Basic version Advanced version AV Surround Receiver Owner’s Manual DVD Information SR7007
n SAFETY PRECAUTIONS RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
n CAUTIONS ON INSTALLATION n NOTES ON USE z z z Wall zz For proper heat dispersal, do not install this unit in a confined space, such as a bookcase or similar enclosure. • More than 12 in. (0.3 m) is recommended. • Do not place any other equipment on this unit. Information DVD z Advanced version • Avoid high temperatures. Allow for sufficient heat dispersion when installed in a rack. • Handle the power cord carefully. Hold the plug when unplugging the cord.
Thank you for purchasing this marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference.
Accessories Features y u Q0 o Q1 Digital video processor up-scales analog video signals (SD resolution) to 4K This unit is equipped with the 4K video upscaling function, which allows for outputting analogue or SD (standard video quality) video to HDMI at 4K (3840 × 2160 pixels). This enables the unit and a TV connected with a single HDMI cable and any video source to be reproduced precisely with HD level of quality.
Features This unit is equipped with an easy to see “Graphical User Interface” that uses menu displays and levels. The use of level displays increases operability of the this unit. HDMI connectors enable connection to various digital AV devices (input: 7, output: 3) This unit is equipped with Audyssey DSX® processor. By connecting front height speakers to this unit and playing back through Audyssey DSX®, you can experience a more powerful playback expression in the height audio range.
Basic version Here, we explain the connections and basic operation methods for this unit.
Basic version Connections Important information Make connections before using this unit. To create a home theater that can play back higher quality video and audio by fully utilizing the capabilities of this unit and your video devices, connect this unit to each of your video devices with HDMI cables.
Important information Make Settings as Necessary This unit is equipped with three types of video input connectors (HDMI, Component video and video) and three types of video output connectors (HDMI, Component video and video). This function automatically converts various formats of video signals input to this unit into the formats used to output the video signals from this unit to a monitor.
Important information NOTE This unit Video device Input (IN) Output HDMI-compatible TV Output (ZONE2 MONITOR OUT) HDMI signal HDMI connector HDMI connector Input HDMI connector HDMI connector HDMI-incompatible TV Component video signal Component video signal Component video connectors Component video connectors Video signal Video connector Video signal Video connector DVD Component video connectors Video connector Video connector 7 Information Component video connectors Advanced v
Connecting an HDMI-compatible device nn Before connecting this unit to TV via HDMI connections (vpage 9) nn Connecting this unit to a TV via HDMI connections (vpage 10) Basic version You can connect up to ten HDMI-compatible devices (7-inputs/3-outputs) to the unit. When a TV is connected to the HDMI ZONE2 OUT connector, you can play back a video or audio from the device connected to the HDMI 1 – 6 IN connector in ZONE2 (vpage 104).
Connecting an HDMI-compatible device nnAbout ARC (Audio Return Channel) function This function plays TV audio on this unit by sending the TV audio signal to this unit via HDMI cable. If a TV without the ARC function is connected via HDMI connections, video signals of the playback device connected to this unit are transmitted to the TV, but this unit can not play back the audio from the TV. If you want to enjoy surround audio for TV program, a separate audio cable connection is required.
Connecting an HDMI-compatible device • Video signals are not output if the input video signals do not match the monitor’s resolution. In this case, switch the Blu-ray Disc/DVD player’s resolution to a resolution with which the monitor is compatible. • When this unit and monitor are connected with an HDMI cable, if the monitor is not compatible with HDMI audio signal playback, only the video signals are output to the monitor. Make audio connections (vpage 14 “Connecting a TV”).
Connecting an HDMI-compatible device Connecting this unit to video devices via HDMI connections Cables used for connections Audio and video cable (sold separately) Basic version Digital camcorder (Primary) HDMI OUT HDMI cable • This interface allows transfer of digital video signals and digital audio signals over a single HDMI cable.
Connecting an HDMI-compatible device nnDeep Color (vpage 171) When a device supporting Deep Color is connected, use a cable compatible with “High Speed HDMI cable” or “High Speed HDMI cable with Ethernet”. This unit supports the following HDMI functions: nnAbout 3D function NOTE • When playing back 3D video, refer to the instructions provided in the manual of your playback device together with this manual.
Connecting an HDMI-incompatible device Connection methods for various devices vpage 15 vpage 16 vpage 17 Changing the source assigned to connectors Video cable (sold separately) This unit can change the source that is assigned to the HDMI IN, DIGITAL AUDIO IN and COMPONENT VIDEO IN connectors.
Connecting an HDMI-incompatible device Input connector setting When making the following connection, you must change the input connector settings. • This section describes how to connect when your TV does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8).
Connecting an HDMI-incompatible device Satellite tuner/Cable TV This section describes how to connect when your satellite tuner or cable TV does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8).
Connecting an HDMI-incompatible device Input connector setting When making the following connection, you must change the input connector settings. This section describes how to connect when your DVD player does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8). a DIGITAL AUDIO OPTICAL connector When connecting to connectors marked as 1, change “TV AUDIO” to “DVD”. nnAudio connection For how to change, see “Input Assign” (vpage 126).
Connecting an HDMI-incompatible device Blu-ray Disc player AUDIO This section describes how to connect when your Blu-ray disc player does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8). nnAudio connection The following methods are available for connecting to this unit. Use either of the methods to make a connection. The numbers prefixed with connectors indicate the recommendation order.
Connecting an HDMI-incompatible device GFront panelH Digital camcorder This section describes how to connect when your digital camcorder does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8). nnAudio connection The following methods are available for connecting to this unit. Use either of the methods to make a connection. The numbers prefixed with connectors indicate the recommendation order.
Connecting an HDMI-incompatible device Input connector setting When making the following connection, you must change the input connector settings. This section describes how to connect when your media player does not support HDMI connections. For instructions on HDMI connections, see “Connecting an HDMI-compatible device” (vpage 8). a DIGITAL AUDIO COAXIAL connector When connecting to connectors marked as 1, change “CBL/SAT” to “MEDIA PLAYER”.
Connecting an HDMI-incompatible device Connecting an iPod or USB memory device to the iPod/USB port • You can enjoy music stored on an iPod or USB memory device. • For operating instructions see “Playing an iPod” (vpage 39) or “Playing a USB memory device” (vpage 42). Basic version Supported iPod models • iPod classic Cables used for connections To connect an iPod to this unit, use the USB cable supplied with the iPod.
Connecting an HDMI-incompatible device CD player AUDIO You can enjoy CD sound. COAXIAL OUT AUDIO OUT L R nnAudio connection The following methods are available for connecting to this unit. Use either of the methods to make a connection. The numbers prefixed with connectors indicate the recommendation order. The smaller the number is, the higher playback quality is achieved.
Connecting an HDMI-incompatible device Turntable (MM cartridge) You can enjoy playing records. nnAudio connection The following methods are available for connecting to this unit. Basic version Connecting a record player a AUDIO IN (PHONO) connector This makes an analog audio connection. AUDIO OUT GND L NOTE The SIGNAL GND terminal of this unit is not a safety ground connection. Connect it to reduce noise when noise is excessive.
Connecting an HDMI-incompatible device Direction of broadcasting station • By connecting a HD Radio antenna to this unit, you can receive HD Radio programs. • HD Radio broadcasting currentry is available in the United States and select other countries. • After connecting the antenna and receiving a broadcast signal (vpage 46 “Listening to HD Radio stations”), fix the antenna with tape in a position where the noise level becomes minimal.
Connecting an HDMI-incompatible device • You can connect a wireless receiver (RX101, sold separately) to play back music on your Bluetooth device with this unit. • To do this, switch the input source to “M-XPort” (vpage 36 “Selecting the input source”). • This unit supports the A2DP standard of the Bluetooth profile. • See also the manuals for your wireless receiver and Bluetooth device.
Connecting a device with a multi-channel output connector Devices with a multi-channel output connector (Blu-ray Disc player, DVD player, External decoder etc.) AUDIO SUBWOOFER FRONT L R CENTER SURROUND L R SURROUND BACK L Basic version • You can connect this unit to an external device fitted with multi-channel sound audio output connectors to enjoy music and video. • To play analog signals input from 7.1CH IN connectors, set “Input Mode” (vpage 128) to “7.1CH IN”.
Connecting an external power amplifier • When using just one surround back speaker, connect it to the left channel (L) terminal. • Use the volume control on the subwoofer to control subwoofer volume. • If the subwoofer volume sounds low, use the volume control provided on the subwoofer to adjust the volume.
Connecting to a home network (LAN) Required system • Playback of network audio such as the Internet radio and music servers • Playback of music from online services • AirPlay • Operations on this unit via the network nnBroadband internet connection nnModem Device that connects to the broadband circuit and conducts communications on the Internet. A type that is integrated with a router is also available. nnRouter Network settings are necessary.
Connecting the power cord Basic version After completing all the connections, insert the power plug into the power outlet. Advanced version To household power outlet (AC 120 V, 60 Hz) Information Power cord (supplied) NOTE • Do not plug in the power cord until all connections have been completed. • Do not bundle power cords together with connection cables. Doing so can result in humming or noise.
Here, we explain “Audyssey® Setup”, which allows you to automatically make the optimal settings for your speakers, and “Network”, which allows you to connect this unit to a home network (LAN). This unit lets you play via your home network (LAN) music files stored on a computer and music content such as that from Internet radio.
Set up speakers (Audyssey® Setup) Prepare the included setup microphone Mount the setup microphone on a tripod or stand and place it in the main listening position. When placing the setup microphone, adjust the height of the sound receptor to the level of the listener’s ear. Sound receptor Set up the subwoofer If using a subwoofer capable of the following adjustments, set up the subwoofer as shown below. For details, see your subwoofer’s manual.
Set up speakers (Audyssey® Setup) 5 • This step automatically checks the speaker configuration and speaker size, and calculates the channel level, distance, and crossover frequency. It also corrects distortion in the listening area. Select “Start” and then press ENTER. When measuring begins, a test tone is output from each speaker. Audyssey Setup Connect the calibration microphone to the SETUP MIC input on the front the AV receiver. Next • Measurement requires several minutes.
Set up speakers (Audyssey® Setup) • In this step, you will perform measurements at multiple positions (two to eight positions) other than the main listening position. • Just one position can be measured but measuring multiple positions increases the accuracy of the correction of acoustic distortion within the listening area. When measurement of position 8 is completed, “Measurements finished.” message is displayed. Audyssey Setup a 12 Select “Calculation” and then press ENTER.
Set up speakers (Audyssey® Setup) Store ui to select the item you 13 Use want to check, and then press ENTER. Finish 14 Select “Store” and then press ENTER. Save the measurement results. Audyssey Setup Check processing results. To proceed, press “Store”. Audyssey Setup You can set Dynamic Volume function, which automatically adjusts volume level for all content. Speaker Config. Distances Levels Crossovers Audyssey Setup Check processing results. To proceed, press “Store”.
Set up speakers (Audyssey® Setup) NOTE • An error message is displayed if Audyssey® Setup could not be completed due to speaker placement, the measurement environment, etc. If an error message is displayed, check the relevant items and perform the necessary measures. Then perform Audyssey® Setup again. • If the result still differs from the actual connection status after remeasurement or the error message still appears, it is possible that the speakers are not connected properly.
Set up speakers (Audyssey® Setup) This function enables you to check the measurement results and equalizer characteristics after Audyssey® Setup. This unit can be connected to a home network (LAN) to listen to Internet radio or play back music files and still image (JPEG) files stored on a computer. 1 Use ui to select “Parameter Check” and then press ENTER.
Basic version Playback (Basic operation) Important information Setup (vpage 29) nn Playing a Blu-ray Disc player/DVD player (vpage 37) nn Playing Super Audio CD (vpage 37) nn Playing a CD player (vpage 38) nn Playing an iPod (vpage 39) nn Playing a USB memory device (vpage 42) nn Listening to HD Radio stations (vpage 45) Selecting a listening mode (Sound Mode) (vpage 75) NOTE Also refer to the operating instructions of the connected devices when playing them.
Important information Use VOLUME df to adjust the volume. • The volume display method varies depending on the “Scale” setting (vpage 116). GAdjustable rangeH 0.0 The following describes the procedure for playing Blu-ray Disc player/ DVD player. 1 Prepare for playback. q Turn on the power of the TV, subwoofer and player. this unit. nn When the “Scale” setting (vpage 116) is “–79.5dB – 18.0dB” GAdjustable rangeH – – –.– –79.5dB – 18.
Playing a CD player Basic version The following describes the procedure for playing CD player. 1 Prepare for playback. q Turn on the power of the subwoofer and player. w Load the disc in the player. Advanced version Press ON/STANDBY X to turn on 2 power to the unit. Press CD to switch the input 3 source to “CD”. 4 Play the CD player.
Playing an iPod Listening to music on an iPod The iPod display modes include “Direct Mode” and “Remote Mode”. By default, “Direct Mode”, where you directly operate iPod itself while seeing the iPod screen, is set. To change to “Remote Mode”, where you perform operations while having the iPod information displayed on the TV screen, see “Setting “Remote Mode” (Operation Mode)” (vpage 40). iPod to the iPod/USB port (vpage 20). 2 Press iPod/USB to switch the 3 input source to “iPod/USB”.
Playing an iPod In this mode, various lists and screens during playback on iPod are displayed on the TV screen. This section describes the steps up to playing back tracks on iPod in “Remote Mode”. The option menu screen is displayed. The “Operation Mode” screen is displayed. Display mode Direct Mode Remote Mode P P Playable Music file files Video file Active buttons z Remote control unit (This unit) P iPod P P zzOnly the sound is played. Option Operation Mode 5 6 Press ENTER, p or 1.
Playing an iPod nnPerforming random playback (Random) 1 Press OPTION while in Remote Mode. 2 Use ui to select “Repeat”, then press ENTER. 1 2 Use ui to select “Random”, then press ENTER. The option menu screen is displayed. iPod Press OPTION while in Remote Mode. The option menu screen is displayed. Title Artist Album 100% 00:06 Pause Back 3 Repeat Now Playing Random Operation Mode Previous Next OPTION Option 100% Pause Back Use o p to select repeat playback mode.
Playing a USB memory device Important information • Only USB memory devices conforming to mass storage class and MTP (Media Transfer Protocol) standards can be played on this unit. • This unit is compatible with USB memory devices in “FAT16” or “FAT32” format. • This unit is compatible with MP3 files conforming to “MPEG-1 Audio Layer-3” standards. • File types that this unit can play back and specifications are shown below.
Playing a USB memory device the USB memory device to the iPod/USB 1 Connect port (vpage 20). iPod/USB to switch the 2 Press input source to “iPod/USB”. Make this setting at “M-DAX” (vpage 115) in the menu. You can use the “M-DAX” function to restore to a state close to the audio before compression while correcting the bass feel to enjoy a richer playback experience. The default setting is “Off”. nnGoing back to the previous screen Press o or BACK.
Playing a USB memory device Operation buttons CH/PAGE df INFO OPTION Function Page search Display of information such as the source name, volume, and sound mode name Text Search / Repeat playback / Random playback / Picture View / Slideshow Cursor operation / Auto search (cue, ui) ENTER (Press and release) ENTER (Press and hold) BACK SETUP 3 1 2 8 9 Advanced version uio p Basic version nnUSB memory device operation buttons Enter Stop DVD Information Return Setup Pause Playback / Pause Stop Auto s
Listening to HD Radio stations Important information How to tune in nnUsing the HD Radio™ receiver The modes for receiving FM broadcasts consists of “Auto” mode that automatically searches available broadcast stations and “Manual” mode that lets you tune in using buttons to change the frequency. The default setting is “Auto”. You can also use “Direct Tune” to tune in by entering the frequency directly. In “Auto” mode, you cannot tune in to radio stations if the reception is not good.
Listening to HD Radio stations 1 Press TUNER to switch the input source to “HD Radio”. 4 Use o p to select “FM” or “AM”, then press ENTER. GTV ScreenH HD Radio GTV ScreenH STEREO HD-AUTO HD Radio FM FM 87.50MHz Now Playing TUNE+/- Tune Preset CH / OPTION Option The option menu screen is displayed. The Band screen is displayed. GTV ScreenH HD Radio Option • FM – FM When listening to an FM broadcast. AM When listening to an AM broadcast.
Listening to HD Radio stations You can change the mode for tuning into FM/AM broadcasts. GTV ScreenH HD Radio STEREO HD-AUTO The option menu screen is displayed. GTV ScreenH HD Radio TUNE+/- STEREO HD-AUTO Direct Tune Now Playing Tune Mode FM 87.50MHz Auto Preset Memory Preset Name Auto Preset Skip TUNE+/- Mode • Preset Memory CH 1 Tune CH / Preset OPTION Option *OPTION Tune Mode CH / Preset the tuning mode 1 Select (“HD-AUTO”, “AUTO” or “MANUAL”).
Listening to HD Radio stations You can enter the receiving frequency directly to tune in. The option menu screen is displayed. The direct tuner screen is displayed and “–” in the display flashes. source to The screen that lets you enter the frequency is displayed. GTV ScreenH HD Radio STEREO HD-AUTO Now Playing FM ---.-MHz DIRECT TUNE Input Enter GDisplay of this unitH GTV ScreenH HD Radio FM ---.
Listening to HD Radio stations nnTuning in to radio stations and presetting them automatically (Auto Preset Memory) 4 Press ENTER. The unit starts to tune in to radio stations automatically and preset them. GTV ScreenH Up to 56 stations can be preset. If “Auto Preset Memory” is performed after performing “Preset Memory”, the “Preset Memory” settings will be overwritten. The option menu screen is displayed.
Listening to HD Radio stations Your favorite broadcast stations can be preset so that you can tune them in easily. Up to 56 stations can be preset. • To preset other stations, repeat steps 1 to 4. Preset Memory 1 HD2 5 HD1 6 7 TUNE+/- 8 Tune Now Playing FM 87.90MHz FM 89.10MHz FM FM 87.50MHz 93.30MHz 41 – 48 FM 97.90MHz FM 98.10MHz FM 98.90MHz FM100.10MHz OPTION Preset Option HD Radio OPTION STEREO HD-AUTO Now Playing CH 1 Preset stored at CH 1 FM 87.
Listening to HD Radio stations You can set the name to the preset broadcast station or change it. Up to eight characters can be input. source to The screen that lets you edit the preset name is displayed. The screen that lets you edit the preset name is displayed. • Each time o p is pressed, the setting is changed as shown below.
Listening to HD Radio stations You can set in advance, the stations you do not want to be displayed when tuning in, by groups or by stations. The preset skip setting is useful when tuning in, because only your favorite stations are displayed. The option menu screen is displayed. The Preset Skip screen is displayed. GTV ScreenH stations you want to skip. • Each time o p is pressed, the setting is changed as shown below.
Listening to HD Radio stations nnCheck the HD Radio reception information 1 Press STATUS on the main unit while an HD Radio broadcast is being received. While the Preset Skip screen is displayed, use o p to select a group containing a broadcast station to cancel the skip for. The current reception information is shown on the display. nnTuner (HD Radio reception) operation buttons Operation buttons CH/PAGE df INFO ui to select a broadcast station to cancel the 2 Use skip for.
Listening to internet radio Internet radio refers to radio broadcasts distributed over the Internet. Internet radio stations from around the world can be received. Listening to internet radio Important information 1 Prepare for playback. GPlayable broadcast station typesH Supported file types Internet radio WMA (Windows Media Audio) P MP3 (MPEG-1 Audio Layer-3) P q Check the network environment, then turn on this unit’s power (vpage 27 “Connecting to a home network (LAN)”).
Listening to internet radio Make this setting at “M-DAX” (vpage 115) in the menu. You can use the “M-DAX” function to restore to a state close to the audio before compression while correcting the bass feel to enjoy a richer playback experience. The default setting is “Off”. nnSwitching the screen display Press STATUS on the main unit. The display switches between track title and radio station name etc. each time the button is pressed. Press o or BACK.
Listening to internet radio There are many Internet radio stations in the world, and this unit can tune into these stations. But finding the radio station you want to hear may be difficult, because there are too many stations. If this is the case, then please use vTuner, an Internet radio station search website specifically designed for this unit. You can use your PC to search Internet radio stations and add them as your favorites. This unit can play radio stations added to vTuner.
Playing back files stored on a PC and NAS Basic version This unit can play back music files and playlists (m3u, wpl) stored on a PC and on Network Attached Storage (NAS) that supports DLNA. Important information • The network audio playback function of this unit connects to the server using technologies shown below. • Windows Media Player Network Sharing Service • Windows Media DRM10 • File types that this unit can play back and specifications are shown below.
Playing back files stored on a PC and NAS Here, we apply the settings to share music files stored on a PC and NAS on the network. nnSharing media stored in PC If you are using a media server, be sure to apply this setting first. When using Windows Media Player 12 (Windows 7) NOTE Perform this procedure after changing the control panel display to “Category”.
Playing back files stored on a PC and NAS Use this procedure to play music files, image files or playlists. 1 Prepare for playback. 2 Press NETWORK. Use uio p to select “Media 3 Server”, then press ENTER. Make this setting at “M-DAX” (vpage 115) in the menu. You can use the “M-DAX” function to restore to a state close to the audio before compression while correcting the bass feel to enjoy a richer playback experience. The default setting is “Off”.
Playing back files stored on a PC and NAS nnMedia server operation buttons Operation buttons CH/PAGE df INFO nn Searching content with keywords (Text Search) (vpage 69) OPTION nn Performing random playback (Random) (vpage 70) uio p nn Add to favorites from the Option menu (Favorite Memory) (vpage 71) nn Playing back still images in sequential order (Slideshow) (vpage 72) DVD 60 Enter Stop Return Setup Pause Playback / Pause Stop Auto search (cue) Call up favorites Add to the favorites list Inform
Using online services nnAbout Flickr (vpage 62) nnAbout SiriusXM (vpage 67) Flickr is an online photograph sharing service that started in 2004. You can use the this unit to view photographs that have been made public by Flickr users. You do not need an account to use Flickr. To view photographs that you recorded yourself, you need an account in order to upload these photographs to the Flickr server. For details, see the Flickr homepage. http://www.flickr.
Using online services You can view photographs shared by particular users, or all of the photographs shared on Flickr. ui to select “Add Flickr Contact”, then press ui to select the file, and then press ENTER or 4 Use 8 Use ENTER or p. p. The selected file is displayed. Flickr nnViewing photographs shared by particular users 1 [1/2] Press o or BACK. All Content Prepare for playback. q Check the network environment, then turn on this unit’s power (vpage 27 “Connecting to a home network (LAN)”).
Using online services to select “All Content”, then press ENTER 1 orUsepui . Flickr nnFlickr operation buttons Operation buttons CH/PAGE df INFO [1/2] OPTION Add Flickr Contact All Content uio p 2 Option Use ui to select the folder, and then press ENTER or p. Interestingness Displays photographs that are popular from the number of user comments or number of times they are added as favorites. Search by text Displays the most recently added photographs. Search for photographs by keyword.
Using online services 1 Prepare for playback. If you have a Pandora account, use ui to select “I 4 have 5 Input “Email address” and “Password”. a Pandora account”, then press ENTER or p. q Check the network environment, then turn on this unit’s power (vpage 27 “Connecting to a home network (LAN)”). w If settings are required, make the “Settings” (vpage 137). e Complete step 4 and obtain a Pandora account. • If you already have a Pandora account, you do not need to obtain a new account.
Using online services You can create up to 100 radio stations. 1 Use ui to select “New Station”, then press ENTER or p. 3 Use ui to select “Search by Artist” or “Search by Track”, then press ENTER. You can search and display a list by track or artist. New Station My Station [1/3] Track or Artist A B C D E D&M1 Radio $ % & L M F G H I J K * + , ; < = > a/A BACK Exit BACK Sign out 2 Input a track or artist name, then press OK .
Using online services You can personalize your stations by providing feedback. Press p while a track is playing. The Pandora menu screen is displayed. Menu nnPandora operation buttons NOTE • You can Skip up to 6 Tracks that are being played back within 1 hour. • You can create up to 100 Stations (radio stations). nnSign out Disassociate this unit from your Pandora account. [1/8] the Pandora top menu is 1 While displayed, press BACK.
Using online services Over 120 channels of the SiriusXM programming you love, including commercial-free music plus sports, talk, news and entertainment. Listen anywhere on your computer or smartphone. 1 Prepare for playback. Network Favorites Please set your SiriusXM username and password. You can go to www.siriusxm.com to sign up for an account. Or,select “Start Trial” below to start the one-time free trial. Sign in Start Trial BACK Cancel Enter 5 Input the “Username” and “Password”.
Using online services Disassociate this unit from your SiriusXM account. 1 When the popup menu appears, use o p to select 2 “Yes”, then press ENTER. While the SiriusXM top menu is displayed, press BACK.
Convenient functions nn Searching content with keywords (Text Search) (vpage 69) USB Internet Radio 1 2 Use ui to select “Text Search”, then press ENTER. While content is playing, press OPTION. The keyboard input screen is displayed. USB [1/9] Option D&M1 D&M2 nn Favorites function (vpage 71) D&M3 Music1 Playback starts. Text Search Repeat Random Slideshow Music2 nn Playing back music and a favorite picture at the same time (Picture View) (vpage 72) Music3 Music4 OPTION Option .
Convenient functions Media Server USB Performing random playback (Random) Media Server USB 1 While content is playing, press OPTION. 2 Use ui to select “Repeat”, then press ENTER. The option menu screen is displayed. The option menu screen is displayed.
Convenient functions Playing back content added in “Favorite Memory” There are two ways to add content to favorites: q Add to favorites from the Option menu w Add to the FAVORITE STATION button 1 uio p to select “Favorites”, 2 Use then press ENTER. nnAdd to favorites from the Option menu (Favorite Memory) Press NETWORK. Network Media Server Internet Radio Favorites The option menu screen is displayed. “Favorite added” is displayed, and the current content is added to favorites.
Convenient functions 1 Press NETWORK. uio p to select “Favorites”, 2 Use then press ENTER. USB Internet Radio Media Server Playing back still images in sequential order (Slideshow) You can play back still image (JPEG) files stored on a USB memory device or media server and pictures on Flickr website as a slide show. The display time can also be set. 1 Play back a still picture (vpage 62). back a music file or Internet radio station 2 Play 1 Play back an image and press OPTION. (vpage 54, 59).
AirPlay function zzAvailable as a free download from the App Store. nnStreaming music stored in iPhone, iPod touch, or iPad directly to the unit Selecting multiple speakers (devices) iTunes 10, or later, on a Mac or Windows PC 1 Install that is connected to the same network as this unit. Click the AirPlay icon and select “Multiple Turn this unit ON. 1 Speakers” from the list. 2 2 Check the speakers you want to use.
AirPlay function With this unit’s remote control unit, you can perform iTunes song play, pause, and auto search (cue) operations. Devices General Playback Sharing Store Parental Devices is displayed on the menu screen while AirPlay is being operated. • Source input will be switched to “NETWORK” when AirPlay playback is started. • You can stop AirPlay playback by pressing the o or choosing other input source. • To see song and artist names together, press STATUS on the main unit.
This unit allows you to enjoy various kinds of surround and stereo playbacks. Multi-channel audio formats are adopted by many of the contents including Blu-ray disc and DVD as well as digital broadcasting and Internet-delivered movies and music. This unit supports playback of almost all of these multi-channel audio formats. It also supports surround playback of audio formats other than multi-channel audio such as 2-channel stereo audio.
Selecting a listening mode This mode detects the type of input digital signal, and automatically selects the corresponding mode for playback. 1 2 Press PURE to select “AUTO”. Play the selected device (vpage 37 – 67). Auto surround playback begins.
Selecting a listening mode Input signal Listening mode DTS-HD / DTS Express PCM/DSD multi-channel Multi-channel z4 Listening mode DTS-HD HI RES / DTS-HD HI RES A-DSX z5 DTS-HD MSTR / DTS-HD MSTR A-DSX z5 DTS Express / DTS Express A-DSX z5 DTS-HD + NEO:6 DTS-HD + PLgx Music DTS-HD + PLgz MULTI CH IN / MULTI CH IN A-DSX z5 MULTI CH IN 7.1 MULTI IN + Dolby EX MULTI IN + PLgx Music MULTI IN + PLgz MULTI CH STEREO VIRTUAL z1 2-channel also includes analog input.
Selecting a listening mode Input signal Listening mode All Listening mode Views on the TV screen or display e DIRECT PURE DIRECT AUTO z2 z1 2-channel also includes analog input. z2 When AUTO mode is selected, the sound mode that is compatible with the input signal is used for playback. z3 This mode plays back 2-channel source in 5.1 or 7.1-channel playback. It cannot be selected when headphones are used, or when only front speakers are used.
Selecting a listening mode Dolby listening mode DTS listening mode Listening mode type DOLBY PLgxz1 DOLBY Pro Logic DOLBY PLgzz2 DOLBY TrueHD DOLBY DIGITAL Plus DTS SURROUND DTS ES DSCRT6.1z DTS ES MTRX6.1z DTS 96/24 DTS-HD DTS Express zz This can be selected when “Speaker Config.” – “Surr. Back” is not set to “None”. PCM multi-channel listening mode Listening mode type MULTI CH IN Description This mode can be selected when playing multi-channel PCM sources .
Selecting a listening mode Listening mode type Audyssey DSX (A-DSX)z STEREO listening mode Description Listening mode type STEREO This mode creates playback for the new channels (front wide or front height) in 5.1-channel systems. By adding front wide or front high channels, the surround sound effects sound more three dimensional and realistic.
Advanced version Here, we explain functions and operations that let you make better use of this unit.
Procedure for speaker settings Speaker installation Speaker connection (vpage 84) Speaker installation • Determine the speaker system depending on the number of speakers you are using and install each speaker and subwoofer in the room. Here, we explain how to install the speakers using a typical example. • The speaker impedance should be from 6 to 8 Ω. This unit is compatible with Audyssey DSX® (vpage 171) and Dolby Pro Logic gz (vpage 171), which offers an even wider and deeper surround sensation.
Speaker installation When 5.1ch speakers are installed FL When using Audyssey DSX®, install front wide speakers or front height speakers. When using Dolby Pro Logic gz, install front height speakers. FL FR SW FR SW Basic version When 7.1-channel speakers are installed When 6.
Speaker connection NOTE Speaker terminals Carefully check the left (L) and right (R) channels and + (red) and – (black) polarities on the speakers being connected to this unit, and be sure to interconnect the channels and polarities correctly. Use a subwoofer cable to connect the subwoofer. off about 0.03 ft/10 mm of 1 Peel sheathing from the tip of the speaker cable, then either twist the core wire tightly or terminate it. the speaker terminal 2 Turn counterclockwise to loosen it.
Speaker connection Basic version Connecting 7.1-channel speakers using surround back, front height, and front wide speakers Advanced version The illustration on the right shows a connection example for performing 7.1-channel playback using the surround back, front height or front wide speakers.
Speaker connection Basic version Connecting 6.1-channel speakers using one surround back speaker If using only one surround back speaker, connect to the “L” side of the SURROUND BACK terminal. For speaker settings in this case, see “When 6.1ch speakers are installed” (vpage 83). To perform 6.1-channel playback using the surround back speaker, set “Assign Mode” to “Main Only” in steps 3 to 5 for “Set up “Amp Assign”” (vpage 91). Also use the “Speaker Config.” setting (vpage 132) to set “Surr.
Speaker connection Basic version Connecting 5.1-channel speakers To perform 5.1-channel playback, set “Assign Mode” to “Main Only” in steps 3 to 5 for “Set up “Amp Assign”” (vpage 91). Cables used for connections Audio cable (sold separately) Advanced version Speaker cable Subwoofer cable NOTE • For speaker cable connections, see page 84. • For speaker impedance , see page 84.
Speaker connection Basic version Connecting front A/B speakers You can connect a second set of speakers to this unit and use them for playback. In this case, set “Assign Mode” to “Front B” in steps 3 to 5 for “Set up “Amp Assign”” (vpage 91). Cables used for connections Audio cable (sold separately) Advanced version Speaker cable Subwoofer cable For multichannel playback, connect center, surround, surround back, and front speakers and a subwoofer.
Speaker connection Basic version Connecting 2.1-channel speakers Cables used for connections Audio cable (sold separately) Speaker cable Advanced version Subwoofer cable NOTE • For speaker cable connections, see page 84. • For speaker impedance , see page 84. nnFor connecting two subwoofers Two subwoofers can be connected to this unit. The same signal is output from each subwoofer terminal.
Speaker connection Basic version Connecting front speakers with a bi-amp connection • You cannot use surround back speakers in a bi-amp connection. Use front speakers that support a bi-amp connection and connect the speakers to the FRONT speaker terminals and the SURROUND BACK speaker terminals. In this case, set “Assign Mode” to “Bi-AMP” in steps 3 to 5 for “Set up “Amp Assign”” (vpage 91).
Set up speakers around items indicate the settings. First install and connect the speakers to this unit. Before Audyssey® Setup measurement, the settings shown below can be made. • Changing the amplifier assignment (Amp Assign) The signal output from the SURROUND BACK speaker terminal of this unit can be switched to match your speaker environment (vpage 91 “Set up “Amp Assign””).
Set up speakers speakers, and then press ENTER. 7 Set up “Channel Select” Use ui to select “Channel Select”, and then press ENTER. Audyssey Setup Setting for 7.1-channel playback using surround back, front height, or front wide speakers. ZONE2 Setting to assign the unit’s built-in power amplifier for ZONE2 and output the audio in stereo. ZONE3 Setting to assign the unit’s built-in power amplifier for ZONE3 and output the audio in stereo.
Set up speakers Measure Set to measure the front height speakers. Skip NOTE After performing Audyssey® Setup, do not change the speaker connections or subwoofer volume. In event of a change, perform Audyssey® Setup again. Set when you do not want to measure the front height speakers. Basic version 11 Use o p to set whether or not a front height channel is measured, and then press ENTER. o p to set whether or not a front wide channel is 12 Use measured, and then press ENTER.
Basic version Connections (Advanced connection) Connecting the REMOTE CONTROL connectors Remotely connecting marantz devices • You can connect an IR receiver to this unit to perform operations on this unit and external devices with the supplied remote control unit. • To do this, disable the remote control signal receiving function (vpage 102 “Remote lock function”). • When you are using a marantz device other than this unit that supports remote connection, an IR receiver is not necessary.
Connecting an external control device DC OUT jacks When you connect an external control device, you can control this unit with the external control device (such as power supply operation, volume adjustment, and input source switching). When a device with DC IN jack is connected, the connected device’s power on/standby can be controlled through linked operation to this unit. The DC OUT jack outputs a maximum 12 V/150 mA electrical signal.
Basic version Playback (Advanced operation) HDMI control function Setup (vpage 29) Playback (Basic operation) (vpage 36) If you connect the unit and an HDMI control function compatible TV or player with an HDMI cable and then enable the HDMI control function setting on each device, the devices will be able to control each other.
HDMI control function 97 Information DVD Advanced version If the HDMI control function does not operate properly, check the following points.
Sleep timer function ZONE SELECT to switch 1 Press “MAIN”. SLEEP and display the time 2 Press you want to set. NOTE The sleep timer function cannot turn off the power of devices connected to this unit. To turn off the power of those connected devices, set up sleep timers on the connected devices themselves. indicator on the display lights. 120 110 100 90 80 70 Information • The time switches as shown below each time SLEEP is pressed.
Web control function • This unit and the PC need to be connected to the network properly (vpage 27 “Connecting to a home network (LAN)”) in order to use the web control function. • Depending on the settings of your security-related software, you may not be able to access this unit from your PC. If this is the case, then change the settings of the security-related software. File For example, if the IP address of this unit is “192.168.100.19”, enter “http://192.168.100.19/”. File http://192.168.100.
Web control function t GExample 2H Setup menu screen GExample 1H MAIN ZONE control screen y ZONE CONTROL NETWORK iPod/USB HD Radio marantz SR7007 Q1 MAIN ZONE INPUTS CBL/SAT SPEAKERS GAME NETWORK Blu-ray CBL/SAT DVD AUX-1 AUX-2 MEDIA PLAYER TV AUDIO HD Radio CD PHONO Internet Radio iPod/USB M-XPort NETWORK FAVORITE STATION i o VIDEO 1 3 2 Q5 USER ACCOUNT GENERAL Q3 ON OFF Auto Lip Sync AVR TV HDMI Audio Out Auto(Dual) Video Output ON OFF HDMI Control ***** Standby Source *
Dual backup memory function Panel lock function To prevent accidental operation of this unit, you can disable operation of the buttons on the front panel. BACK ui ENTER BACK Advanced version X ON/STANDBY DISPLAY ZONE SELECT nnDisabling all key button operations nnRemembering set details (Backup) “MEMORY SAVING” is shown in the display, and the setting details are remembered. NOTE All button operations except X ON/STANDBY are disabled. • The volume is not remembered.
Panel lock function X ON/STANDBY while you press and hold BACK and ENTER with the unit 1 Press in standby mode. 2 Press ui to select “FP LOCK zOff”. 3 Press ENTER to enter the setting. Remote lock function • When not connecting an IR receiver, disable the Remote lock function. When the function is enabled, you can not perform operations with the remote control unit. • By default, this function is disabled. BACK ui ENTER Basic version nnCanceling the Panel lock function (z The currently set mode.
Various memory functions Personal memory plus function This function sets the settings (input mode, sound mode, HDMI output mode, MultEQ® XT, Dynamic EQ, audio delay etc.) last selected for the individual input sources. Basic version Switches light illumination on/off • You can switch the lighting around the main display on or off. • The factory setting is “ON”. The surround parameters, tone settings and the volumes of the different speakers are stored for the individual sound modes.
• You can operate this unit so as to enjoy audio in a room (ZONE2, ZONE3) other than the MAIN ZONE (room where the unit is located). • You can simultaneously play back the same source in both the MAIN ZONE, ZONE2 and ZONE3. You can also play back separate sources in the MAIN ZONE, ZONE2 and ZONE3. • When a TV is connected to the HDMI ZONE2 OUT connector, you can play back a video or audio from the device connected to the HDMI 1 - 6 IN connector in ZONE2 (HDMI ZONE2 function).
Audio output Video output Video Connection nnAudio connections (ZONE2, ZONE3) The audio signals of this unit’s ZONE2 and ZONE3 audio output terminals are output to the ZONE2 and ZONE3 amplifiers and played on these amplifiers. ZONE2 The video signals of this unit’s ZONE2 video output connector are played by the ZONE2 TV.
Playback Sleep timer function Adjusting the volume Use VOLUME df to adjust the volume. GAdjustable rangeH 0 – 40 – 98 (When the “Scale” (vpage 116) setting is “0 – 98”) the input source select 3 Press button to select the input source to be played. The audio signal of the selected source is output to ZONE2 or ZONE3. GAdjustable rangeH – – – –79dB – –40dB – 18dB (When the “Scale” (vpage 116) setting is “–79.5dB – 18.0dB”) • At time of purchase, “Volume Limit” (vpage 140) is set to “70 (–10dB)”.
Basic version How to make detailed settings Menu map For menu operation, connect a TV to this unit and display the menu on the TV screen. For menu operations, see the following page. By default, this unit has recommended settings defined. You can customize this unit based on your existing system and your preferences.
Menu map Detailed items General Description Page 140 140 140 141 141 141 141 Advanced version 141 142 143 Information Sets the language for display the menu on the TV screen. ZONE2 Setup Makes settings for audio playback in a ZONE2 system. ZONE3 Setup Makes settings for audio playback in a ZONE3 system. Zone Rename Change the display title of each zone to one you prefer. Trigger Out 1 Selects when to activate trigger out 1. Trigger Out 2 Selects when to activate trigger out 2.
Examples of menu screen displays GExample 2H Audyssey® Setup screen (with illustration) GExample 1H Menu selection screen (Top menu) Setup Menu i Audio q e Video o Inputs w Speakers Network General Amp Assign Channel Select Setup Assistant Q1 q Currently selected setup icon w List of GUI menu setup icons e Currently selected setup item r List of GUI menu setup items Start Q0 i Currently selected setup icon o Operation guidance text Channel Select Q0 Illustration Q1 Selected setup item Infor
Examples of menu and front display Menu display Top menu display Front display Description q Press SETUP to display the menu screen. w TV screen: Displays the selected line. Display: Displays the selected item. • Use ui to move to the item you want to set.
Inputting characters Keyboard screen nnInput method the screen for inputting 1 Display characters (vpage 107 “Menu Select a character on the TV screen to input characters. nnDisplay of a keyboard input screen map”). Basic version On this unit, you can change the name displayed on the following screens to the names that you prefer.
Make audio-related settings. Items that can be set with the “Audio” procedure Menu operation Surround Parameter (vpage 113) 1 Press ZONE SELECT to switch “MAIN”. 2 Press SETUP. 3 Use ui to select the menu to be set or operated. 4 Press ENTER or p to enter the setting. Tone (vpage 114) Subwoofer Level (vpage 115) M-DAX (vpage 115) Audio Delay (vpage 116) • To return to the previous item, press o or BACK. • Exiting the Menu, press SETUP while the menu is displayed. The menu display disappears.
Audio Default settings are underlined. You can adjust the surround audio sound field effects to match your preferences. The items (parameters) that can be adjusted depend on the signal being input and the currently set sound mode. For details on the adjustable parameters, see “Sound modes and surround parameters” (vpage 163). • Some setting items cannot be set while playback is stopped. Make the settings during playback. • When the sound mode is “PURE DIRECT”, you cannot set the surround parameters.
Audio 0 – 7 (3) The smaller the value, the more dialogue is concentrated on the center channel. The larger the value, the more dialogue is distributed to front left and right channels, and the more the sound image widens in the front. Tone Adjust the tonal quality of the sound. Setting items NOTE Bass Adjust bass. NOTE Treble Adjust treble. “Bass” can be set when the menu “Tone Control” setting is “On”. –6dB – +6dB (0dB) “Treble” can be set when the menu “Tone Control” setting is “On”.
Audio Default settings are underlined. Sets the subwoofer on/off and its output level. Setting items Subwoofer Turn subwoofer output on and off. Default settings are underlined. Compressed audio formats such as MP3, WMA (Windows Media Audio) and MPEG-4 AAC reduce the amount of data by eliminating signal components that are hard for the human ear to hear.
Audio Default settings are underlined. Audyssey Set Audyssey MultEQ® XT, Audyssey Dynamic EQ® and Audyssey Dynamic Volume®. These can be selected after Audyssey® Setup has been performed. For additional information on Audyssey technology, please see page 171. While viewing video, manually adjust the time to delay audio output. Setting details 0ms – 200ms NOTE Volume Default settings are underlined. Set the MAIN ZONE (room where the unit is located) volume setting.
Audio Dynamic EQ Solve the problem of deteriorating sound quality as volume is decreased by taking into account human perception and room acoustics. Works with MultEQ® XT. Setting details Setting items On : Use Dynamic EQ. Off : Do not use Dynamic EQ. • is displayed when set to “On”. • This can also be set by pressing DYNAMIC EQ on the main unit. Each time DYNAMIC EQ is pressed, the setting is changed as shown below.
Audio Stage Height Adjust sound stage height when using front height speakers. Setting details –10 – +10 (0) • “Audyssey DSX®” can be set when you are using front height speakers or front wide speakers. • “Audyssey DSX®” is only valid when using a center speaker. • “Audyssey DSX®” is valid when surround mode is DOLBY listening mode or DTS listening mode other than PLgz Height. Graphic EQ Use the graphic equalizer to adjust the tone of each speaker.
Make video-related settings. Items that can be set with the “Video” procedure NOTE When HDMI ZONE2 function is used, these settings are not available. Picture Adjust (vpage 120) Menu operation HDMI Setup (vpage 120) Output Settings (vpage 122) Component Video Out (vpage 123) The menu is displayed on the TV screen. Volume Display (vpage 123) Info Display (vpage 123) Advanced version 1 2 Press SETUP. 3 Use ui to select the menu to be set or operated. 4 Press ENTER or p to enter the setting.
Video Default settings are underlined. Setting items Make settings for HDMI video/audio output. Setting details Setting details On : Compensated. Off : Not compensated. AVR : Play back through speakers connected to the unit. TV : Play back through TV connected to the unit. • The audio signal input from the HDMI input connector can be output as an output signal from the HDMI output connector by setting the HDMI audio output destination to TV.
Video Video Output Make settings for HDMI monitor output. Setting details Setting items HDMI Control On : Use HDMI control function. You can link operations with Off : Do not use HDMI control function. devices connected to HDMI and compatible with HDMI • When a device that is not compatible with the HDMI control function is Control. connected, set “HDMI Control” to “Off”. • Please consult the operating instructions for each connected device to check the settings.
Video Default settings are underlined. Makes screen-related settings. zz “Blu-ray”, “GAME”, “AUX2”, “TV AUDIO” or “CD” can be set when “HDMI” or “COMP” (vpage 126, 127) has been assigned. Setting items TV AUDIO z CBL/SAT DVD Blu-ray z GAME z AUX1 AUX2 z MEDIA PLAYER CD z NETWORK TV AUDIO z Resolution Set the output resolution. You can set “Resolution” separately for HDMI output of the analog video input and HDMI input.
Video Progressive Mode Set an appropriate progressive conversion mode for the source video signal. Volume Display Setting details Auto : The video signal is automatically detected and the appropriate mode is set. Video : Select mode suitable for video playback. Video and Film : Select mode suitable for video and 30-frame film material playback. Sets where to display the master volume level. Setting items Volume This item can be set when “i/p Scaler” is set to anything other than “Off”.
Video Default settings are underlined. Sets how long each menu is displayed when the input source is “NETWORK”, “iPod/USB”, or “HD Radio”. Setting items Setting details Always : Show display continuously. 30s : Show display for 30 seconds after operation. 10s : Show display for 10 seconds after operation. Off : Turn display off. Audio Default settings are underlined. Set the video signal format to be output for the TV you are using. Setting items Format Setting details NTSC : Select NTSC output.
Perform settings related to input source playback. • You do not have to change the settings to use the unit. Make settings when needed. Items that can be set with the “Inputs” procedure Menu operation Input Assign (vpage 126) 1 Press ZONE SELECT to switch “MAIN”. 2 Press SETUP. 3 Use ui to select the menu to be set or operated. 4 Press ENTER or p to enter the setting.
Inputs This unit has certain input sources such as “CBL/SAT” assigned to audio and video connectors by default. By making the default connections, you can simply press an input source select button to play back audio or video from the connected device with ease. When making connections other than the default settings, you must change settings in this section.
Inputs Setting details Setting items DIGITAL COAX 1 / COAX 2 / OPT 1 / OPT 2 : Assign a digital input connector to the Set this to change the digital selected input source. input connectors assigned None : Do not assign a digital input connector to the selected input source. to the input sources. • At time of purchase, the settings of the different input sources are as shown below.
Inputs Default settings are underlined. Remove from the display input sources that are not used. Input Select Set the audio input mode and decode mode of each input source. The input modes available for selection may vary depending on the input source. Setting details CBL/SAT / DVD / Blu-ray / GAME / AUX1 / AUX2 / MEDIA PLAYER / iPod/USB / CD / HD Radio / NETWORK / TV AUDIO / M-XPort / PHONO : Select input source that is not used. • Show : Use this source. • Hide : Do not use this source.
Inputs Default settings are underlined. Video of another input source is played back combined with the playing audio. Setting details Default : Play the picture and sound of the input source. CBL/SAT / DVD / Blu-ray / GAME / AUX1 / AUX2 / MEDIA PLAYER / TV AUDIO / CD : Select video input source to view. The video of the selected input source is played along with the audio currently being played. This can be set for individual input sources.
Set when changing Audyssey® Setup settings. • If you change the speaker settings after performing Audyssey® Setup, it will not be possible to set Audyssey MultEQ® XT, Audyssey Dynamic EQ® and Audyssey Dynamic Volume® (vpage 116). • Can be used without changing the settings. Please set if necessary. Items that can be set with the “Speakers” procedure Menu operation Manual Setup (vpage 131) 1 2 Press SETUP. 3 Use ui to select the menu to be set or operated. 4 Press ENTER or p to enter the setting.
Speakers Perform when setting the speakers manually or when changing settings made in Audyssey® Setup. • If you change the speaker settings after performing Audyssey® Setup, it will not be possible to select Audyssey MultEQ® XT, Audyssey Dynamic EQ® and Audyssey Dynamic Volume® (vpage 116). • “Manual Setup” can be used without changing the settings. Please set if necessary. Setting items Amp Assign Select power amplifier usage method to match your speaker system.
Speakers Speaker Config. (Continued) Setting details Setting items Surr. Back : Set the presence, size and number of surround back speakers. • Large : Use a large speaker that can adequately play back low frequencies. • Small : Use a small speaker that has inadequate playback capacity for low frequencies. • None : Select when the surround back speakers are not connected. Bass Set subwoofer and LFE signal range playback. • “Subwoofer Mode” can be set when “Speaker Config.
Speakers Distances Set distance from listening position to speakers. Measure beforehand the distance from the listening position to each speaker. Setting details Setting items Unit : Set the unit of distance. • Feet / Meters Step : Set the minimum variable width of the distance. • 1ft / 0.1ft • 0.1m / 0.01m Set Defaults : The “Distances” settings are returned to the default settings. • Yes : Reset to the defaults. • No : Do not reset to the defaults. Levels Test Tone Start : Output test tone.
Speakers Setting details Crossovers Set the maximum frequency of the bass signal output from each channel to the subwoofer. Set the Crossover Frequency to suit the bass reproduction capability of the speaker being used. Crossover : Set the crossover frequency. • 40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz / Individual : Set the crossover frequency for all speakers. See the speaker manual for information concerning speaker crossover frequency.
To use this unit by connecting it to a home network (LAN), you must configure network settings. If you set up your home network (LAN) via DHCP, set “DHCP” to “On” (use the default setting). This allows this unit to use your home network (LAN). If you assign an IP address for each device, you must use the “IP Address” setting to assign an IP address to this unit and enter the information about your home network (LAN) such as the gateway address and subnet mask.
Network Friendly Name Display network information. The Friendly Name is the name of this unit displayed on the network. You can change the Friendly Name according to your preferences. Setting details Setting items Friendly Name / DHCP=On or Off / IP Address / MAC Address Edit Name Edits Friendly Name. MAC Address is required to make a vTuner account. Default settings are underlined. Set the network function on/off during standby.
Network Default settings are underlined. Make settings for wired LAN. Only set “Settings” when connecting to a network without a DHCP function. Network e Network/Settings DHCP IP Control IP Address 192.168.000.001 Friendly Name Subnet Mask 255.255.255.000 Default Gateway 255.255.255.000 Primary DNS 000.000.000.000 Secondary DNS 000.000.000.
Network nn Proxy settings Make this setting when connecting to the Internet via a proxy server. Make the proxy settings only when you connect to the Internet via a proxy server that is on your internal network or provided by your provider, etc. Use when receiving maintenance from a marantz service engineer or custom installer. Setting details NOTE Network/Settings Network IP Control IP Address 192.168.000.001 Friendly Name Subnet Mask 255.255.255.000 Default Gateway 255.255.255.
Make various other settings. Items that can be set with the “General” procedure Menu operation 1 2 Press SETUP. 3 Use ui to select the menu to be set or operated. 4 Press ENTER or p to enter the setting. Language (vpage 140) • To return to the previous item, press o or BACK. • Exiting the Menu, press SETUP while the menu is displayed. The menu display disappears. Front Display (vpage 141) Press ZONE SELECT to switch “MAIN”.
General Default settings are underlined. Set the language for display on the menu screen. Setting details English / Français / Español ZONE2 Setup / ZONE3 Setup Default settings are underlined. Set the audio to play back with multi-zone (ZONE2, ZONE3). • “ZONE2 Setup” is displayed when “ZONE2” is selected with “Assign Mode” (vpage 131). • “ZONE3 Setup” is displayed when “ZONE3” is selected with “Assign Mode” (vpage 131).
General Auto Standby Change the display title of each zone to one you prefer. When you do not perform any operation on this unit with no audio or video input for a specified time, this unit automatically enters the standby mode. Before it enters the standby mode, “Auto Standby” is displayed on the display of this unit and the menu screen. Setting details MAIN ZONE / ZONE2 / ZONE3 • Up to 10 characters can be input. • For character input, see page 111.
General Items Setting details ZONE Show information about current settings. Show information about receiver settings, input signals, etc. NOTE This item is not compatible with the HDMI ZONE2 function. Items Setting details Sound Mode : The currently set surround mode. Input Signal : The input signal type. Format : The number of input signal channels (presence of front, surround, LFE). Sample Rate : The input signal’s sampling frequency. Offset : The dialogue normalization correction value.
General Default settings are underlined. Set whether or not to check for firmware update, update the firmware, and display update and upgrade notifications. Setting items Update Update the firmware of the receiver. In cases where it is not possible to connect to the network after doing a firmware update, connect to the network again using “Network” (vpage 135). Update : The notification message is displayed for about 20 seconds when the power is turned on.
General Add New Feature Display new features that can be downloaded to this unit and perform an upgrade. NOTE Upgrade Package : Display the items to be upgraded. Upgrade Status : Display a list of the additional functions provided by the upgrade. Upgrade Start : Execute the upgrade process. When the upgrade starts, the STANDBY indicator becomes red and the menu screen is shut down. During the upgrade, the amount of upgrade time which has elapsed is displayed.
By registering preset codes for external devices to the provided remote control, you can operate your TV and playback devices (such as Blu-ray Disc player and DVD player) with the remote control. Registering preset codes When preset codes are registered in the included remote control unit, it can then be used to operate any devices you have, such as DVD players or TVs made by different manufacturers.
Registering preset codes 1 Press and hold the input source select buttons for the appliance to control, and press SET until indicator blinks twice. The back light flashes. The indicator blinks twice, after which the set code is shown for 3 seconds in the remote control display. By default, the input source select buttons on the remote control perform only the input source select operation.
Registering preset codes Preset codes that can be registered to TV buttons Button The types of devices that can be registered to each input source select button on this remote control are assigned as shown in the following table. Register the preset code under the desired device name in “List of preset codes” (vpage 183).
Operating external devices • The operation mode of the remote control unit is switched as shown in the table. When the FAVORITE STATION is pressed, the AVR-operation mode starts automatically. NOTE If the mode of the remote control unit is set to other than AVR-operation mode, press AVR to switch the remote control unit to the AVR-operation mode to perform the following operations: • For menu operation by pressing SETUP.
Operating external devices The supplied remote control unit can control a device other than this unit. the input source select 1 Press button to which the preset nnDVD group (2zzz) (DVD player / DVD recorder) operation Operation buttons TV X TV INPUT CH/PAGE df 2 Operate the device. • For details, refer to the device’s operating instructions.
Operating external devices Function Power on/off Menu TV power on/standby Switch TV input Enter Pause Playback Stop Auto search (cue) Manual search (fast-reverse/fast-forward) Track selection 6 7 0–9 Operation buttons DEVICE X DEVICE MENU TV X TV INPUT CH/PAGE df INFO uio p ENTER BACK SETUP 3 1 8 9 6 7 DVD 150 Operation buttons DEVICE X DEVICE MENU TV X TV INPUT INFO OPTION uio p ENTER BACK SETUP 3 1 Function Power on/standby (Popup) Menu TV power on/standby Switch TV input Information Top menu Curso
Operating learn function Remembering remote control codes from other devices with the remote control signal transmission sections facing each other. 5 cm • If “NG” is shown on the remote control display, perform step 5 again. If “NG” is shown again on the remote control display, the remote control may not be able to learn the code correctly. In this case, use the specialized remote control for the device. • If the remote control memory becomes full, “FULL” is shown on the remote control display.
Operating learn function Codes can be erased in three ways: by buttons, sources, and by all memory contents. nnDelete remote control codes for each button want to delete. The input source is shown in the remote control display. 3 Press and hold ON/STANDBY X and press the learned button to be erased twice. “ERASE” is shown in the remote control display, and the mode returns to LEARN mode. nnDelete remote control codes for all input sources Press and hold SET until the 1 LEARN indicator blinks.
Setting the back light Disabling the backlight and hold ZONE SELECT 1 Press and SET for at least 3 seconds. ui to set the zone to be used 2 Use and press ENTER. “SET” flashes four times on the remote control unit and the normal operation mode is restored. Remote control unit display Light button Zone to be used MAIN ZONE only M2 MAIN ZONE / ZONE2 M23 MAIN ZONE / ZONE2 / ZONE3 Turning the backlight on Press and hold both SET and Light button until indicator flashes twice.
Informations Here, we list various information related to this unit. Please refer to this information as needed.
Basic version Part names and functions Front panel For buttons not explained here, see the page indicated in parentheses ( ).
Front panel For buttons not explained here, see the page indicated in parentheses ( ). Q4 Q3 Q2 Q1 When the headphones are plugged into this jack, audio will no longer be output from the connected speakers.
Display Basic version Main Display The input source name, surround mode, setting values and other information are displayed here. nnStandard display nnSleep timer display q Light illumination y This lights when the sleep mode is selected (vpage 98). Advanced version When the power to this device is switched on, the surrounding area is lit blue. The settings can be changed so the light does not switch on (vpage 103 “Switches light illumination on/ off”).
Display Q2 Q1 Q0 o i u yt r w e o Tuner reception mode indicators The input source name, sound mode, setting values and other information are displayed here. w Front speaker indicator This lights according to the setting of the front A and B speakers. e Output signal channel indicators This lights when the mute mode is selected (vpage 37). y Sleep timer indicator This lights when the sleep mode is selected (vpage 98, 106).
Rear panel Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 Basic version See the page indicated in parentheses ( ). i u o Advanced version Information q w e q FM/AM antenna terminal (ANTENNA)··································· (23) w Analog audio connectors (ANALOG AUDIO IN/ANALOG AUDIO OUT) ····································································· (15, 16, 17, 19, 21, 22) e PRE OUT connectors·································· (85, 86, 87, 88, 89, 90) r 7.1ch input connectors (7.
Remote control unit q Display w e r Q7 t Q8 w AVR button········································ (146, 148) e SET button································· (145, 151, 153) r ZONE SELECT button························· (30, 106) t Device operation buttons q LEARN indicator w Information display e indicator q q w e (DEVICE X / DEVICE MENU)············ (149, 150) y Q9 W0 i o W1 W2 W3 W3 ENTER button (CH/PAGE df) ···························· (41, 44, 53, 56, 60, 63, 66, 68) W4 SETUP button i SL
Remote control unit Operating range of the remote control unit q Remove the rear lid in the direction of the arrow and remove it. Point the remote control unit at the remote sensor when operating it. w Load the two batteries properly as indicated by the marks in the battery compartment. Basic version Inserting the batteries R03/AAA Approx. 23 ft/7 m 30° e Put the rear cover back on. NOTE NOTE DVD 161 Information • Insert the specified batteries in the remote control unit.
nn Trademark information (vpage 162) nn Surround (vpage 163) nn Relationship between video signals and monitor output (vpage 169) nn Explanation of terms (vpage 171) Basic version Other information Trademark information This product uses the following technologies (Random order): The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Surround Basic version This unit is equipped with a digital signal processing circuit that lets you play program sources in the sound mode to achieve the same sense of presence as in a movie theater. Sound modes and surround parameters This table shows the speakers that can be used in each sound mode and the surround parameters adjustable in each sound mode. Symbols in the table S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels.
Surround Sound Mode (vpage 75) S Sz16 Sz16 Sz16 Sz16 Sz16 Sz16 Sz16 Dynamic Compression z12 (vpage 113) S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S Dimension (vpage 113) Center Image (vpage 113) Low Frequency Speaker Height Gain Effects Select z14 z13 z15 Panorama (vpage 114) (vpage 113) (vpage 114) (vpage 113) Center Width (vpage 114) z10 z11 z12 S S S z13 S S z14 S S S S S S S S S S S S z15 z16 S S S S S S S S S S S S S S S S S S S z17 z18 During playback
Surround Sz5 S S S S S S S S S S S S S S S S S S S S DVD MultEQ® XT z20 (vpage 116) Audyssey (vpage 116) Dynamic EQ Dynamic Volume z21 z21 (vpage 117) (vpage 117) Audyssey DSX® z20 (vpage 117) M-DAX z22 (vpage 115) z1 z5 z19 S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S z20 S S S S S S S S z21 S S S S S S S S S S S S S S S S S S 165 z22 z23 During playback in PURE DIRECT mo
Surround Basic version nnTypes of input signals, and corresponding sound modes This table shows the input signal that can be played in each sound mode. Check the audio signal of the input source then select the sound mode. Symbols in the table F This indicates the default sound mode. S This indicates the selectable sound mode. Input signal types and formats PCM NOTE Sound Mode (vpage 75) PCM (2ch) DTS-HD Master Audio DTS EXPRESS DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DOLBY DTS (5.
Surround NOTE Sound Mode (vpage 75) PCM (2ch) DTS-HD Master Audio DTS EXPRESS DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DOLBY DTS (5.1ch) DTS 96/24 DOLBY TrueHD DOLBY DIGITAL Plus DOLBY DIGITAL EX (With Flag) DOLBY DIGITAL (5.
Surround NOTE Sound Mode (vpage 75) z1 z2z4 z2z3 z2z5 z2z3 z2z3 PCM (2ch) DTS-HD Master Audio DTS-HD High Resolution Audio DTS EXPRESS DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DOLBY DTS (5.1ch) DTS 96/24 DOLBY TrueHD DOLBY DIGITAL Plus DOLBY DOLBY DIGITAL DIGITAL EX EX (With Flag) (With no Flag) DOLBY DIGITAL (5.1ch) Super Audio CD DOLBY DIGITAL (2ch) F S S S S F (7.
Relationship between video signals and monitor output Video Conversion COMPONENT VIDEO HDMI On A A A A On A A S S
Relationship between video signals and monitor output When “Video Conversion” (vpage 122) is set to “On”, “i/p Scaler” (vpage 122) is set to “Analog”, “Analog & HDMI” or “HDMI” are set, the resolution of the input video signal can be converted to a different resolution for output (vpage 6 “Converting input video signals for output (Video conversion function)”). The relationship between the resolution of the convertible video signal and HDMI output resolution is shown in the table below.
Explanation of terms D Deep Color An imaging technology supported by HDMI. Unlike RGB, which uses 8 bits (256 shades) per color, it can use 10 bits (1024 shades), 12 bits (4096 shades), or 16 bits (65536 shades) to produce colors in higher definition. Both devices linked via HDMI must support Deep Color. DLNA DLNA and DLNA CERTIFIED are trademarks and/ or service marks of Digital Living Network Alliance. Some contents may not be compatible with other DLNA CERTIFIED® products.
Explanation of terms F FLAC FLAC stands for Free lossless Audio Codec, and is a lossless free audio file format. Lossless means that the audio is compressed without any loss in quality. The FLAC license is as shown below. Copyright (C) 2000,2001,2002,2003,2004,2005,200 6,2007,2008,2009 Josh Coalson 172 I iTunes iTunes is the name of the multimedia player provided by Apple Inc. It enables management and playback of multimedia contents including music and movies.
Explanation of terms Z ZONE2 This unit can operate in a room other than the room where this unit is placed (MAIN ZONE) (ZONE2 playback). The room for ZONE2 playback is called ZONE2. ZONE3 This unit can operate in a room other than the room where this unit is placed (MAIN ZONE) (ZONE3 playback). The room for ZONE3 playback is called ZONE3. 173 Information DVD W Windows Media DRM This is a copyright protection technology developed by Microsoft.
If a problem should arise, first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? If this unit does not operate properly, check the items listed in the table below. Should the problem persist, there may be a malfunction. In this case, disconnect the power immediately and contact your store of purchase. Symptom GGeneralH Symptom Cause/Solution Page Power does not turn on.
Symptom Cause/Solution Page When the following • Set “HDMI Control” in the menu to “Off”. operations are Furthermore, if you do not want to link the power off operation performed on with devices compatible with HDMI control, set “Power Off devices compatible Control” in the menu to “Off”. with HDMI control, the same operations occur on this unit.
GAudioH Symptom Audio is not output. Cause/Solution Page • Check the connections for all devices. 10,11,14,15, 16,17,18,19, 20,21,22,23, 24,25,26,27 • Check the speaker connections and configurations. 85, 86, 87, 88, 89, 90 128 155 No sound is produced from subwoofer. • Check the subwoofer connections. DTS sound is not output. • Set “Decode Mode” on the menu to “Auto” or “DTS”. 128 Dolby TrueHD, DTSHD, Dolby Digital Plus audio is not output. • Make HDMI connections.
Cause/Solution Page “M-DAX” cannot be selected. • Check that an analog signal or PCM signal (Sample Rate=44.1/48 kHz) is input. For playback of multichannel signals such as Dolby Digital or DTS surround, “M-DAX” cannot be used. • Switch the sound mode to other than “DIRECT” or “PURE DIRECT”. 115 • The HDMI audio signals selected for ZONE2 are only output to the HDMI ZONE2 OUT connector.
Symptom • Files are stored in a non-compatible format. Record in a compatible format. • You are attempting to play a file that is copyright protected. Files that are copyright protected cannot be played on this unit. • Set and computer are connected by USB cable. The set’s iPod/ USB port cannot be used for connection to a computer. • Media sharing settings are not correct. Change media sharing settings so that the unit can access the folders on your computer.
GM-XPortH Audio is not output when a wireless receiver (RX101 is connected). Cause/Solution Resetting the microprocessor Page • Check that the Bluetooth device and Wireless receiver (RX101) 24, 171, 173 are correctly paired. Perform this procedure if the display is abnormal or if operations cannot be performed. When the microprocessor is reset, all the settings are reset to their default values. GAME A-DSX GRemote control unitH Symptom Cause/Solution Page • Batteries are worn out.
nn Audio section Basic version Specifications nn Video section • Power amplifier Rated output: Maximum effective output power: Frequency response: Rated output — 2 V (at 0 dB playback) Total harmonic distortion — 0.008 % (1 kHz, at 0 dB) S/N ratio — 102 dB Dynamic range — 100 dB Digital input: Format — Digital audio interface • Phono equalizer (PHONO input — MEDIA PLAYER OUT) Input sensitivity: 2.
Index vvC 2.1-channel·························································· 89 3D········································································ 12 5.1-channel···················································· 83, 87 6.1-channel···················································· 83, 86 7.
vvL vvO On-screen Info·················································· 123 Operation Mode·················································· 40 Output Settings················································· 122 vvP Pairing······························································· 173 Pandora®······················································ 61, 64 Panel lock function············································ 101 Panorama·························································· 113 Paramete
List of preset codes M Marantz GE 0000 Goldstar TV group (1zzz) A Citizen Colortyme Contec/Cony Craig Crown Curtis Mathes D E Daewoo Daewoo Daytron Dimensia Dumont Electroband Electrohome Emerson F G Envision Fisher Fujitsu Fujitsu Funai Gateway DVD H Hallmark Hisense Hitachi I J Hitachi Hitachi Infinity Janeil JBL JC Penney Jensen JVC K JVC JVC Kawasho Kenwood Kloss Novabeam KTV L M LG M.
T Z 2004, 2026, 2028, 2008 2028 2026 2046 2060 2010 2010 D E F G I J K GE GENEXXA HARMON HITACHI INKEL JC PENNEY JVC KARDON KENWOOD L M KRELL LUXMAN LX I MAGNAVOX MARANTZ N O MATHES MCS MGA MISSION MITSUBISHI NAD NAKAMICHI NEC MCS NIKKO ONKYO OPTIMUS P PANASONIC PHILIPS DVD RCA REALISTIC ROTEL RS ORIGINAL SAE SAMSUNG SANSUI SANYO SCOTT SEARS SHARP SHERWOOD SHURE SONY SYLVANIA SYMPHONIC T TEAC TECHNICA V Y Z THETA DIGITAL TOSHIBA VICTOR YAMAHA ZENITH H Humax J L M N O P R S B C D E F
13 25/64 (340.0) Weight : 27 lbs 9 oz (12.5 kg) DVD 185 7 9/32 (185.0) 21/32 (16.5) 2 9/64 (54.5) Information 1 31/32 (50.0) 2 13/64 (56.0) 1 31/32 (50.0) 10 33/64 (267.0) 15 45/64 (399.0) 14 7/32 (361.0) Advanced version 6 23/32 (170.5) 1 9/16 (39.5) 27/32 (21.5) Unit : in. (mm) Basic version 17 21/64 (440.0) 37/64 (14.
