Microwave Oven Customer Assistance: 1-866-321-9509 EM720C2WT-PM
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open- door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper wi th the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged.
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic safety precautions, including the following: 8. Use this appliance only for its intended uses as described in this manual. Do not use corrosive chemicals or vapors 2. Read and follow the specific: "PRECAUin this appliance.
19. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. i) Do not overheat the liquid. ii) Stir the liquid both before and halfway through heating it.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. 2. Longer cord sets or extension cords are available and may be used if care is exercised in their use. 3. If a long cord sets or extension cord is used: i) The marked electrical rating of the cord set or extension marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.
Materials you can use in microwave oven Utensils Remarks Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls. Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Microwave-safe only.
SETTING UP YOUR OVEN Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray 1 Turntable ring assembly 1 Instruction Manual 1 F E D C A B A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window F) Door assembly G) Safety interlock system G Turntable Installation Hub (underside) Glass tray Turntable shaft a. Never place the glass tray upside down.
Countertop Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. Installation 1. Select a level surface that provides enough open space for the intake and/or outlet openings. 12 inches(30cm) 3.0 inches(7.5cm) OPEN 3.
OPERATION Control Panel and Features (1) (2) (3) (4) (7) (8) (5) (6) (9) (1) (2) (3) (4) (5) (6) (7) (8) (9) (11) Time Cook (10) Time Defrost Power Clock Auto Menus: Popcorn, Potato, Pizza, Frozen Vegetable, Beverage, Dinner Plate Number Buttons: 0-9(Express cook: 1-6) Weight Defrost Kitchen Timer Stop/Cancel: clears all previous setting pressed before cooking starts. During cooking: press once to stop oven; twice to stop and clear all entries. (10) Memory Function (11) Start/+30Sec.
OPERATION 1. POWER LEVEL 10 power levels are available. Level 10 9 8 7 6 5 4 3 2 1 Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10% Display PL10 PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1 2. CLOCK SETTING (1) Press "CLOCK", "00:00" will display. (2) Press the number keys and enter the current time. For example, the time is 12:10 , please press "1,2,1,0" in turn. (3) Press "CLOCK" to finish clock setting. ":" will flash and the clock will be lighted.
Example: to cook the food with 50% microwave power for 15 minutes. a. Press "TIME COOK" once. "00:00" displays. b. Press "1", "5", "0", "0" in order. c. Press "POWER" once, then press "5" to select 50% microwave power. d. Press "START/+30SEC." to start cooking. Note: 1) In the process of setting, if the "STOP/CANCEL" button is pressed, or if there is no operation within 1 minute, the oven will go back to the former setting automatically.
8. POPCORN a) Press "POPCORN" repeatedly until the number you wish appears in the display, "1.75", "3.0", "3.5" oz will display in order. For example, press "POPCORN" once, "1.75" appears. b) Press "START/+30 SEC." to cook, buzzer sounds once. Buzzer will sound five times when cooking is finished and then turn back to waiting state. Important Information About Microwave Popcorn Feature : 1. When selecting 3.0 or 3.
11. BEVERAGE a) Press "BEVERAGE" repeatedly until the number you wish appears in the display, "1", "2", "3" cup will display in order. One cup is about 4.0 oz. For example, press "BEVERAGE" once, "1" appears. b) Press "START/+30 SEC." to cook, buzzer sounds once. When cooking is finished, buzzer sounds five times and then turns back to waiting state. 12. DINNER PLATE a) Press "DINNER PLATE" repeatedly until the number you wish appears in the display, "9.0", "12.0", "18.0" oz will display in order.
15. MULTI-STAGE COOKING At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is defrosting, then defrosting shall be placed as the first stage automatically. Note: Auto cooking cannot work in the multi-stage cooking. Example: if you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes.
Maintenance Troubleshooting If you experience issues with the microwave oven, use the chart below for possible solutions. I f the issue still persists, contact the customer service centre at the toll- free number provided for further assistance. TROUBLE POSSIBLE CAUSE Oven will not start a. Electrical cord for oven is not plugged in. b. Door is open. c. Wrong operation is set. a. Plug into the outlet. b. Close the door and try again. c. Check instructions. Arcing or sparking a.
ONE YEAR LIMITED WARRANTY This product carries a warranty that it will be free from defects in material and workmanship for a period of one year from the date of purchase. This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep your original sales receipt.
