Appendix H - Factory Defaults
DynaPro Mini| PIN Encryption Device | Programmer’s Reference (Commands)
Page 101
Appendix H Factory Defaults
H.1 Terminal Factory Defaults
Table 3-97 - Terminal Factory Defaults
Tag Description
Tag
Configurable
Default Value (hex)
PSE Name
0xDFDF22
Compile Only
31 50 41 59 2E 53 59 53 2E 44 44 46 30 31
Number of Applications
0xDFDF21
Compile Only
0A
Transaction Currency
Code
0x5F2A
Acquirer
08 40
Transaction Currency
Exponent
0x5F36
Acquirer
02
Terminal Country Code
0x9F1A
Acquirer
08 40
IFD Serial Number
0xDFDF25
Manufacturing
XX XX XX XX XX XX XX XX (USIP
SN Binary)
Terminal ID
0x9F1C
Acquirer
31 31 32 32 33 33 34 34 (Configurable)
Terminal Capabilities
0x9F33
Manufacturing
ICS Config 1:E0 F8 C8, ICS Config 2:E0
B8 C8
Terminal Type
0x9F35
Manufacturing
ICS Config 1:22, ICS Config 2:22
Additional Terminal
Capabilities
0x9F40
Manufacturing
ICS Config 1:70 00 A0 B0 01, ICS Config
2:70 00 A0 B0 01
Random number for
random online
transaction selection
0xDFDF00
Device
8D
Revoked Certificate
Lists
0xDFDF01
Not supported
A0 00 00 00 03 96 FF FF FF A0 00 00 00
04 96 FF FF FF A0 00 00 00 05 96 FF FF
FF
Authorization Request
Tags (ARQC)
0xDFDF02
Acquirer
9F 03 9F 26 82 5A 5F 34 9F 36 9F 1A 95
9F 02 5F 2A 9A 9C 9F 37 9F 10 DF DF 53
F5 F4
Advice Tags
0xDFDF03
Not supported
5A
Financial Request Tags
(ARPC)
0xDFDF04
Not supported
91 71 72 9F 01 89 8A
Reversal Tags
0xDFDF05
Acquirer
82 9F 36 DF DF 25 9F 10 9F 5B 9F 33 9F
35 95 9F 01 5F 24 5A 5F 34 8A 9F 15 9F
16 9F 39 9F 1A 9F 1C 57 9F 02 5F 2A 9A
9F 21
Authorization Response
Tags
0xDFDF06
Acquirer
8A 91
