-1- Magnum Dynalab MD 809 T Internet Media Tuner INSTRUCTION MANUAL 1
-2- TABLE OF CONTENTS MAGNUM DYNALAB MD 809 T ......................................................................................... 1 Internet Media Tuner ................................ 1 TABLE OF CONTENTS ........................................................................................................ 2 QUICKSTART: ..................................................................................................................... 4 DEAR VALUED CUSTOMER ......................................
-3MUSIC PLAYER MODE (NETWORK AND USB) ............................................................. 15 SHARED MEDIA (FROM UPnP MEDIA SERVER)15 DAB RADIO MODE ........................................................................................................... 17 FM RADIO MODE ............................................................................................................. 18 IMAGE/FUNCTIONS OF RF-20 REMOTE .......................................................................
-4- QUICKSTART: BEFORE DOING THIS PLEASE START READING AT PAGE 4 FOR SETUP OF UNIT TURN ON UNIT WITH MAIN POWER SWITCH ON THE BACK AND FRONT OF UNIT Hooking up to the WIRELESS Internet service 1. Tap the Settings Menu 2. go to Network Settings 3.
-5- Dear Valued Customer Thank you for choosing the Magnum Dynalab MD Wi Fi Tuner Plus. Great care has been given to the design, manufacturing and selection of components for the MD Internet Media Tuner. This complete process ensures optimum listening enjoyment for many years. When using these high grade components, a considerable length of time is required for the MD 809 T Internet Media Tuner to reach its full potential. Have the tuner run continuously for 3 days in order to fully warm up its components.
-6- UNPACKING YOUR MD Tuner Carefully inspect all sides of the shipping carton for damage. If there are marks or holes in the carton make note of the location in relation to the unit inside. Any obvious dents or scuff marks should alert you to the possibility of damage. Carefully remove the MD Internet Media Tuner from the end caps and wrapping, inspect all sides. Pay special attention to the corresponding areas on the unit where damage was found to the shipping carton.
-7- SETTING UP THE MD Internet Media Tuner 1. Position the tuner away from any spot which may have extremes in temperatures. 2. Place the tuner on a very rigid surface capable of holding 75 pounds (34 KG). 3. It is important that the tuner is not covered and it is not installed in a closed area where there is little air circulation. Ensure at least 2” of clearance on the left and right of the device, and 5” of clearance above the unit to allow for proper ventilation. 4.
-8known for around the world. The MD 809 combines the engineering from our flagship MD 109 World Source Platform with the audio board design of our new MD 309 Hybrid Integrated Amplifier allowing you, our customer to enjoy over 20,000 Tuner stations worldwide, and for the first time with the Magnum Dynalab performance our listeners have come to expect.
-9- DISPLAY FUNCTIONS AND USAGE UI Screen Buttons Function/usage Home: takes you back to main menu icon screen. Close Back: Return to previous screen. Directory: In play mode, this button may be used to return to the last track list or station list. Preset: Radio modes: Press to select; There are 10 presets each for DAB and FM modes. Add to presets Information: View more information about the station or track playing. Touch button to show a separate information screen covering the whole play screen area.
- 10 - MENU SCREEN OPERATION The MD 809 T has three types of menu: The Main menu allows access to all modes and settings functions. Each mode has a menu, with options specific to that mode. For example, the DAB Tuner mode menu has five options: Scan, Edit favorites, DRC, manual tune and Prune invalid stations. The system Settings menu allows access to system settings and information such as time, equalizer, network, backlight settings and miscellaneous settings.
- 11 program for the song you are listening to. Most common today are : MP3, MP4, MPEG, WAV Sampling Rate: The sampling rate, sample rate, or sampling frequency defines the number of samples per unit of time (usually seconds) taken from a continuous signal to make a discrete signal. Browsing You are able to browse stations and songs with the MD 809 in Internet Tuner, FM, DAB and in Music Player Mode.
- 12 - Internet Tuner Mode The MD 809 can play thousands of radio stations and podcasts from around the world though a broadband Internet connection. To enter Internet Tuner mode touch the Internet Tuner icon from the main menu and this will take you to the Internet Tuner playing screen. INTERNET TUNER CONNECTION SETUP During initial setup of your internet tuner, the MD 809 will search your home for an available Wi Fi network.
- 13 - INTERNET RADIO PORTAL REGISTRATION With your MD 809 Internet Media Tuner Plus you are able to create and organize your favorite lists of stations via an Internet Radio Portal website. This will allow you to have a full list of the stations you listen to regularly on one page instead of having to search each time. We recommend using the Frontier Silicon radio portal website for this function. Visit the portal website at www.wifiradiofrontier.com.
- 14 Even though the Internet radio portal contains thousands of stations, you may want to listen to stations not listed. You can add your own stations via the portal. These added stations are accessible from the tuner by touching the Internet Radio icon from the main menu > Directory icon > My Added Stations > [Station]. SETTING UP A MUSIC SERVER In order for the MD 809 to play music files from a computer, the computer must be set up to share files or media.
- 15 - MUSIC PLAYER MODE (network and USB) Music player mode plays audio files such as MP3s, AACs, WMAs or FLACs from a computer on the local network or from a USB Flash stick/hard drive. To enter Music player mode, touch the My Music icon on the main menu and the display shows the Select Music Source screen. Once in the Select Music Source screen, touch either Shared Media, USB Playback or My Playlist.
- 16 From Music, there are numerous ways of selecting tracks, including: o By Music, o By Genre, o By Artist, o All Music, o . Once you have found a track you want to play, touch the track title. A short press plays the track immediately and a long press changes the list to Edit mode with an add to presets icon allowing you to add the selected track or folder. You can also add entire albums to the playlist.
- 17 - DAB RADIO MODE (NOT AVAILABLE IN NORTH AMERICA) DAB radio mode receives DAB/DAB+ digital radio and displays information about the station, stream and track playing. To enter DAB radio mode, touch the DAB icon on the main menu screen until the display shows DAB Radio. When entering DAB radio mode, the last station listened to is automatically selected.
- 18 You can choose the order of the DAB station list to be either Alphanumeric, Ensemble or Valid. Ensemble lists groups of stations that are broadcast together on the same ensemble, for example BBC or South Wales local. Valid lists valid stations first, alphanumerically, then offair stations. To change station order, touch the DAB menu bar > Station order > then Alphanumeric, Ensemble or Valid.
- 19 - IMAGE/FUNCTIONS OF RF-20 REMOTE To use the remote control for your MD 809 you must first turn the unit ON with the main power switch on the front of the unit. Next put the remote into its proper mode to communicate with the Internet Media Tuner. Push the button next to MD 809. Your remote is now in the proper operating mode. 1. ON BUTTON- Turns the touch screen on 2.
- 20 - DIAGRAM OF MD 809 Internet Media Tuner 20
- 21 - USER INFRMATION Ownership of the intellectual property rights in the software in this product remains in the ownership of the party who provided it (or the respective licensor) and all of their respective rights are reserved. Its components and software are the intellectual property of Magnum Dynalab and Frontier Silicon and cannot be copied in any way. If you download a software upgrade to your Tuner, additional license terms may apply; these are available at http://www.frontier-silicon.
- 22 - TROUBLE SHOOTING PROBLEM No sound – Display on POSSIBLE CAUSE • Make sure unit is streaming • Unit source incorrect • Interconnect not properly installed • Preamp set to wrong source • Power amp off No Sound – Display dark • Power cord disconnected • Power off at source • Fuse blown FM Signal Distorted • Antenna not connected • Antenna placed in poor location Unit continues to try and load Clock appears in right hand corner • Weak Wi-Fi signal Unit will not stream on shared media • Compute
- 23 will come back on in the Internet mode 23
- 24 - DIGITAL INPUT /OUTPUT CONNECTING TO AN EXTERNAL DAC ( digital to analog device) Using a good quality digital cable connect from the digital outputs on the back of the MD unit either ( RCA or optical ) to the DAC CONNECTING TO ANOTHER DIGITAL SOURCE; Connect a digital cable from you digital source to the digital connector on the back of the MD 809 T , move the switch on the back of the unit to digital. The digital signal will now be sent through the DAC inside the MD 809T .
- 25 - SAFETY SHEET IMPORTANT SAFETY INSTRUCTIONS 1. KEEP THESE INSTRUCTIONS 2. HEED ALL WARNINGS 3. FOLLOW ALL INSTRUCTIONS 4. DO NOT USE THIS APPARATUS IN WATER 5. CLEAN ONLY WITH DRY CLOTH 6. DO NOT BLOCK ANY VENTILATION OPENINGS, INSTALL IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS. 7. DO NOT INSTALL NEAR ANY HEAT SOURCES SUCH AS RADIATORS, HEAT REGISTERS, STOVES, OR OTHER APPARATUS (INCLUDING AMPLIFIERS) THAT PRODUCE HEAT. 8. DO NOT DEFEAT THE SAFETY PURPOSE OF THE GROUNDING TYPE PLUG.
- 26 - LIMITED WARRANTY Register your product at www.magnumdynalab.com Magnum Dynalab Ltd. herein referred to as the “manufacturer” guarantees this product to be free of defect in both material and workmanship and agrees to remedy any such defect or replace any defective component at no charge for a period of two years from date of sale to the first end user.
- 27 - SPECIFICATIONS MD 809 T AUDIO SPECIFICATIONS 1. audio frequency response ( +/- 1 dB) 15 Hz-200KHz 2. balanced audio output ( 600 ohms) 2.2 volts 3. line audio output 1.0 volt 4. power consumption (typ/max) 50w/100w 5. line power ( must be specified) 110/120/230/240 TUBE SPECIFICATIONS 1. tube position 1 & 2 - 6922 MagnumDynalab Reference Cryo Treated 2. tube position 3 & 4 - 6922 MagnumDynalab Reference Cryo Treated 3. filament current max-33o mA min 270 mA 4. anode current max -1.07 mA min 0.
