Preface, Contents Connections 1 Operating condition 2 To establish the system 3 Installation SINAUT MICRO SC 4 OPC Routing Software SINAUT MICRO SC 5 SINAUT MICRO SC configuration 6 PLC Library SINAUT MICRO SC 7 PLC Library SINAUT MICRO SC Flex Px 8 MD720-3 in OPC Mode 9 SIMATIC NET SINAUT MICRO SC System manual Troubleshooting Glossary C79000-G8900-C210 Release 08/2008 10
Safety Guidelines This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are graded according to the degree of danger.
General notices about the system Before using the software SINAUT MICRO SC and the PLC library please read carefully this system manual. Observe also the system manual of the GPRS/GSM modem SINAUT MD720-3.
Preface Purpose of this documentation This documentation will support you on your way to successful application of the SINAUT MICRO SC. It will introduce you to the topic in clear and straightforward steps and provide you with an overview of the hardware and software components of the SINAUT MICRO SC and SINAUT MD720-3 station control system.
Preface • You can find your local contact for Automation & Drives in our contacts database. • You will find information on local service, repairs, spares and much more under the rubric "Service". You will find the latest version of this documentation under the entry ID 22547968. Do you still have questions relating to the use of the products described in the manual? If so, then please talk to your local Siemens contact. You will find the addresses in the following sources: • On the Internet at: http://www.
Contents Preface.......................................................................................................................................... 4 1 Connections .................................................................................................................... 7 1.1 Communication via GPRS/GSM.......................................................................... 8 1.2 Communication by SMS ......................................................................................
Connections 1 The software SINAUT MICRO SC and the GPRS-Modem SINAUT MD-720-3 meet the following purpose: Communication of S7-200 controls via GPRS The SINAUT MICRO SC software is a OPC routing software with special communication functions. These communication functions enable the SINAUT MICRO SC to have data connections to remote S7-200 controls. For the connections the GPRS (General Packet Radio Service) of GSM networks (Global System for Mobile Communication) is used.
Connections 1.1 Communication via GPRS/GSM Connection S7-200 Ù MICRO SC OPC routing software GPRS/ GSM OPC Client Internet S7-200 PPI SINAUT MD720-3 SINAUT MICRO SC OPC Server Figure 1-1 GPRS communication S7-200 to SINAUT MICRO SC routing software The central SINAUT MICRO SC OPC Routing Software can connect up to 256 remote controls S7-200 via GSM/GPRS. The GSM/GPRS modems SINAUT MD720-3 connect the S7-200 controls to the GSM/GPRS network.
Connections GPRS communication S7-200 to S7-200 via SINAUT MICRO SC routing software Also the remote controls S7-200 can exchange data via the SINAUT MICRO SC Routing Software. To do this the control sends the data to the SINAUT MICRO SC Routing Software which forwards the data to the addressed control. 1.
Connections GSM data call S7-200 Õ Configuration computer GPRS/ GSM Fixed net S7-200 PPI Configuration computer SINAUT MD720-3 Figure 1-4 Remote configurations of the S7-200 by CSD data call When a call goes to the connected control this control switches to the PPI mode. Then a software update is possible.
Operating condition 2.1 2 Reachability of SINAUT MICRO SC The computer running the OPC routing software SINAUT MICRO SC needs to be reachable from the GPRS network permanently. Therefore this computer needs to be connected directly to the GPRS or must permanently be reachable in the internet by DSL for example. Caution The computer running the OPC routing software should be turned-off only for short period of times.
Operating condition 2.3 Defined Address of the OPC Routing Software SINAUT MICRO SC In order that a SINAUT MD720-3 can actively establish a GPRS connection to the OPC Server SINAUT MICRO SC, the OPC Server SINAUT MICRO SC must have a fixed IP address. There are three ways of obtaining a fixed IP address: Fix IP address The server is connected to the GPRS network via a dedicated line. In this case it has normally been assigned a fixed IP address by the network operator.
Operating condition 2.5 Necessary information Please have the following information available before you start to configure the SINAUT MICRO SC and the SPS program modules: Information about GSM / GPRS You will get this information from your GSM/GPRS network provider, e.g. on his Web pages, from his account manager or from his customer service. APN (Access Point Name) : ............................................................................. Name of the gateway to the Internet, Intranet.
Operating condition 14 SINAUT MICRO SC C79000-G8900-C210
To establish the system 3 Approach 1. Get the necessary information about the your internet and GPRS access, see Necessary information, chapter 2.5. 2. Install the OPC Routing Software SINAUT MICRO SC, see Installation SINAUT MICRO SC, chapter 4. 3. Open the configuration tool and configure the stations, see SINAUT MICRO SC configuration, chapter 6. 4. Define the entries for the SPS program modules WDC_INIT, see PLC Program modules, chapter 7.1.
To establish the system 16 SINAUT MICRO SC C79000-G8900-C210
Installation SINAUT MICRO SC 4.1 4 System requirements Hardware • PC compatible Server (INTEL or AMD); clock speed: > 1GHz recommended, • main memory: > 500Mbyte recommended; hard disk: > 1GByte free memory space recommended, • CD-ROM drive to run the installation, • Network adapter and network access to the internet or the GPRS.
Installation SINAUT MICRO SC 4.2 Installation Administrator To install the SINAUT MICRO SC software you need administrator rights for the computer. Number of connections Depending on the license which you have acquired, the SINAUT MICRO SC supports • 8 connections to 8 stations • 64 connections to 64 stations • 256 connections to 256 stations In addition there is a demo version available, which allows the connection to one only station (for a limited period).
Installation SINAUT MICRO SC Figure 4-2 Figure 4-3 Enter the license number. The license number is written on the licence certificate of the packaging.
Installation SINAUT MICRO SC Figure 4-4 Select the directory the SINAUT MICRO SC software shall be installed into. Figure 4-5 After you have start the SINAUT MICRO SC software, you will find an icon for this software in the task bar of Windows.
OPC Routing Software SINAUT MICRO SC 5 Any OPC client gains access to the actual data in the connected controls by means of the OPC Routing Software SINAUT MICRO. With the software you can also display the status information of each of the GPRS connections to the controls. 5.1 OPC Server The SINAUT MICRO SC OPC Server has the name „M2MOPC.OPC.1“. If the OPC client offers a list of all OPC servers you have to choose the corresponding entry. Or write the name in the field.
OPC Routing Software SINAUT MICRO SC 5.2 OPC Items The OPC server provides for each configured station the following OPC items: MSC:[]DB1,{}{,} Access to the PLC’s memory Read / Write MSC:[]GPRSConnected GPRS connection is currently established Datatype: Bool, Read only MSC:[]SignalQuality GSM signal quality (0..
OPC Routing Software SINAUT MICRO SC Notice When a new OPC item at the SINAUT MICRO SC OPC server is created, at the first time 64 bytes will be readout of the CPUs memory to optimize GPRS data volume. If the memory address is at the memory edge of the CPU, error messages may occur at the SINAUT MICRO SC. These error messages can be ignored. Stationname: The station’s name to access. This name is part of the station’s configuration.
OPC Routing Software SINAUT MICRO SC Count: (optional) Number of array elements that have to be accessed starting with the offset given in address. If no number is determined, a single variable will be accessed. A data block in the remote station is always mapped to DB1. Example: 8 Bytes starting at address 500 of the S7-200 with the stationname „S1“ are addressed e.g.
OPC Routing Software SINAUT MICRO SC Example: 5.4 Access path: - Item ID: MSC:[S1]DB1,INT100 Address Space Browsing The OPC server supports hierarchically Address Space Browsing. When browsing the data on the PLC there’s an asterisk „*“ given in the Item ID instead of the address. That one has to be replaced by the requested byte-offset. 5.
OPC Routing Software SINAUT MICRO SC 26 SINAUT MICRO SC C79000-G8900-C210
SINAUT MICRO SC configuration 6.1 6 Configuration tool SINAUT MICRO SC provides process remote control via GPRS (General Packet Radio Service). The system provides communication for the connected stations with each other and access to all stations over an OPC server. This "SINAUT MICRO SC" configuration tool is used to configure and monitor all stations connected to the system. A station consists of a Siemens S7-200 PLC and a GPRS modem SINAUT MD720-3.
SINAUT MICRO SC configuration The menu bar provides the following options: • File • Exit Closes the configuration tool (the server keeps on running). • Extras • Settings System-wide settings • ? • • Help Opens this help Info Shows license information The buttons on the right side are for processing the connected stations. Add Adds a new station to the system. A dialog is opened, to edit the properties of the new station. Edit Opens a dialog to edit the properties of the selected station.
SINAUT MICRO SC configuration Station properties Figure 6-2 Station properties Station name The specific station's name. This name must be unique over all stations. This name must be provided in the OPC client for addressing the variables. Station number The station's unique number. This number must match the parameter STATION_NUMBER when calling WDC_INIT. This number is used as destination address with communication between PLCs. Possible values are between 1 and 65535, 0 is reserved for the server.
SINAUT MICRO SC configuration GPRS modem password The password used by the GPRS modem for login at the server. This password must match MODEM_PASSWORD when calling WDC_INIT in the PLC program. This password is proposed depending on the station number but can be changed at any time. SPS status monitoring Indicates if and how the connection to the PLC is monitored in periodic intervals. • Status monitoring deactivated The connection to the PLC is not monitored. No additional costs are created.
SINAUT MICRO SC configuration Station status Figure 6-3 Station status Shows the current connection status of the selected station. The status is checked by an active call to the PLC when opening this dialog. GPRS connection Shows if the GPRS modem is connected to the server. PLC status Shows if there's a communication between the server and the PLC. There's only communication possible between the OPC server and the stations or between the stations with each other, if both fields show connected.
SINAUT MICRO SC configuration Status matrix Figure 6-4 Shows the current connection status of all configured stations. The stations are identified by their station number. The color coding shows the current state: The station is disconnected. The GPRS modem is connected to the server but communication with the PLC isn't possible. The station is connected With Test status of all stations the status of all stations is updated.
SINAUT MICRO SC configuration Settings Figure 6-5 Language selection Here the language used for the user interface can be selected. If you select an other language it is active after a restart of the program. Server Port Here the TCP/IP port the GPRS modems use to connect to the server can be configured. Possible values are between 1025 and 32767, the default is 26862. Notice: The port as configured here must match the setting in all PLC programs.
SINAUT MICRO SC configuration 34 SINAUT MICRO SC C79000-G8900-C210
PLC Library SINAUT MICRO SC 7 For wireless GPRS communication a GSM/GPRS-Modem SINAUT MD720-3 is connected to the PLC S7-200. The GSM/GPRS modem is configured and controlled by program modules of the S7-200. The PLC library SINAUT MICRO SC offers the possibility to communicate with the OPC routing software SINAUT MICRO SC“ as well as with other control systems via GPRS. Please observe too the PLC library PLC Library SINAUT MICRO SC Flex Px in chapter 8.
PLC Library SINAUT MICRO SC 7.1 PLC Program modules The PLC library provides the following modules for developing a GPRS communication. • WDC_INIT Parameter setting of modem • WDC_SEND Execution of transmission tasks • WDC_RECEIVE Processing of received data • WDC_CONTROL Controlling of communication mode (PPI resp. Freeport) The library always uses port 0 of the PLC.
PLC Library SINAUT MICRO SC 7.2 Program module WDC_INIT The module initialises the GRPS library, the PLC serial interface as well as the GPRS modem. Remark: This module is to be called from the user program once per cycle. WDC_INIT STATION_NUMBER BUSY IP_ADDRESS_CS DONE DESTPORT_CS ABORTED MODEM_NAME ERROR MODEM_PASSWORD PIN APN AP_USER AP_PASSWORD DNS CLIP Entering configuration parameters as string A lot of the configuration parameters need to be entered as strings.
PLC Library SINAUT MICRO SC Call of WDC_INIT: Corresponding entries MICRO SC Ù SPS program modules // //Data module comments // //Press F1 to start Help and a program example. // VB1800 11 VB1801 '68.225.63.9' VB1820 5 VB1821 '26862' VB1830 6 VB1831 'modem1' VB1840 7 VB1841 'secret1' VB1850 4 VB1851 '0000' VB1860 16 VB1861 'internet.t-d1.de' VB1910 5 VB1911 'guest' VB1920 5 VB1921 'guest' VB1930 26 VB1931 '194.25.2.131;193.254.160.
PLC Library SINAUT MICRO SC STATION_NUMBER (WORD) Logical address of local station. IP_ADDRESS_CS (DWORD (Saving address of string)) IP-address or DNS of server (Central Station). DESTPORT_CS (DWORD (Speicheradresse des Strings)) TCP/IP Port des Servers. MODEM_NAME (DWORD (Saving address of string)) Name for GPRS modem registration to the server. MODEM_PASSWORD (DWORD (Saving address of string)) Password for GPRS modem registration to the server.
PLC Library SINAUT MICRO SC AP_PASSWORD (DWORD (Saving address of string)) Password for registration at GPRS access point. DNS (DWORD (Saving address of string)) IP addresses of DomainNameServer of GSM provider. If two DNS servers are to be specified, these can be divided by semicolon (;) (DNS1;DNS2), e.g. „194.25.2.131;193.254.160.1“. CLIP (DWORD (Saving address of string)) List of all valid dial-in numbers at the station. Several listing entries are divided by semicolon (;).
PLC Library SINAUT MICRO SC DONE (BOOL) 1 The initialization has been successfully accomplished. ABORTED (BOOL) 1 The initialization has been aborted due to an error. ERROR (WORD) Error number, describing the result of the processing. A list of all error numbers and their meaning is to be found in chapter 7.6.
PLC Library SINAUT MICRO SC 7.3 Program module WDC_SEND This module processes all transmission tasks, initiated by the user program (transmission impulse via START). Thereby a new transmission task is accepted only then when no other task is active (BUSY must be 0). In the context of a transmission task, it is possible to send a user data block with specification of starting index and the length to the remote station. While BUSY is set parameters of the module must not bee edited.
PLC Library SINAUT MICRO SC DATA_LENGTH (BYTE) Amount of bytes, to be sent and/or read. COMMAND (WORD) 1 Send data to another station 2 Request data from another station CURRENTTIME (DWORD) Starting address of 8-Byte buffer with the current time in Siemens S7-200 BCD format (see READ_RTC standard module). If no real-time clock is available, 0 can be specified here.
PLC Library SINAUT MICRO SC 7.4 Program module WDC_RECEIVE This module monitors the receipt buffer. When a new telegram has arrived it will be evaluated. Received data will directly be copied to the mentioned address. To the application the receipt of data will be signaled via the outputs DATA_START and DATA_LENGTH. Remark: This module is to be called from the user program once per cycle.
PLC Library SINAUT MICRO SC REMOTESTATIONADDRESS (WORD) Logical address of remote station (PLC or OPC server), that has transmitted the message. DATA_START (WORD) Starting index of received data. DATA_LENGTH (BYTE) If data has been received, amount of received bytes. If no data has been received, 0. NEWTIME_RECEIVED (BOOL) Flag, which signals the receipt of a new system time.
PLC Library SINAUT MICRO SC 7.5 Program module WDC_CONTROL This WDC module indicates the current operation mode of the GPRS modem and the library. This module enables the modem switching in the AT command mode, to become access directly to the modem via AT commands from the user program (call via positive flank ACT_AT_MODE). This module enables the change to the „normal operation“ after a remote programming session via CSD call to the GPRS modem (call via rising edge at ACT_GPRS_SERVICE).
PLC Library SINAUT MICRO SC ACT_GPRS_SERVICE (BOOL) With consideration of the delay time DELAY_TIME_GPRS a rising edge activates the freeport mode of the interface 0 and puts the modem into the GRPS mode. ACT_AT_MODE (BOOL) A rising edge activates the AT command mode to the modem. DELAY_TIME_GPRS (WORD) Delay time in seconds between rising edge of ACT_GPRS_SERVICE and the switching in the freeport mode.
PLC Library SINAUT MICRO SC BUSY (BOOL) DONE (BOOL) 1 A mode change is carried out ABORTED (BOOL) 1 Mode change has been successfully completed. ERROR (WORD) Error list with cause of missed mode change. A list of all error numbers and their meaning is to be found in chapter 7.6 Error numbers.
PLC Library SINAUT MICRO SC 7.6 Error numbers The WDC program modules return error numbers if errors have occurred, in order to describe the error situation in detail. The following table contains all supported error numbers and their meaning.
PLC Library SINAUT MICRO SC 50 SINAUT MICRO SC C79000-G8900-C210
PLC Library SINAUT MICRO SC Flex Px 8 For wireless GPRS communication a GSM/GPRS-Modem SINAUT MD720-3 is connected to the PLC S7-200. The PLC library SINAUT MICRO SC Flex Px offers the possibility to communicate with the OPC routing software SINAUT MICRO SC as well as with other control systems via GPRS.
PLC Library SINAUT MICRO SC Flex Px 8.1 PLC Program modules The PLC library provides the following modules for developing a GPRS communication. • WDC_CONFIG_FLEX_Px Parameter setting of modem SINAUT MD720-3 • WDC_INIT_FLEX_Px Parameter setting of communication interface • WDC_SEND_FLEX_Px Execution of transmission tasks • WDC_RECEIVE_FLEX_Px Processing of received data Program modules being marked with FLEX_P0 always uses port 0 of the PLC.
PLC Library SINAUT MICRO SC Flex Px 8.2 Program module WDC_CONFIG_FLEX_Px The module initialises the GRPS library, the PLC serial interface as well as the GPRS modem. Remark: This module is to be called from the user program once per cycle. WDC_INIT_advanced BUSY IP_ADDRESS_CS DONE DESTPORT_CS ABORTED MODEM_NAME ERROR MODEM_PASSWORD PIN APN AP_USER AP_PASSWORD DNS CLIP Entering configuration parameters as string A lot of the configuration parameters need to be entered as strings.
PLC Library SINAUT MICRO SC Flex Px Call of WDC_INIT_advanced: Corresponding entries MICRO SC Ù SPS program modules // //Data module comments // //Press F1 to start Help and a program example. // VB1800 11 VB1801 '68.225.63.9' VB1820 5 VB1821 '26862' VB1830 6 VB1831 'modem1' VB1840 7 VB1841 'secret1' VB1850 4 VB1851 '0000' VB1860 16 VB1861 'internet.t-d1.de' VB1910 5 VB1911 'guest' VB1920 5 VB1921 'guest' VB1930 26 VB1931 '194.25.2.131;193.254.160.
PLC Library SINAUT MICRO SC Flex Px IP_ADDRESS_CS (DWORD (Saving address of string)) IP-address or DNS of server (Central Station). DESTPORT_CS (DWORD (Speicheradresse des Strings)) TCP/IP Port des Servers. MODEM_NAME (DWORD (Saving address of string)) Name for GPRS modem registration to the server. MODEM_PASSWORD (DWORD (Saving address of string)) Password for GPRS modem registration to the server. PIN (DWORD (Saving address of string)) PIN for activation of SIM card.
PLC Library SINAUT MICRO SC Flex Px DNS (DWORD (Saving address of string)) IP addresses of DomainNameServer of GSM provider. If two DNS servers are to be specified, these can be divided by semicolon (;) (DNS1;DNS2), e.g. „194.25.2.131;193.254.160.1“. CLIP (DWORD (Saving address of string)) List of all valid dial-in numbers at the station. Several listing entries are divided by semicolon (;).
PLC Library SINAUT MICRO SC Flex Px ABORTED (BOOL) 1 The initialization has been aborted due to an error. ERROR (WORD) Error number, describing the result of the processing. A list of all error numbers and their meaning is to be found in chapter 7.6. 8.3 Program module WDC_INIT_FLEX_Px The module initialises the GPRS library, the PLC serial interface as well as the GPRS modem. Remark: This module is to be called from the user program once per cycle.
PLC Library SINAUT MICRO SC Flex Px Call of WDC_INIT_smart: STATION_NUMBER (WORD) Logical address of local station. BUSY (BOOL) 0 Inactive 1 The initialization sequence is in process at the moment. DONE (BOOL) 1 The initialization has been successfully accomplished. ABORTED (BOOL) 1 The initialization has been aborted due to an error. ERROR (WORD) Error number, describing the result of the processing.
PLC Library SINAUT MICRO SC Flex Px 8.4 Program module WDC_SEND_FLEX_Px This module processes all transmission tasks, initiated by the user program (transmission impulse via START). Thereby a new transmission task is accepted only then when no other task is active (BUSY must be 0). In the context of a transmission task, it is possible to send a user data block with specification of starting index and the length to the remote station. While BUSY is set parameters of the module must not bee edited.
PLC Library SINAUT MICRO SC Flex Px DATA_LENGTH (BYTE) Amount of bytes, to be sent and/or read. COMMAND (WORD) 1 Send data to another station 2 Request data from another station CURRENTTIME (DWORD) Starting address of 8-Byte buffer with the current time in Siemens S7-200 BCD format (see READ_RTC standard module). If no real-time clock is available, 0 can be specified here.
PLC Library SINAUT MICRO SC Flex Px 8.5 Program module WDC_RECEIVE_FLEX_Px This module monitors the receipt buffer. When a new telegram has arrived it will be evaluated. Received data will directly be copied to the mentioned address. To the application the receipt of data will be signaled via the outputs DATA_START and DATA_LENGTH. Remark This module is to be called from the user program once per cycle.
PLC Library SINAUT MICRO SC Flex Px REMOTESTATIONADDRESS (WORD) Logical address of remote station (PLC or OPC server), that has transmitted the message. DATA_START (WORD) Starting index of received data. DATA_LENGTH (BYTE) If data has been received, amount of received bytes. If no data has been received, 0. NEWTIME_RECEIVED (BOOL) Flag, which signals the receipt of a new system time.
MD720-3 in OPC Mode 9.1 9 Connect / Setup the PPI adapter The S7-200 PLC and the GSM/GPRS modem MD720-3 are connected by the Siemens PPI Modemkabel Typ- Best. Nr. 6NH9701-0AD. Connection Connect the port PPI-RS485 with the PLC and the port PC-RS232 with the SINAUT MD720-3. Use a gender changer to adapt the PPI cable and the modem. Setup PPI-Adapter Character format: 8 N 1 Bit count : Bit rate: 10 bit 57600 bps DIP switch: DIP switch no.
MD720-3 in OPC Mode 9.2 Prepare the SINAUT MD720-3 for the OPC mode The GSM/GPRS-Modem SINAUT MD720-3 will be configured by the PLC S7-200 and the program modules. An additional configuration is not necessary. 9.3 SMS transmission in OPC mode Information about the SMS transmission in OPC mode you can find in the Internet in the SET21 examples, Beitrags-ID 22537809 9.4 Service calls in OPC mode To download a new firmware setup a service connection to the GSM/GPRS modem MD720-3.
MD720-3 in OPC Mode 9. In the Start-menu select Connect to and choose the connection you just have set up, e.g. Service-MD720. 10. Click two times OK to finish the Modem Configuration and the Properties windows To establish a service connection As soon as the network connection is set up you can establish the service connection. 1. Click Start. 2. In the Start-menu select Connect to and choose the connection to the SINAUT MD720-3. 3.
MD720-3 in OPC Mode 3. Then at the Ftp>-prompt enter: put !cmdfile Press Enter. After the firmware file and the !cmdfile file are successfully uploaded the SINAUT MD720-3 will start to install the new firmware. This process can last up to 10 minutes. After this the SINAUT MD720-3 restarts. Then the SINAUT MD720-3 is ready again. To tear-down the service connection Tear-down the local service connection when you do not use it any more. 1. At the Ftp>-prompt enter: quit Then press Enter. 2.
Troubleshooting 10 SINAUT MD720-3 and SINAUT MICRO SC do not connect The status indication of the SINAUT MICRO SC shows that the connection to the SINAUT MD720-3 is not established and the LED “C” (Connect) of the SINAUT MD720-3 is off or blinks slowly. The SINAUT MD720-3 is not ready for Operation Please check the LED indication of the SINAUT MD720 (refer to System manual SINAUT MD720-3, chapter Functions of LEDs in OPC-Mode), if the SIM card is inserted correctly and the if the PIN is accepted.
Troubleshooting Using a common mobile phone with GPRS function, please check if a GPRS Service is available in the location of your SINAUT MD720-3. The SINAUT MD720-3 does not reach the SINAUT MICRO SC The SINAUT MD720-3 is attached to the GPRS, but the LED “C” is off or blinks slowly. If the SINAUT MD720-3 is ready for operation and the signal quality is sufficient and the device is attached to the GPRS, please check the values for IP_ADDRESSCS, DESTPORT_CS.
Troubleshooting • that the internet address of your server (IP address or hostname) is correctly entered in your PLC program module (IP_ADDRESS_CS Parameter), • that the DynDNS server is frequently updated, if you are using a DynDNS Service to get a fixed address for your SINAUT MICRO SC. SINAUT MICRO SC and SPS do not connect The Status indication of the SINAUT MICRO SC shows, that the connection between SINAUT MICRO SC and SINAUT MD720-3 is established, but that the PLC is not reachable.
Troubleshooting 70 SINAUT MICRO SC C79000-G8900-C210
Glossary DynamicDNS providers offer the capability of being accessible via a fixed Internet address Each computer which is connected to the Internet has an IP address (IP = Internet Protocol). An IP address consists of 4 numbers, separated by full stops, which each have up to three digits. If the computer is online via the telephone line per modem, per ISDN or per ADSL it is assigned a dynamic IP address by the Internet service provider, i.e. the address changes from session to session.
Glossary APN (Access Point Name) (Access Point Name). Cross-network connections, e.g. from the GPRS network into the Internet are established in the GPRS network via socalled APNs During the dialling into the GPRS network the calling terminal specifies via the APN with which network it wishes to be connected: • the Internet, • a private company network connected via a dedicated line.
Glossary SMTP is based upon IP and is an E-mail protocol. IKE is based upon UDP and is an IPsec protocol. ESP is based upon IP and is an IPsec protocol. On a Windows PC the WINSOCK.DLL (or WSOCK32.DLL) takes over the handling of both these protocols. PPP (Point to Point Protocol) Designates a transmission procedure via serial point-to-point connections for data packets, specially for Internet access via a modem.
