Specifications

132
Free delivery on orders over £50 (UK mainland only) Orders UNDER £50 P&P £4.95
3
• Three stage turbine power unit
• Most nishes can be sprayed
• 25’ (7.6m) 3/4” hose supplied
• Supplied with Fuji’s comprehensive guide
• Choice of Xpc spray guns with Adjustable Spray Pattern control
• 1.4mm aircap as standard, covers the majority of applications
• Other aircaps available for special applications
Fuji Mini-Mite
3 or 4 Turbine Unit
with T70 Spray Gun
• Quiet running three stage turbine power unit
• 7.6m(25’) of 3/4” bore hose
• Low delivery pressure gives good nish with reduced
overspray
• Most nishes can be sprayed including inks, stains, lacquers,
varnishes, enamels and acrylics
• Included is Fuji’s very comprehensive guide covering all
aspects of HVLP spraying in great detail
Fuji Q3 or Q4 Gold Pro Turbine
Unit with T70 Spray Gun
Professional
Spray Equipment
If you are considering setting up a spraying system in your work-
shop a High Volume Low Pressure (HVLP) has to be the way to go.
Completely portable, they take up next to no space and need very
little setting up compared to a compressor driven system. Also, the
cost layout is relatively low to achieve professional results, with
much less time being spent between jobs. We have sold the FUJI
HVLP spray systems for many years; they are consistently rated as
the very best systems around thanks to continuous development in
turbine and spray gun technology.
There are 4 FUJI Turbines to choose from, but don’t worry, it’s not a complex choice. The
range has two designs in two turbine types. The Mini-Mite range is the basic version whilst
the Q Gold models have the patented Fuji noise reduction system, reducing noise by 50%,
down to an almost conversational level. The numbers 3 or 4 refer to the number of turbine
fans, four fans giving a higher pressure (9psi versus 6.5psi) to cope with higher viscosity
finishes such as latex house paints or larger jobs that need a faster application of the finish,
re-spraying a car for example. For normal water or oil based finishes to be applied to furni-
ture, cabinets or for small vehicle panel refinishing the three turbine models will be more
than adequate. All models feature an internal air dump valve to allow the non-bleed spray
gun feature, twin air filters, a sturdy top grab handle and high quality alloy and brass air
fittings. A 7.6 meter hose is supplied, with quick-connect fittings and an air volume control
valve. The bottom line is, you can expect a consistent and impressive performance from any
model of FUJI HVLP spray system, we don’t think you can really ask for more.
Model
Rating
Power
Noise Level
Nozzle
Hose Length
Overall L x W x H
Weight
Pro-Spray 1500-3s
Industrial
1.5kW
78dB(A)
1.3mm
6m
425 x 365 x 415mm
14kg
Model
Rating
Power
Noise Level
Nozzle
Hose Length
Overall L x W x H
Weight
Mini-Mite T70
Trade
1.5kW
73dB(A) @ 6 meters
1.4mm (Std)
7.6m
430 x 370 x 430mm
12kg
Mini-Mite 3 Turbine Unit &
T70 Suction Feed Spray Gun £469.96 £391.63 717477
Mini-Mite 3 Turbine Unit &
T70 Gravity Feed Spray Gun £469.96 £391.63 717478
Mini-Mite 4 Turbine Unit &
T70 Suction Feed Spray Gun £579.96 £483.30 717479
Mini-Mite 4 Turbine Unit &
T70 Gravity Feed Spray Gun £579.96 £483.30 717480
Inc.vat Ex.vat Code
Q3 Gold Pro Turbine Unit &
T70 Suction Feed Spray Gun £629.95 £524.96 717481
Q3 Gold Pro Turbine Unit &
T70 Gravity Feed Spray Gun £629.95 £524.96 717482
Q4 Gold Pro Turbine Unit &
T70 Suction Feed Spray Gun £759.96 £633.30 717483
Q4 Gold Pro Turbine Unit &
T70 Gravity Feed Spray Gun £759.96 £633.30 717484
Inc.vat Ex.vat Code
