ENGLISH INSTRUCTION MANUAL Angle Grinder 9564PC 9564PCV 9565PC 9565PCV 9566PC 9566PCV 008369 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ENGLISH SPECIFICATIONS Depressed center wheel diameter Spindle thread 115 mm M14 9564PC - 9564PCV - 125 mm M14 9565PC - 9565PCV - - 9566PC - 9566PCV No load speed (no) / Rated speed (n) 150 mm M14 11,500 10,000 2,800 - 11,500 4,000 - 10,000 Overall length 307 mm 307 mm 307 mm 307 mm Net weight 1.9 kg 1.9 kg 1.9 kg 1.9 kg Safety class /II • Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
ENH101-8 conditions. Water entering a power tool will increase the risk of electric shock. 7. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. 8. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. 9.
rate for which it was designed. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. 19. Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. 20.
11. 12. 13. 14. 15. 16. 17. 18. resist kickback forces. Always use auxiliary handle, if provided, for maximum control over kickback or torque reaction during start-up. The operator can control torque reactions or kickback forces, if proper precautions are taken. b) Never place your hand near the rotating accessory. Accessory may kickback over your hand. c) Do not position your body in the area where power tool will move if kickback occurs.
21. 22. 23. 24. or binding of the wheel in the cut and the possibility of kickback or wheel breakage. b) Do not position your body in line with and behind the rotating wheel. When the wheel, at the point of operation, is moving away from your body, the possible kickback may propel the spinning wheel and the power tool directly at you. c) When wheel is binding or when interrupting a cut for any reason, switch off the power tool and hold the power tool motionless until the wheel comes to a complete stop.
Speed adjusting dial WARNING: MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. 1 1. Speed adjusting dial SAVE THESE INSTRUCTIONS. FUNCTIONAL DESCRIPTION 008372 • CAUTION: Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. The rotating speed can be changed by turning the speed adjusting dial to a given number setting from 1 to 5.
For tool with clamp lever type wheel guard returns to admissible levels, the tool will operate as normal. 1 Soft start feature 3 Soft start because of suppressed starting shock. • 4 ASSEMBLY • CAUTION: Always be sure that the tool is switched off and unplugged before carrying out any work on the tool. 1. Wheel guard 2. Bearing box 3. Screw 4. Lever 2 008375 1. Screw Installing side grip (handle) 1 008376 008373 Pull the lever in the direction of the arrow after loosening the screw.
1 1. Lock nut wrench 2. Shaft lock • CAUTION: After operation, always switch off the tool and wait until the wheel has come to a complete stop before putting the tool down. Grinding and sanding operation A 2 B 008378 Installing or removing diamond wheel (accessory) • 15 CAUTION: Make sure that the arrow on the tool should point in the same direction as the arrow on the diamond wheel. 1 2 3 008379 ALWAYS hold the tool firmly with one hand on housing and the other on the side handle.
1. Exhaust vent 2. Inhalation vent 1 2 008381 The tool and its air vents have to be kept clean. Regularly clean the tool's air vents or whenever the vents start to become obstructed. To maintain product SAFETY and RELIABILITY, repairs, carbon brush inspection and replacement, any other maintenance or adjustment should be performed by Makita Authorized Service Centers, always using Makita replacement parts.
Makita Corporation Anjo, Aichi, Japan 884754A221 12
