Yaw Damper for a 747 Jet Transport
10-3
Yaw Damper for a 747 Jet Transport
This case study demonstrates the tools for classical control design by stepping
through the design of a yaw damper for a 747 jet transport aircraft.
The jet model during cruise flight at MACH = 0.8 and H = 40,000 ft. is
A = [-0.0558 -0.9968  0.0802 0.0415
 0.5980 -0.1150 -0.0318 0
 -3.0500 0.3880 -0.4650 0
 0 0.0805  1.0000 0];
B = [ 0.0729  0.0000
 -4.7500  0.00775
 .15300  0.1430
 0 0];
C = [0 1 0 0
 0 0 0 1];
D = [0 0
 0 0];
The following commands specify this state-space model as an LTI object and
attach names to the states, inputs, and outputs.
states = {'beta' 'yaw' 'roll' 'phi'};
inputs = {'rudder' 'aileron'};
outputs = {'yaw' 'bank angle'};
sys = ss(A,B,C,D,'statename',states,...
 'inputname',inputs,...
 'outputname',outputs);
You can display the LTI model sys by typing sys.MATLABrespondswith
a =
   beta  yaw  roll  phi
 beta -0.0558 -0.9968 0.0802 0.0415
 yaw 0.598 -0.115 -0.0318 0
 roll  -3.05 0.388  -0.465 0
  phi  0  0.0805  1  0
