HDD & DVD Player/Recorder with Digital Tuner Owner's Manual

64 EN64 EN
BASIC PLAYBACK
Using the Title / Disc Menu
DVD or video CD with PBC function may contain a title
list, which describes the contents of the disc, or a disc
menu, which guides you through the available functions
in the disc.
Press [DVD] first.
1) Insert a disc (refer to page 24 on how to insert a
disc).
* Make sure the disc is compatible with this unit. (Refer
to page 58 for the list of compatible discs.)
It may take a while to load the disc.
2) Press [TITLE] or [DISC MENU] to call up the title list
or disc menu.
3) Use [K / L / { / B] to make a selection, and then
press [OK] to enable your selection.
4) Press [STOP C] to exit.
1) During playback, press [PAUSE F].
Playback will be paused.
F
2) Press [PLAY B] to return to the normal playback.
Note
• You can select a numbered menu with [the Number
buttons] also.
• Menus vary among discs. Refer to the information
accompanying the disc for details.
• [TITLE] or [DISC MENU] will not always be active
with all DVD.
• For video CD, when “PBC (Video CD only)” in “CD
Playback Mode” menu is “ON”, the video CD main
menu will appear when inserting a disc.
Note
• On DVD, set “Still Mode” to “Field” in “Playback”
menu if pictures in the pause mode are blurred.
(Refer to page 99.)
Pause
Kodak Picture CD
Playing Back an Audio CD and a CD-
RW/-R with MP3 / JPEG Files (cont’d)
The Picture CD is a service to convert photographs taken
by a conventional film camera into digital data and write
the data on a CD. You can enjoy picture images on the TV
set by playing back the Picture CDs.
For details of Kodak Picture CD, contact a shop that
provides developing service of Kodak Inc.
1) Press [TITLE].
Picture CD
1 / 2
4 5 6
1 2 3
Image 1
• To exit the Picture CD thumbnail List, press [TITLE]
again or press [STOP C].
Arrow icons mean the title list includes a next or
previous page. Use [{ / B] in the direction of the
icon you wish to follow. You can also quick review the
six thumbnails at once between the first and last
pages by pressing [H / G].
2) Use [K / L / { / B] to select a desired track to be
played back, then press [PLAY B] or [OK].
An image will be played back from the selected track
and go to the next one in turn.
3) Press [STOP C] to stop playback.
Notes on JPEG and Kodak Picture CD:
• After track is displayed for 5 seconds or 10 seconds
(set in the “Slide Show” on page 69) the display
moves to the next track.
During JPEG or Kodak Picture CD playback, press [B]
or [{] to rotate a picture 90 degrees clockwise or
counterclockwise respectively.
(Not available when the display menu appears.)
