Demolition Hammer MODEL HM0810B 002874 DOUBLE INSULATION I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. w w w. m a k i t a t o o l s.
SPECIFICATIONS Model HM0810B Blows per minute 2,900 Overall length 433 mm (17-1/32”) Net weight 5.3 kg (11.7 lbs) • Manufacturer reserves the right to change specifications without notice. • Specifications may differ from country to country. GENERAL SAFETY RULES USA002-2 (For All Tools) WARNING: Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work Area 1.
6. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. 7. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp edges or moving parts. Replace damaged cords immediately. Damaged cords increase the risk of electric shock. 8. When operating a power tool outside, use an outdoor extension cord marked “W-A” or “W”.
24. When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section of this manual. Use of unauthorized parts or failure to follow Maintenance instructions may create a risk of electric shock or injury. USE PROPER EXTENSION CORD: Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw.
tion. Without proper warm-up, hammering operation is difficult. 7. Always be sure you have a firm footing. Be sure no one is below when using the tool in high locations. 8. Hold the tool firmly with both hands. 9. Keep hands away from moving parts. 10. Do not leave the tool running. Operate the tool only when hand-held. 11. Do not point the tool at any one in the area when operating. The bit could fly out and injure someone seriously. 12.
FUNCTIONAL DESCRIPTION • 002887 2 CAUTION: Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Switch action 1 • • 1. Lock button 2. Switch trigger CAUTION: Before plugging in the tool, always check to see that the switch trigger actuates properly and returns to the “OFF” position when released. Switch can be locked in “ON” position for ease of operator comfort during extended use.
002914 Installing or removing the bit 1 Clean the bit shank before installing the bit. 2 Press in the tool retainer and turn it until the red dots on the tool retainer and the tool holder are aligned. Release the tool retainer. 1. Red dot (Tool holder) 2. Red dot (Tool retainer) 002915 1 Insert the bit into the tool holder as far as it will go. Press in the tool retainer and turn it a full 180 degrees. Then release it to secure the bit.
002949 Use a hex wrench to remove the rear cover. 002950 Use a screwdriver to remove the brush holder caps. Take out the worn carbon brushes, insert the new ones and secure the brush holder caps. 002963 Lubrication 1 2 1. Hex wrench 2. Rear cover 1 2 1. Screwdriver 2. Brush holder cap 1 This tool requires no hourly or daily lubrication because it has a grease-packed lubrication system. It should be relubricated after every 6 months of operation.
• CAUTION: Do not tighten the crank cap excessively. It is made of resin and is subject to breakage. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. ACCESSORIES • CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual.
Memo 10
Memo 11
Memo 12
Cut First-Class Postage Required Post Office will not deliver without proper postage. Makita U.S.A., Inc.
MAIL THIS PORTION Your answers to the following questions are appreciated. 1. This product was purchased from: Home Center 3. How did you learn about this product: Magazine Radio Hardware/Lumber Store From Dealer Exhibition Tool Distributor Newspaper From Friend Industrial Supply Store Display Previous Usage Construction Supply Catalog Other ( Other ( ) 2. Use of the product is intended for: ) 4.
FACTORY SERVICE CENTERS 1-800-4-MAKITA RETAIN THIS PORTION FOR YOUR RECORDS ALABAMA 2365 Pelham Parkway Pelham, AL 35124 (205) 620-1791 COLORADO 11839 E. 51st Ave. Denver, CO 80239-2709 (303) 371-2850 KENTUCKY 1215 S. Hurstbourne Parkway Louisville, KY 40222 (502) 326-3740 NEW MEXICO 5805 Menaul Blvd. NE Albuquerque, NM 87110 (505) 881-4619 PUERTO RICO 200 Guayama St. Hato Rey, PR 00917 (787) 250-8776 ARIZONA 3707 E. Broadway Rd., Ste. 6 Phoenix, AZ 85040 (602) 437-2850 CONNECTICUT 508 Spring St.
WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, • crystalline silica from bricks and cement and other masonry products, and • arsenic and chromium from chemically-treated lumber. Your risk from these exposures varies, depending on how often you do this type of work.
