press [OK].
SETTING THE CLOCK Manual Clock Setting 1 2 3 4 Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. Daylight Saving Time When “Daylight Saving Time” is “ON”, the unit clock will automatically adjust the time in order to fit the daylight saving time. “ON (MAR - NOV)” has been selected as the default. “General Setting” menu will appear. Use [K / L] to select “Clock”, then press [OK]. “Clock” menu will appear. Use [K / L] to select “Clock Setting”, then press [OK].
Switching Analog Mode / Digital Mode You can easily switch the analog TV (NTSC) and digital TV (ATSC) with the remote control. Note DTV 125. 1 Now Scanning Note [CHANNEL / Use [CHANNEL ] / ] to change the channel.
TUNER SETTINGS This section describes how to switch the TV audio. When you record a TV program, only the audio selected here will be recorded. Selecting TV Audio Digital TV STANDBY-ON DTV/TV SOURCE DISPLAY OPEN/CLOSE 1 Press [AUDIO] to cycle through available audio languages. English 1/2 A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 .
TUNER SETTINGS Introduction Selecting TV Audio (cont’d) Analog TV STANDBY-ON DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 5 6 TUV WXYZ 7 8 9 SPACE CLEAR . 0 SETUP DISC MENU o OK s B RETURN p B j F i h g REC DVD TV Audio Select Stereo: Outputs main-audio. SAP (secondary audio program): Outputs sub-audio. TIMER REPEAT REC MODE D.DUBBING I V.REPLAY Use [K / L] to select “Stereo” or “SAP”, then press [OK].
TUNER SETTINGS DTV Closed Caption Digital TV Digital TV has its own closed captions called DTV CC. Use this menu to change the settings for DTV CC. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 SETUP DISC MENU 1 2 3 o OK s B TITLE Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. “General Setting” menu will appear. Use [K / L] to select “Display”, then press [OK].
TUNER SETTINGS Introduction Closed Caption Style Digital TV Digital TV can also change the style of its closed caption such as font, color or size, etc. SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 5 6 TUV WXYZ 8 9 SPACE CLEAR 7 . 0 SETUP DISC MENU o B RETURN p B j F i h g C AUDIO REC + HDD DVD OSD Language Screen Saver FL Dimmer CC Style V-Chip 4 5 Use [K / L] to select “ON”, then press [OK]. TIMER REPEAT REC MODE D.DUBBING V.
TUNER SETTINGS 6 Use [K / L] to select the item and switch the setting for each item you want to set, then press [OK]. Font color of the displayed caption can be switched as below. Font Color • When “User Setting” is set to “ON”, you can set the following items. CC style set by “User Setting” will be displayed. • The setting description for each item is shown below.
Before you make a recording, read the following information. Recordable Discs Unrecordable Discs Logo Attributes • DVD-RW recorded in the mode other than +VR is not recordable on this unit unless you erase all contents in the disc (refer to page 90). • DVD-R recorded in the mode other than +VR is not recordable on this unit. Maximum recordable numbers of title / chapters HDD : DVD-RW DVD-R Recording DVD+R DVD : Basic Setup DVD+RW 8cm/12cm, single-sided, single layer disc Approx. max.
INFORMATION ON RECORDING Recording Mode About HDD You can select a recording mode among 6 options, and the recording time will depend on the recording mode you select as follows. Disc size Recording mode 8cm Disc 12cm Disc HDD (Internal) Recording time HQ 18 min SP 36 min SPP 45 min LP 54 min Video/sound quality (good) EP 72 min SLP 108 min (poor) HQ 60 min (good) SP 120 min SPP 150 min LP 180 min EP 240 min SLP 360 min (poor) HQ 15 hrs (good) SP 30 hrs SPP 37.
Make Recording Compatible Introduction BEFORE RECORDING Setting for Auto Chapter You can set a specified time for chapter marks. 1) Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. “General Setting” menu will appear. 2) Use [K / L] to select “Recording”, then press [OK]. “Recording” menu will appear. 3) Use [K / L] to select “Auto Chapter”, then press [OK]. 2) Use [K / L] to select “Recording”, then press [OK]. “Recording” menu will appear.
BASIC RECORDING & ONE-TOUCH TIMER RECORDING Follow the steps to record TV programs. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 DEF 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . If you are recording to the HDD, press [HDD] first, then proceed to step 2. If you are recording to a disc, press [DVD] first. 1 Insert a recordable disc (refer to page 24 on how to insert a disc). Align the disc to the disc tray guide.
BASIC RECORDING & ONE-TOUCH TIMER RECORDING 5 Introduction 4 Press [REC I] to start recording. “I HDD” or “I DVD” will be displayed for 5 seconds. e.g.) DVD Press [STOP C] to stop recording. As for DVD recording, the title list will appear automatically after writing to a disc complete. (Refer to “Guide to a Title List” on page 74.) e.g.) DVD+R Connections I DVD Press [PAUSE F] to pause recording. Press [PAUSE F]] or [REC I] again to restart recording. To set one-touch timer recording (OTR)...
TIMER RECORDING You can program the unit to record up to 36 programs within a month in advance. Daily or weekly program recordings are also available. Before recording, make sure • Set the clock before setting a timer programming. • If you are recording to a disc, insert a recordable disc with enough recordable space. Guide to Timer Programming Display 3 1 2 Timer Programming FEB/20/07 10:30 AM 125.1 SP SP (1:00) MON FEB/19 11:30AM Date FEB/20 Start End CH 10:30AM 11:30AM DTV125.
TIMER RECORDING Date FEB/20 CH DTV125. 1 Start 10 : 30AM REC To HDD End --:-Mode SP 1h00m End 11 : 30AM Mode SP SP 1h00m e.g.) digital mode Start 10 : 30AM REC To HDD End 11 : 30AM Mode SP SP 1h00m e.g.
TIMER RECORDING How to select a channel number for the timer recording Analog TV For channel number 2-6 press, press [B] or [ • ] to decide the channels. For other channels (7-69), the channel will be decided as soon as you enter the channel number. Analog CATV For channel number 1-12 press, press [B] or [ • ] to decide the channels. For other channels (13125), the channel will be decided as soon as you enter the channel number.
TIMER RECORDING Connections Basic Setup Recording • If there is a power failure or this unit has been unplugged for more than 30 seconds, the clock setting and all timer programming will be lost. • When recording to a DVD, if a disc is not inserted, the unit will perform the alternate recording to the HDD (refer to page 43).
SPECIAL RECORDING Time Shift Recording STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE With [TIME SHIFT], even if you leave your couch while you are watching TV through this unit, you can come back and watch the rest of the program from right where you left at any convenient time with just one touch of a button. A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 .
SPECIAL RECORDING 2) Load the disc that includes a title to be overwritten. It takes a while to display the title list. 3) Press [REC MODE] to select a recording mode. Refer to “Recording Mode” on page 38. 4) Use [K / L] to select a title to be overwritten, then press [OK]. 1 SP 2) Use [K / L] to select “Play”, then press [OK]. Playback will start. 3) Press [PAUSE F] at the point from which you want to start overwriting. 4) Press [REC I].
SPECIAL RECORDING Hints for Overwriting When you overwrite on the unnecessary title, there were various circumstances such as follows. Please note that following cases only describe the overwriting without any recording mode discrepancy. To avoid accidental deletion please check if there is no important title after the overwriting point. When overwriting title is shorter than the existing title: (overwriting from the beginning of the title) overwrite recording : A 30 - 180 seconds will be cut off.
Introduction DUBBING Information on Dubbing You can dub the contents of the HDD to DVD or vice verse. Before you start dubbing, refer to page 37 to see the recording compatibility.
DUBBING Settings for an External Device Connect the external device properly to the unit by using input jacks either E2 (Front) or E1 (Rear). When connecting an external device of monaural output to this unit, use AUDIO L jack of E2 (Front). Use S-video or the RCA audio/video cables for this connection. or S-VIDEO OUT VIDEO OUT AUDIO OUT R L VIDEO OUT external device AUDIO OUT R L S-VIDEO OUT (camcorder, VCR etc.
DUBBING Before recording from an external device, refer to the instructions for the connection on page 50. If you are recording to the HDD, press [HDD] first, then proceed to step 2. If you are recording to a disc, press [DVD] first. SOURCE DTV/TV DISPLAY OPEN/CLOSE A ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 DISC MENU 1 2 SETUP o B RETURN p B j F h g C CHANNEL -AUDIO REC + HDD DVD TIMER REPEAT REC MODE D.DUBBING I V.REPLAY V.
DUBBING Selected Title Dubbing Preparing for dubbing (HDD to DVD): • Insert a recordable DVD. Preparing for dubbing (DVD to HDD): • Insert a disc to be dubbed. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 1 2 Press [SETUP] in stop mode. Use [K / L] to select “Dubbing”, then press [OK].
DUBBING e.g.) HDD 8 Introduction 5 Use [K / L / s / B] to select a desired title, then press [OK]. Use [s / B] to select a desired recording mode, then press [OK]. HDD DVD Title List 1 2 Please select REC MODE. CH10 SP High 3 HQ SP SPP LP EP Dubbing Titles 4 5 Repeat steps 4 to 5 until you register all the titles to be dubbed. Yes No Dubbing will start. • It may take awhile to prepare for the dubbing. To stop the dubbing in progress: Press [STOP C] on the front panel.
DUBBING One Title Dubbing (HDD to DVD only) This function lets you select one specific title from the title list for dubbing. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . DEF Preparing for dubbing: • Insert a recordable DVD. 1 2 3 0 DISC MENU SETUP o OK s RETURN p B F i h g C CHANNEL -AUDIO REC + HDD Use [K / L / s / B] to select a desired title to dub, then press [OK].
To prevent accidental recording, editing or erasing the titles, you can protect them from “Disc Edit” menu. STANDBY-ON DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 9 CLEAR . Use [K / L] to select “Disc Protect OFF ON”, then press [OK]. e.g.) DVD+RW Disc Edit Edit Disc Name Erase Disc Make Edits Compatible Disc Protect OFF ON 0 SETUP DISC MENU Use [K / L] to select “Disc Edit”, then press [OK]. Basic Setup 8 SPACE 7 Press [SETUP].
PLAYING THE DISCS ON OTHER DVD PLAYERS Finalizing a Disc You will need to finalize DVD+R, DVD-RW or DVD-R to play them back on other DVD players. Finalizing may take several minutes up to an hour. A shorter recording period on the disc will require a longer time period for finalization. Do not unplug the power cord during finalization. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 1 2 3 4 Press [SETUP].
PLAYING THE DISCS ON OTHER DVD PLAYERS Introduction Auto Finalizing STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 o OK s RETURN p B i h g 5 C REC + HDD DVD Auto Finalize Disc Full End of Timer Rec Use [K / L] to select “ON”, then press [OK]. e.g.) “Disc Full” Disc Full Your setting will be activated. TIMER REPEAT REC MODE D.DUBBING I V.SKIP RAPID PLAY TIME SHIFT 6 Press [SETUP] to exit.
INFORMATION ON PLAYBACK Before you play back DVD, read the following information. Playable Discs and Files Unplayable Discs This unit is compatible to play back the following discs. To play back a DVD, make sure that it meets the requirements for region codes and color systems as described below. You can play back discs that have the following logos will play back on the unit. Other disc types are not guaranteed to play back.
INFORMATION ON PLAYBACK DVD-video title 1 chapter 1 chapter 2 track 1 chapter 1 title 2 chapter 2 audio CD, video CD track 2 track 3 track 4 chapter 3 track 5 Basic Setup • PBC setting turns to “ON” when loading video CD with PBC function, thus, even after setting PBC to “OFF” and ejecting the video CD then reloading the video CD, this setting turns to “ON” automatically. • Some operations cannot be performed while PBC function is on.
BASIC PLAYBACK Direct Playback If you are playing back the titles in HDD, press [HDD] first, then proceed to step 2. If you are playing back the titles in DVD, press [DVD] first. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 3 GHI JKL MNO DEF 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 1 Align the disc to the disc tray guide. * Make sure the disc is compatible with this unit. (Refer to page 58 for the list of compatible discs.
BASIC PLAYBACK STANDBY-ON DTV/TV DISPLAY OPEN/CLOSE A ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 DISC MENU SETUP o OK s 1 It may take a while to load the disc. 2 B RETURN • To exit the title list, press [STOP C]. • To resume the title list, press [TITLE]. p B j F i h g C CHANNEL -- REC + HDD DVD TIMER REPEAT REC MODE D.DUBBING I V.REPLAY 3 Use [K / L // s / B] to select a desired title, then press [OK].
BASIC PLAYBACK Note for DVD title list If you want to see disc information, press [{ ] when the first page of the title list is displayed or press [ K ] when the first title is selected but not when “Play”, “Edit” or “Overwrite” is highlighted. e.g.) DVD+RW 4 Use [K / L] to select “Play” (for DVD), or select “Resume Playback” or “Play from Start” (for HDD), then press [OK]. e.g.
BASIC PLAYBACK Introduction Playing Back an Audio CD and a CD-RW/-R with MP3 / JPEG Files STANDBY-ON DISPLAY OPEN/CLOSE It may take a while to load the disc. A .@/: ABC 1 2 3 GHI JKL MNO DEF 5 6 TUV WXYZ 7 8 9 SPACE CLEAR . When an audio CD is inserted, track list will appear. When a CD-RW/-R with MP3/JPEG files is inserted, file list will appear. • To exit the track/file list, press [STOP C]. • To resume the track/file list, press [TITLE].
BASIC PLAYBACK Playing Back an Audio CD and a CDRW/-R with MP3 / JPEG Files (cont’d) Kodak Picture CD The Picture CD is a service to convert photographs taken by a conventional film camera into digital data and write the data on a CD. You can enjoy picture images on the TV set by playing back the Picture CDs. For details of Kodak Picture CD, contact a shop that provides developing service of Kodak Inc. 1) Press [TITLE].
Resume Playback Introduction SPECIAL PLAYBACK Note You can play back from where you stopped playing back the disc last. Resume ON During playback, you can skip forward or backward by the amount of time you set in “Playback” menu. To set the time amount, refer to “ 8 Variable Skip / Replay” on page 99. During playback, press [V.SKIP] if you want to skip forward. Press [V.REPLAY] if you want to skip backward. Recording For HDD: You can set a resume point per every title.
SPECIAL PLAYBACK Step by Step Playback Time Shift Playback 1) During playback, press [PAUSE F]. Playback will be paused and sound will be muted. 2) Press [G] repeatedly. Playback will advance one frame (or step) at a time when you press [G] with the sound muted. To play back step by step backward: Press [H] repeatedly. Every time you press the button, the playback will go backward by one frame. • Press and hold [H] / [G] to reverse / advance continuously. 3) Press [PLAY B] to continue the normal playback.
SPECIAL PLAYBACK Introduction Marker Setting Zoom 1) During playback, press [DISPLAY]. 1/ 5 1/ 5 0:01:00 / 1:23:45 , then press [OK] within 1 2) Use [{ / B] to select second or wait for 1 second to display the marker list. e.g.) DVD-video 1/ 5 1/ 5 0:01:00 / 1:23:45 DVD Video 3) Use [K / L] to select a desired zoom factor to zoom, then press [OK]. 1/ 5 1/ 5 0:01:00 / 1:23:45 3) Use [K / L] to select a desired marker number. When it reaches the desired point, press [OK]. × 1.2 × 1.5 × 2.
SPECIAL PLAYBACK Repeat Playback Note Available repeat function may vary depending the discs. 1) During playback press [DISPLAY], then proceed to step 2), or press [REPEAT] then proceed to step 3). , then press [OK] within 1 2) Use [{ / B] to select second or wait for 1 second to display the selection menu. 1/ 5 1/ 5 0:01:00 / 1:23:45 • Point B for the repeat A-B playback should be set within the same title or track as point A. • To cancel the repeat playback, select “OFF” at step 3.
SPECIAL PLAYBACK Slide Show You can select the display time between 5 seconds and 10 seconds. 1) Press [SETUP]. 1) Follow steps 1 and 2 in “Random Playback” on page 68. 2) Use [K / L] to select “CD Playback Mode”, then press [OK]. “CD Playback Mode” menu will appear. 3) Use [K / L] to select the display time, then press [OK]. Basic Setup 3) Use [K / L] to select “Program Play”, then press [OK]. 2) Use [K / L] to select “Slide Show”, then press [OK].
SEARCH Title / Chapter Search Track Search Using [H] / [G] Using [H] / [G] 1) During playback, press [G] to skip the current title or chapter and move to the next. The title or chapter will move forward by one at a time. • If there is no chapter in one title, the current title will be skipped. 1) During playback, press [G] to skip the current track/file and move to the next. The track/file will move forward one at a time. To go back to the beginning of the current track/file, press [H].
SEARCH Introduction Time Search 1) During playback, press [DISPLAY]. 1/ 5 Connections , then press [OK]. 2) Use [{ / B] to select e.g.) DVD-video 1/ 5 0:01:00 / 1:23:45 DVD Video Basic Setup e.g.) audio CD 1/ 5 0:00:15 / 0:05:00 CD When time search is not available, counter are not displayed. Recording The number next to will be highlighted. To move to the number next to , press [B].
SELECTING THE FORMAT OF AUDIO AND VIDEO You can select the format of audio and video as you prefer depending on the contents of the disc you are playing back. Switching Subtitles Switching Audio Soundtrack DVD-video may have subtitles in 1 or more languages. Available subtitle languages can be found on the disc case. You can switch subtitle languages anytime during playback.
SELECTING THE FORMAT OF AUDIO AND VIDEO 2) Use [{ / B] to select , then press [OK] within 1 second or wait for 1 second to display the selection menu. e.g.) DVD-video , then press [OK]. 2) Use [{ / B] to select e.g.) DVD-video 1/ 5 1/ 5 0:01:00 / 1:23:45 DVD Video Basic Setup 1/ 5 Some DVD-video have scenes shot from 2 or more angles. Angle information should be on the disc case if the disc contains multi-angle scenes. 1) During playback, press [DISPLAY]. 1) During playback, press [DISPLAY].
INFORMATION ON EDITING Guide to a Title List Title list allows you to check the titles recorded on the HDD or the disc easily. You can choose a title to play back from this list and easily edit the titles as you prefer. Press [HDD], then press [TITLE]. Press [DVD], then press [TITLE].
INFORMATION ON EDITING Introduction Edit Menu Media Available Futures Putting names on titles HDD DVD ✔ ✔ ✔ Deleting selected titles ✔ Deleting a scene of a title ✔ Adding / deleting chapter marks ✔ Connections ✔ Deleting a title ✔ ✔ Hiding chapters ✔ Dividing a title ✔ ✔ *1 Basic Setup Protecting a title ✔ Setting an index picture ✔ Making edits compatible ✔ *2 Note Putting name on disc ✔ Setting or Releasing disc protect ✔ • Once you have finalized a DVD+R/ DVD-R, you canno
EDITING Deleting a Title You can delete a title which you do not need anymore. Please be advised that the title once deleted cannot be brought back. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ If you are editing the titles on HDD, press [HDD] first. If you are editing the titles on DVD, press [DVD] first. 1 2 Press [TITLE]. Use [K / L / { / B] to select a desired title to delete, then press [OK].
EDITING HDD mode Resume Playback Play From Start Edit Title Delete Delete Multiple Titles Dubbing 5 Use [K / L] to select “Yes”, then press [OK]. Final confirmation message will appear. Select “Yes”, then press [OK]. The title is now deleted. Connections Title List JAN/ 1/07 12:00AM CH10 SP 12:00AM (1:00:00) JAN/ 1/07 1 2 4 5 CH10 SP 3 DVD mode +VR Edit 1 Introduction 4 Use [K / L] to select “Title Delete”, then press [OK].
EDITING Deleting Selected Titles You can delete titles which you do not need anymore. Please be advised that the titles once deleted cannot be brought back. 3 Use [K / L] to select “Delete Multiple Titles”, then press [OK]. 4 Use [K / L / { / B] to select the title you want to delete, then press [OK]. STANDBY-ON DTV/TV SOURCE Resume Playback Play From Start Edit Title Delete Delete Multiple Titles Dubbing DISPLAY OPEN/CLOSE A .
EDITING You can put title names on the titles and change the names from this menu. STANDBY-ON 4 Use [K / L] to select “Yes”, then press [OK]. +VR Edit - Edit Title Name Connections 1 Yes No SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 2 3 JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . MY FAVORITE 0:00:59 The title name is now updated. 5 0 DISC MENU SETUP o OK s Press [RETURN] once or repeatedly to go back to the title list.
EDITING Chapter Marks (Add) You can put chapter marks in each title. Once a chapter is marked, you can use it for the chapter search feature. STANDBY-ON DTV/TV SOURCE DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 DISC MENU SETUP o OK s B RETURN TITLE p B j F i h g To add a chapter mark: 1 2 3 4 Follow steps in “How to Access the Edit Menu” on page 75 to display “Edit” menu.
EDITING Introduction Chapter Marks (Delete) STANDBY-ON DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 9 CLEAR . 0 DISC MENU SETUP o OK s B RETURN TITLE p F Submenu will appear. Use [H] / [G] to go to the chapter with the chapter mark number you want to delete, then press [PAUSE F]. Chapter mark number is displayed on the preview screen. e.g.) DVD i +VR h g Recording B j Use [K / L] to select “Chapter Mark”, then press [OK].
EDITING Chapter Marks (Delete All) To delete all chapter marks: STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 DISC MENU SETUP o OK s B RETURN TITLE p B j 1 2 3 4 Follow steps in “How to Access the Edit Menu” on page 75 to display “Edit” menu. Use [K / L] to select “Chapter Mark”, then press [OK]. Submenu will appear. Use [K / L] to select “Delete All”, then press [OK].
EDITING Introduction Dividing a Title You can divide one title into 2 new titles. SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 2 3 JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 DISC MENU SETUP o B RETURN p B j F When it comes to the desired point, press [PAUSE F]. Use [K / L] to select “Title Dividing”, then press [OK]. Use [K / L] to select “Yes”, then press [OK]. The title is now divided into 2 new titles, and it will go back to the title list automatically.
EDITING Deleting a Scene of a Title You can delete a specific part of a title. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 DEF 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 1 2 Follow steps in “How to Access the Edit Menu” on page 75 to display “Edit” menu. Use [K / L] to select “Scene Delete”, then press [OK].
EDITING 7 Edit - Scene Delete 1 Yes No Connections Before and after 5 seconds of the deleted scene can be previewed every time you press [OK]. • If you are not satisfied with the result, use [K / L] to go back to “Start” or “End”, and try setting them again. • If you are satisfied with the result, proceed to step 6. Use [K / L] to select “Yes” then press [OK]. JAN/ 1/07 12:00AM CH10 LP 0 : 07 : 00 start point end point Recording 6 Use [K / L] to select “Delete” then press [OK].
EDITING Protecting a Title To prevent the accidental editing, or erasing of the titles, you can protect them in “Edit” menu. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 1 2 Follow steps in “How to Access the Edit Menu” on page 75 to display “Edit” menu. Use [K / L] to select “Protect”, then press [OK].
EDITING Introduction Hiding Chapters You can hide chapters from the title list. Hidden chapters are skipped during playback. SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 5 6 TUV WXYZ 8 9 SPACE CLEAR 7 . 0 DISC MENU SETUP o Submenu will appear. Use [H] / [G] to go to the chapter you want to hide, then press [PAUSE F]. Use [K / L] to select “Hidden”, then press [OK].
EDITING Setting an Index Picture You can set your desired scene as an index picture for each title. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 DISC MENU SETUP o OK s 1 2 3 4 Follow steps in “How to Access the Edit Menu” on page 75 to display “Edit” menu. Play back the title to find the scene you want to use as an index picture. When it comes to the desired point, press [PAUSE F].
EDITING Introduction Putting Name on Disc Press [STOP C] if you are playing back a disc. You can put a name on the disc and change it from this menu. SOURCE DTV/TV DISPLAY OPEN/CLOSE A ABC 1 2 DEF 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 o e.g.) DVD+RW Disc Edit A window for entering a title name will appear. B RETURN p +VR Edit Disc Name Recording OK s TITLE Use [K / L] to select “Edit Disc Name”, then press [OK].
EDITING Erasing Disc Press [STOP C] if you are playing back a disc. You can erase all titles on a disc. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 DEF 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 1 2 3 SETUP DISC MENU OK Use [K / L] to select “Disc Edit”, then press [OK]. Use [K / L] to select “Erase Disc”, then press [OK]. e.g.) DVD+RW Disc Edit Edit Disc Name Erase Disc Make Edits Compatible Disc Protect OFF ON o s Press [SETUP].
EDITING Introduction Making Edits Compatible STANDBY-ON DTV/TV SOURCE DISPLAY OPEN/CLOSE A ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE . 1 2 3 Press [SETUP]. 4 Use [K / L] to select “Yes”, then press [OK]. CLEAR 0 Use [K / L] to select “Disc Edit”, then press [OK]. Basic Setup .@/: Press [STOP C] if you are playing back a disc. Use [K / L] to select “Make Edits Compatible”, then press [OK].
EDITING Deleting All Titles in HDD Press [STOP C] if you are playing back a disc. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 SETUP DISC MENU o OK s 1 2 3 B TITLE Press [SETUP]. Use [K / L] to select “HDD Menu”, then press [OK]. Use [K / L] to select the desired type of deletion, then press [OK]. Select “Delete All Unprotected Titles” if you want to delete only the unprotected titles.
The following table is the contents which you can set and the default setting. Refer to the following table for useful operation. Setup Playback Pages 96-99 Items (highlight is the default) Parental Lock Disc Audio PCM Dolby Digital Disc Menu Language Subtitle Language Still Mode OSD Language General Setting Screen Saver FL Dimmer CC Style DTV CC Pages 34-36 OFF Service1 Service2 Service3 Service4 Service5 Service6 ON OFF Set the type of the DTV closed caption.
LIST OF SETTINGS Setup Display Pages 100-101 Items (highlight is the default) CC Style Font Style Pages 34-36 Edge Type Font Opacity Font Color General Setting Back Opacity Back Color V-Chip00 Video Pages 102-103 Progressive Scan TV Aspect Video Input Page 50 E1(Rear) E2(Front) Recording Auto Chapter Page 39 Auto Finalize Page 57 Disc Full Style1 Style2 Style3 Style4 Style5 Style6 Style7 Style8 Contents Set font style of the displayed caption. None Raised Depressed Uniform L.Shadow R.
LIST OF SETTINGS Items (highlight is the default) Clock Setting Auto Clock Setting Channel Pages 26-28 Auto Channel Preset Manual Channel Preset TV Audio Select Page 33 Reset All Page 104 Antenna Cable (Analog) Cable (Analog/Digital) Set the clock for the daylight saving time. Tune the channels automatically. Tune the channels manually. Set the analog TV audio type for output and recording. Set to the default setting. Basic Setup Stereo SAP Yes No Contents Set the clock.
SETUPS Playback STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 Press [STOP C] if you are playing back a disc. 1 2 Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. “General Setting” menu will appear. Use [K / L] to select “Playback”, then press [OK].
SETUPS Introduction Playback (cont’d) 1 Parental Lock (Default: OFF) (DVD only) Parental Lock If a password has not been set yet, proceed to A . If a password has been set already, proceed to B . Yes No Password Input Yes Your setting will be activated. B A password has been set already. • Use [the Number buttons] to enter the current password. Password Input Your setting will be activated. • If you want to change password, use [K / L] to select “Yes”.
SETUPS Playback (cont’d) 2 C Disc Audio Choose the appropriate audio setting for your external device. It will only affect a disc playback. Use [K / L] to select a setting, then press [OK]. Dolby Digital PCM Stream Use [K / L] to select a desired item, then press [OK]. Disc Audio A B C A Dynamic Range Control PCM Dolby Digital Dynamic Range Control (Default : ON) (DVD only) Set to “ON” to compress the range between soft and loud sounds. Use [K / L] to select a setting, then press [OK].
SETUPS 5 Subtitle Language (Default : OFF) (DVD only) Set the subtitle language. Use [K / L] to select a setting, then press [OK]. 7 Still Mode (Default : Auto) (DVD only) Select “Auto” usually. Use [K / L] to select a setting, then press [OK]. Auto Field Frame OFF English French Spanish Other Your setting will be activated. 5 , press 4-digit code Note • Frame is 1 completed video image made up of 2 fields (There are 30 frames per second of NTSC video).
SETUPS Display Press [STOP C] if you are playing back a disc. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 SETUP DISC MENU o OK s 1 2 3 B TITLE RETURN p B j F g C CHANNEL -AUDIO REC + HDD DVD TIMER REPEAT REC MODE D.DUBBING I V.REPLAY V.SKIP RAPID PLAY TIME SHIFT Use [K / L] to select “Display”, then press [OK]. Use [K / L] to select a desired item, then press [OK].
SETUPS 1 OSD Language (Default : English) Set the language for the on-screen display. Use [K / L] to select a setting, then press [OK]. English Français Español Password Input Your setting will be activated. 2 2) Use [K / L] to select a desired item, then press [OK]. Screen Saver (Default : 10 minutes) Screen Saver A Downloadable Rating Change Password Downloadable Rating Set the rating system via digital broadcasting, or clear the downloaded ratings.
SETUPS Video Press [STOP C] if you are playing back a disc. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC DEF 1 2 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 7 8 9 SPACE CLEAR . 0 SETUP DISC MENU o OK s B TITLE 1 2 3 RETURN Press [SETUP] and use [K / L] to select “General Setting”, then press [OK]. Use [K / L] to select “Video”, then press [OK]. Use [K / L] to select a desired item, then press [OK]. 1 Progressive Scan 2 TV Aspect 3 Video Input p Submenu will appear.
SETUPS 1 Progressive Scan (Default : OFF) 1) Use [K / L] to select “ON“, then press [OK]. Progressive Scan TV Aspect Activating progressive scan: Check your TV has progressive scan and connect with component video cable. Recording NOTE : If there is no picture or picture is distorted after selecting “Yes”, Wait about 15 seconds for auto recovery.
SETUPS Reset All Reset the setting to default. STANDBY-ON SOURCE DTV/TV DISPLAY OPEN/CLOSE A .@/: ABC 1 2 DEF 3 GHI JKL MNO 4 5 6 PQRS TUV WXYZ 8 9 SPACE CLEAR 7 . 0 1 2 3 o OK s B TITLE RETURN p B j F i h g C CHANNEL -AUDIO REC DVD Use [K / L] to select “Reset All”, then press [OK]. Select “Yes” using [K / L] , then press [OK]. Reset to factory default? 4 Select “Yes” again using [K / L] , then press [OK].
Before requesting service for this unit, check the table below for a possible cause of the problem you are experiencing. Some simple checks or a minor adjustment on your part may eliminate the problem and restore proper operation. The unit turns on automatically without any operation. The OSD language menu appears every time the power turns on. Remedy • Check that the AC power cord is connected securely. • Batteries of the remote control are weak.
DVD RECORDING HDD HDD/DVD TROUBLESHOOTING Timer recording cannot be performed. • Titles recorded by the time shift recording function will not be stored Titles which were supposed to be recorded by the time shift in the title list. They may be stored temporarily in the title list, but will recording function cannot be found be deleted when you exit the time shift recording mode. Time shift in the title list.
EDITING HDD / DVD DVD Dubbing cannot be executed. Titles cannot be edited or deleted. Playback The remote control does not function. • No batteries in the remote or the batteries may be weak. Replace the batteries. • Make sure there is no obstacle between the remote and the unit. • Try getting closer to the unit. (Refer to page 12.) • If above solutions do not solve the problem, please call an Authorized Service Center.
TROUBLESHOOTING Error message Cause Solution Disc Error — Please eject the disc. — Playback feature may not be available on this Disc. • Unplayable disc is inserted in the unit. • The disc is upside down. • Insert the standardized disc which bear the marks on page 58. • Insert the disc with the labeled side facing up. Region Error — Please eject the disc. — Playback is not authorized in your region. • Playback is not authorized in the region of the DVD-video which you inserted in the unit.
Function Setup Others Code 6467 6559 6553 6547 5350 6564 6554 6566 6660 6560 6550 6555 6565 6557 6558 6561 5165 6567 6569 6568 6658 6653 6647 6666 6651 6654 4861 6655 6661 6665 6664 6657 6669 6757 6764 6772 6855 6861 4971 6961 7054 5655 7161 7267 Editing Language Russian Samoan Sangho Sanskrit Scots Gaelic Serbian Serbo-Croatian Sesotho Setswana Shona Sindhi Singhalese Siswat Slovak Slovenian Somali Spanish Sundanese Swahili Swedish Tagalog Tajik Tamil Tatar Telugu Thai Tibetan Tigrinya Tonga Tsonga Turk
GLOSSARY Analog Audio PBC (playback control) (video CD only) An electrical signal that directly represents sound. Compare this to digital audio which can be an electrical signal, but is an indirect representation of sound. See also “Digital Audio”. This function enables you to play back interactive software using a menu screen. See also “Video CD”. Aspect Ratio The width of a TV screen relative to its height.
+VR (video recording) format DVD+Rewritable, DVD+Recordable DVD-Rewritable, DVD-Recordable (+VR mode only) Video recording format Sampling frequency Compression format 13.
ESPAÑOL Discos Reproducibles Disco Grabable Este aparato es compatible con la reproducción de los siguientes discos y archivos. Discos reproducibles Logotipos DVD-video Este aparato puede grabar a DVD+RW, DVD+R, DVD-RW y DVD-R. Los discos DVD+R/DVD-R pueden ser grabados sólo una vez. Los discos DVD+RW/DVD-RW pueden ser grabados y borrados muchas veces. En este aparato los discos DVD-RW/-R serán grabados automáticamente en el modo DVD+VR.
ESPAÑOL Introduction Conexión Básica 1) Desconecte el cable de alimentación de su televisor del tomacorriente de CA. 2) Efectúe la conexión básica ilustrada más abajo.
ESPAÑOL Configuración Inicial Cuando usted encienda este aparato por primera vez necesita seguir estos pasos. 1 2 3 Utilice [K / L] para seleccionar el tipo de señal de emisión, y luego presione [OK]. Ajuste inicial Ajuste de Canal Presione [STANDBY-ON y]. Verificar que la antena esté conectada a la toma "ANTENNA IN". Antena Cable (Analógico) Cable (Analógico/Digital) Encienda el televisor. Seleccione la entrada a la cual está conectado el aparato.
ESPAÑOL HDD Utilice [K / L] para seleccionar “Doblaje”, y luego presione [OK]. Seleccione REC MODE. Alto HQ SP SPP LP EP SLP Auto 500 MB 3000 MB Unidad de disco rígido a DVD Utilice [K / L] para seleccionar “HDD DVD”, y luego presione [OK]. Utilice [K / L] para seleccionar “Añadir”, y luego presione [OK]. DVD 3000 MB Lista doblaje Añadir Borrar todo Inic de doblaje 1/1 Repita los pasos 4 y 5 hasta que registre todos los títulos a ser copiados.
LIMITED WARRANTY FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows: DURATION: PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Certain parts are excluded from this warranty. LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date of original retail purchase.
