1217A Operating Instructions

MADE IN USA

SPECIFICATIONS

Paper Weight………………………………………….28 Lbs. Bond, 90Lbs. Cover,

135Lbs. Index, 150 Lbs. Tag,

165 Lbs. Offset, 60-240 gsm/2

Max. Paper Size……………………………………….11 ¾” x 18”

Min. Paper Size………………………………………..4” x 4”

Speed…………………………………………………..10,300 11” Sheets Per Hour

Types Of Folds………………………………………...Trifold, Single, Z, Double

Parallel, French, Baronial

Feed Table Load Capacity……………………………1 5/8”

Stapled Sheet Capacity……………………………….3 Sheets 20Lb. Bond

Color…………………………………………………...Gray

Dimensions…………………………………………….42” x 17 ½” x 17”

Weight………………………………………………....52Lbs.

Shipping Weight……………………………………...57Lbs.

Power………………………………………………….120VAC(220VAC Optional, bo

European and U.K.)

This manual is for machines that have a serial number greater than 31,450

Reversible Motor

Friction Fed

Conveyor Stacker

Easy Disassembly

Adjustable Folds

Counter Available
