User manual

06 A WELCOME, LET’S GET STARTED
PRINTING
Print Technology: Fused Filament Fabrication
Build Volume: 11.2 L x 6.0 W x 6.1 H in
[28.5 x 15.3 x 15.5 cm]
High 100 microns [0.0039 in]
Medium 270 microns [0.0106 in]
Low 340 microns [0.0133 in]
Positioning Precision: XY: 11 microns [0.0004 in];
Z: 2.5 microns [0.0001 in]
Filament Diameter: 1.75 mm [0.069 in]
Nozzle Diameter: 0.4 mm [0.015 in]
SOFTWARE
Soware Bundle: MakerBot MakerWare
™
File Types: .stl, .obj, .thing
Supports: Windows [XP/7],
Mac OS X [10.6/ 10.7/10.8],
Linux [Ubuntu 12.04+]
PHYSICAL DIMENSIONS
Without Spool: 19.1 x 12.8 x 14.7 in [49 x 32 x 38 cm]
With Spool: 19.1 x 16.5 x 14.7 in [49 x 42 x 38 cm]
Shipping Box: 23 x 21.5 x 17 in [59 x 55 x 43 cm]
Weight: 25.4 lbs [11.5 kg]
Shipping Weight: 44.55 lbs [20.2 kg]
TEMPERATURE
Ambient Operating 15° – 32° C [60° – 90° F]
Temperature:
Storage Temperature: 0° – 32° C [32° – 90° F]
ELECTRICAL
AC Input: 100 – 240 V,
~
2 amps, 50 – 60 Hz
Power Requirements: 24 V DC @ 6.25 amps
Connectivity: USB, SD card [FAT 16, max. 2GB]
MECHANICAL
Chassis: Powder-coated steel
Body: PVC Panels
Build Platform: Acrylic
XYZ Bearings: Wear-resistant,
oil-infused bronze
Stepper Motors: 1.8° step angle with
1/16 micro-stepping
SPECIFICATIONS
Layer Resolution
Settings:
