TS8 · TS6 THE PASSION PEOPLE www.magura.
Contents Diagrams Introduction Preface................................12 Legend................................12 Technical Specifications Specifications.....................13 Dimensions.........................13 English Safety Intended use.......................14 Basic safety instructions.....14 Installation Installing the fork................16 Fitting the front wheel.........17 Fitting the remote control lever (RCL²).........................18 Taking eLECT into operation.
Diagrams 1⅛" albert SL 1⅛"–1.5" tapered 1.5" Ø 28,6 mm Ø 28,6 mm Ø 38,1 mm Ø 30,0 mm Ø 39,8 mm Ø 39,8 mm TD DLO² DLO³ e-lect A B PM 7" / MAGURA M15 PM 6" / QR (9 mm) C 9 mm D Ø 15 mm 4 THE PASSION PEOPLE www.magura.
Diagrams A1 B1 2 V S A1 L English 1 H A2 B2 3 1 5
Diagrams B3 C1 2,5 mm 2 N·m (18 lbf·in) max. 25 mm max. D1 3 E1 7 4 2 2 1 1 T25 10 N·m (89 lbf·in) 6 8 T25 3 N·m (27 lbf·in) max. THE PASSION PEOPLE www.magura.
Diagrams E2 E3 9 English 5 6 10 2,5 mm 2 N·m (18 lbf·in) max. 9 OFF OPEN E4 2 T10 1 N·m (9 lbf·in) max. 4 2 E5 3 8 1 1 7 2 2 (1s –1s –1s –1s …) 3 h => 100 % (——) T25 3 N·m (27 lbf·in) max. 2,5 mm 0,5 N·m (5 lbf·in) max.
Diagrams E6 (——) 3× (0,5s) (——) F1 3× (0,5s) OFF OPEN 8 s min. 3 s min. F2 F3 1 8 THE PASSION PEOPLE www.magura.
Diagrams 20 F4 0 F5 A B English 4 2 3 5 sag ≈ 20–30 % G1 MIN G2 MAX ≈ 12–14 clics 9
Diagrams G3 G4 DLO² – ON DLO² – OFF 2 cm (——) 2× (0,5s) +1,5° +1,5° 0° 0° 2 cm −1,5° −1,5° 3s–5s H1 (——) 2× (0,5s/0,5s) H2 (——) 1× 10 1× (2s) 4× (0,25s) 1× (2s) 2× (0,5s) 4× (0,25s) 1× THE PASSION PEOPLE www.magura.
Diagrams 1 J1 J2 J3 K1 English 3 2 CR 2032 11
Introduction Introduction Preface Welcome to the PASSION PEOPLE, Congratulations on your purchase of the latest generation MAGURA suspension fork – developed in Germany. This owner's manual is an integral part of your MAGURA product and gives you details of the required tools, correct installation, safe use, maintenance and setup options. Please read this manual carefully before you install or use your MAGURA product.
LLSome of the features detailed are optional variants.. Your MAGURA suspension fork is equipped as designed by your dealer or the bicycle manufacturer. TS8 Type name 150 Specifications Variant 140 120 TS6 100 bar (psi) 140 120 100 80 10 (150) Oil Damping Pressure level control [TD] Applications Total weight max.3 150 Air Suspension Air pressure max.
Safety Safety Intended use Any use other than the intended use can lead to accidents that cause serious or fatal injury. MAGURA TS8 and TS6 suspension forks are designed and intended only –– for installation on standard, commercially available bicycles designed according to the dimension of the suspension fork – 26", 650B (27.5") or 29". –– for use with a front wheel that corresponds to the dimension of the suspension fork – 26", 650B (27.5") or 29".
Safety On the road Danger of accident due to component failure. your actions. –– Only ride your bicycle if you are in good physical condition and your bicycle and all of its components are in perfect working order. –– Before each ride, make sure that the quick release system on your wheels is fitted correctly and that your wheels will not work loose. –– Before each ride, make sure that the handlebar and stem are correctly fitted and will not twist.
Installation Installation Installing the suspension fork )) Make sure that the frame, headset, stem, and adjusting nut match the steerer on your suspension fork – see Technical Specifications, page 13. Shortening the steerer Suspension fork unusable due to over-shortened steerer. –– Measure carefully and check the calculated length before cutting.
Installation Fitting the front wheel … using traditional quick release skewer Danger of accident due to front wheel blocking because of faulty installation work. Danger of injury on sharp and/or hot disc brake rotor when removing the front wheel. –– Make sure that a minimum gap of at 2 mm exists between rotating –– Always mount the clamping lever on the front wheel quick release on the right-hand side. parts (hub, fastening screws on the brake disc, etc.) and the suspension fork.
Installation Fitting the remote control lever (RCL²) Fitting the RCL² Bowden cable LLYou will notice that DLO² is suitable for remote control because the blue dial is returned to its original position by a return spring if turned by hand. Blue dials that do not have a return spring do not support remote control with RCL²! However, retrofitting is possible at a MAGURA service centre.. DLO³ is not suitable for remote control! Danger of accident due to faulty installation work.
Installation Danger of accident due to improper accessories. There are 2 attachment options for the eLECT remote control [E5]: –– Standard clamp (1) – for fitting next to the brake lever. –– Direct fitting – exclusively – to brake levers of MAGURA MT Series and rim brakes of HS Series as of model year 2011. LLThe eLECT remote control (2) is generally mounted on the right – however, it can be mounted on the left side if required.
SetUp SetUp Before you go for your first ride with your new MAGURA suspension fork, take some time to adjust the suspension and damping to match your personal weight and style of riding. This is absolutely necessary to make best use of your suspension fork’s characteristics. LLNote that the specified air pressure values are for reference only. You should adjust them for your personal riding style, your seating position, the characteristics of the road, and the geometry of your bicycle.
SetUp Check the air pressure LLThe negative suspension stroke – or sag – is designates the distance by which your suspension fork drops if you apply your own bodyweight to it; this gives you some initial feedback as to whether the air pressure setting is in the right range. Suspension travel mm in 80 3.1 100 3.9 120 4.7 140 5.5 150 5.9 sag ≈ 20–30 % mm in 16–24 0.6–0.9 20–30 0.8–1.2 24–36 0.9–1.4 28–42 1.1–1.7 30–45 1.2–1.8 )) Make sure that DLO³ or DLO² is disabled (OPEN/OFF) [F1].
SetUp Adjusting the damping (compression damper) LLThe compression damping of all MAGURA suspension forks is factory set and cannot be changed. . However, with the compression lever of the DLO³, you can preset the compression damping on your MAGURA suspension to suit your own needs [G2]. )) OPEN – Suspension fork is fully activated. ÎÎ Sensitivity (compression behaviour) fully present. )) FIRM – Suspension fork is less active. ÎÎ This favours an aggressive riding style.
On the Road On the Road Before each ride Locking out the suspension fork – DLO² LLActivating Dynamic Lockout DLO² saves energy riding uphill. This sets Danger of accident due to component failure. –– Before each ride, make sure that the quick release system on your wheels is fitted correctly and that your wheels will not work loose. –– Before each ride, make sure that the handlebar and stem are correctly fitted and will not twist.
… with eLECT in manual mode LLThe eLECT remote control permits manual activation or deactivation (ON/OFF) of DLO².. The first time you press the button on the remote control, you exit automatic mode and change the current DLO² status – from activated to deactivated (ON–OFF) or vice versa (OFF–ON).. Each further press of the button switches between activating and deactivating DLO² (ON–OFF)..
Maintenance vated (OFF). )) Charge the rechargeable battery – see Charging the eLECT rechargeable battery, page 19. Regular LLHow frequently you need to maintain your MAGURA suspension fork depends on how often you use it, but also on weather influences.. Perform the following maintenance steps more frequently if you use your bicycle in extreme conditions (rain, dirt, high mileage, etc.).
Maintenance Rectifying eLECT faults Fault flashes 3× slowly (1 s). . Synchronising. ÎÎ LED ÎÎ LED flashes 4× very quickly (0.25 s). . When button pressed. ÎÎ eLECT unit is not working. Cause problem, . synchronisation failed. ÎÎ Connection ÎÎ Rechargeable battery capacity exhausted. Sleep mode. ÎÎ Rechargeable battery capacity exhausted. Sleep mode. ÎÎ Incorrect calibration. ÎÎ eLECT unit pointing in the wrong direction. eLECT remote control ÎÎ eLECT 1 2 3 ÎÎ LED flashes 4× very quickly (0.
Parts, components and assemblies subject to normal wear and tear are not covered under this warranty. The warranty can expire when use according to the terms is no longer applicable. To this appropriate use also belongs the conditions for operating, maintaining and servicing as prescribed in the manual. Like every other product, the fork also contains parts that wear out as time passes by. The life span of these parts depend on the type and frequency of use, as well on care and maintenance.
LLUnsere weltweiten Handelspartner und Service Center finden Sie unter www.magura.com LLCheck out our worldwide partners and service centers at www.magura.com Deutschland MAGURA Bike Parts . GmbH & Co. KG. Eckisstraße 6. D-72574 Bad Urach phone +49 71 25 96 94 6-0. fax +49 71 25 96 94 6-17 info@magura.de © MAGURA 2013 All rights reserved. Printed in Taiwan. 2 600 108 – 03-2013 Umschlag & Inhalt:. www.technische-redaktion.de LE SSION PEOP THE PAur a.com www.mag Asia MAGURA Asia Limited Co.. No.
