The Simulink LTI Viewer differs from the regular LTI Viewer, in that:
The Simulink LTI Viewer
includes an additional
menu for acquiring the
analysis model from
Simulink, specifying the
operating points, or
removing all the Input
and Output Point blocks.
Select
Linear Analysis from the
Simulink model
Tools menu to
open the Simulink LTI Viewer.
This set of Simulink blocks opens when you select
Linear Analysis.
Use these blocks to specify the inputs and outputs of the portion
of the Simulink model you want to analyze.
Plot region
Your Tools menu may
differ from this one,
depending on your
options.
