M22LID618 OPERATING INSTRUCTIONS COLOUR TELEVISION WITH REMOTE CONTROL
Contents Features ............................................................... 3 Accessories ......................................................... 3 Introduction ........................................................... 4 Preparation ........................................................... 4 Safety Precautions ............................................... 4 Power Source .................................................. 4 Power Cord ......................................................
Programme ............................................ 34 Band ..................................................... 34 Channel ................................................. 34 Standard ............................................... 34 Colour System ...................................... 34 Search .................................................. 34 VCR Mode ............................................. 34 Decoder ................................................ 34 Store ..............................
Features Accessories • Remote controlled colour television. INFO • Fully integrated digital TV (DVB-T). • 100 programmes from VHF, UHF bands or ABC DEF GHI RETURN JKL MNO PQR SUBTITLE STU VWX YZ AUDIO cable channels can be preset. • It can tune cable channels. • Controlling the TV is very easy by its menu EXIT+10 ANGLE driven system. • A scart socket for external devices (e.g. video games, audio set, etc.). • Stereo sound system (German+Nicam). • Full function teletext .
Safety Precautions Introduction Thank you for choosing this product. This manual will guide you Please read the following recommended safety precautions carefully for your safety. for the proper operation of your TV. Before operating the TV, please Power Source read this manual throughly. 220-240 V AC, 50 Hz outlet. Ensure that you select the correct voltage setting for your Please do keep this manual in a safe place for future references. The TV set should be operated only from a convenience.
Cleaning this may result in an electric shock. Before cleaning, unplug the TV set from the wall outlet. Waste Disposal Instructions for waste disposal: Do not use liquid or aerosol cleaners. Use soft and dry • Packaging and packaging aids are recyclable and should principally be recycled. Packaging materials, such as foil bag, must cloth. Ventilation be kept away from children. The slots and openings on the TV set are intended for ventilation and to ensure reliable operation.
Installation To prevent injury, this device must be securely attached to the wall in accordance with the Information for users applicable in European Union countries installation instructions when mounted to the wall (if the option is available). LCD Screen The LCD panel is a very high technology product with about a million thin film transistors, giving you fine picture details.
Overview of the Remote Control Standby Switch to TV Mono-Stereo/Dual I-II Direct programme INFO Double digit Cursor up Cursor left Programme up ABC DEF GHI RETURN Programme down Previous programme JKL MNO PQR SUBTITLE External source Time/Sub-page/Subtitle on-off STU VWX YZ AUDIO Teletext Expand/Image size EXIT+10 ANGLE Reveal/ Switch to PC Index page/Electronic Programme Guide (EPG) Mix Update Hold Personal preference Tv button(Exit Menu or Teletext) Volume down Volume up Cursor down Cu
P/CH MENU TV/AV TV BUTTON Search forward / Skip next Stop Play / Pause Open / Close Power on/off MENU TV / AV Programme Up / Down Volume Up / Down FRONT VIEW Search back / Skip back LCD TV and Operating Buttons DVD BUTTON TOP VIEW REAR VIEW -800-ENG-01-TV-2297W-UK IDTV-1165UK-VGA-10057841.p65 8 25.06.
Viewing the Connections REAR VIEW HDMI Inputs are for connecting a device that has an HDMI socket. Your LCD Television is capable of displaying High Definition pictures from devices such as a High Definition Satellite Receiver or DVD Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i signals. No sound connection is needed for an HDMI to HDMI connection.
Headphone jack is used for connecting an external headphone to the system. Connect to the HEADPHONE jack to listen to the TV from headphones (optional). Component Video Inputs (YPbPr) are used for connecting component video. You can connect the component video and audio sockets with a device that has component output. Connect the component video cables between the COMPONENT VIDEO INPUTS on on the TV and the component video outputs of your device.
Power Connection IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz. • After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the mains. • Plug the power cable to the mains socket outlet. Aerial Connection • Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV. RF Input REAR VIEW - 11 00-ENG-01-TV-2297W-UK IDTV-1165UK-VGA-10057841.p65 11 25.06.
Connecting the LCD TV to a PC For displaying your computer’s screen image on your LCD TV, you can connect your computer to the TV set. • Power off both computer and display before making any connections. • Use 15-pin D-sub display cable to connect a PC to the LCD TV. • When done, switch to PC source. See, “Input selection” section. • Set the resolution that suits your viewing requirements.
Connecting to a DVD Player If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD players may have different connectors. Please refer to your DVD player’s instruction book for additional information. Power off both the TV and the device before making any connections. Note: Cables shown in the illustration are not supplied. • If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD player as illustrated below, switch to HDMI source.
Using Other Connectors You can connect a range of optional equipment to your LCD TV. Possible connections are shown below.Note that cables shown in the illustration are not supplied. • To connect external speakers, use an audio cable to connect Audio Line Out. • Turn on the LCD TV and external speaker set after all connections are made. Refer to your speaker set’s manual for further queries. • To listen the sound from headphones, connect to the HEADPHONE jack of theTV.
Connecting Other Equipment via Scart Most devices support SCART connection. You can connect a; DVD recorder, a VCR or a decoderto yourLCD TV by using the SCART sockets. Note that cables shown in the illustration are not supplied. • Power off both the TV and the devices before making any connections. • For more information, refer to your device’s own instruction book. DVD Recorder REAR VIEW scart socket VCR Decoder - 15 00-ENG-01-TV-2297W-UK IDTV-1165UK-VGA-10057841.p65 15 25.06.
Inserting Batteries in the Remote Control Handset Operating Range for the Remote Control • Remove the battery cover located on the back of the handset by gently pulling backwards from the indicated part. • Point the top of the remote control toward the LCD TV's remote sensor LED while pressing a button. • Insert two AAA/R3 or equivalent type batteries inside. Place the batteries in the right directions and replace the battery cover.
Input Selection Switching the TV On/Off Once you have connected external systems to your TV, you can switch to different input To Switch the TV On • Connect the power cord to the 220-240V AC,50 Hz. • Press STANDBY button. Then the standby LED lights up. • To switch on the TV from standby mode either: • Press the button, P/CH+ / P/CH- or a numeric button on the remote control. • Press the P/CH- or P/CH+ button on the TV. The TV will then switch on.
Basic Operations You can operate your TV using both the remote control and onset buttons. Operation with the Buttons on the TV Volume Setting Programme Selection (Previous or Next Programme) • Press P - button to select the previous programme. • Press P + button to select the next programme. • Press - button to decrease volume or + button to increase volume, so a volume level scale (slider) will be displayed on the screen.
Initial Settings When the TV set is operated for the first time, the IDTV turns on first. Because this is the first time the TV is used, there are no channels stored in the memory and the following message appears on the screen: Auto. Programming System Language Yes Start : Ok • To select the “Yes” or “No” option, highlight or U.K. West Europe Check the antenna cable No • To start installation process, select “Yes”, to cancel select “No”. the item by using the OK button. English Country Txt.
09:25 - 11:00 11:00 - 11:25 Now: 50/50 Next: Ace Lighting Signal Level: 1. BBC ONE 13:15 Current channel is highlighted. Use or buttons to change channels. Also press GREEN/RED buttons to scroll up/down the pages for the channels. • The information banner gives information on the channel selected and the • If you highlight an event; short event description, extended event description, start programmes on it.
• If you press button you can see the If “Subtitle” is on and a language option is button causes the set, pressing the following warning message display on the detailed help information easily. Press button again to exit help menu. • The starting time for EPG is the current time. You can see the event information for the next two hours. By pressing or button, you can go to the next/previous hours while Programmes list is highlighted.
Over Air Download IDTV Menu System To ensure that your IDTV always has the most up-to-date information, please ensure that, after use, it is set to standby mode. At 3 A.M. each day, the IDTV automatically searches for any new information which may be broadcast and will download this to your IDTV automatically. This operation will normally take approximately 30 seconds. The IDTV menu can only be viewed when watching digital terrestrial broadcasting.
Press the OK button to delete the highlighted CHANNEL LIST 1 channel in the channel list. Then the message below appears on the screen: BBC ONE 1. BBC ONE 2. BBC TWO 3. ITV 8 4. Channel 4 5. BBC THREE 6. Teletext 7. BBC FOUR 8. Sky Travel 9. UKHistory 10. RTL Select The selected service will be permanently deleted.
protected access to channels selected by A channel selected as a favourite appears in parents. In order to lock a channel you should know the parental lock password (default the main channel list with a favourites icon ) against the channel name as illustrated ( value is set to 0000 in the factory and can only be changed from the Configuration menu). below: Select the channel to be locked by highlighting it and select the Lock option by pressing or button.
Add New Channels Your previous digital channel list will be destroyed. Are you sure you want to delete all digital channels and settings for first time installation? This tuning menu consists of two parts: Yes • Automatic Search • Manual Search No By selecting Yes and pressing the OK button, the existing channel table will be deleted.
CONFIGURATION Audio Language Subtitle Favourite Mode EPG Preference Receiver Upgrade Parental Settings Change Default Audio Language Auto. Programming System Automatic tuning runs at: State: Fine scanning ... English Off Off Now&Next V.1.5 i More 78 % Audio Language Exit : TV After APS is finalized, the programme table will appear on the screen. In the programme table you will see the programme numbers and names assigned to the programmes.
broadcast simultaneous Next&Now and 7- Search for New Version (Manual Upgrade) Day electronic programme. Manual upgrade starts if the “Search for New Version” item is highlighted by using or Highlight the EPG Preference line in the Configuration menu and use the or button to select Next&Now or 7-Day. Receiver Upgrade The IDTV can be upgraded via the configuration menu, entered from the main menu. In the configuration menu, highlight the button and activated via pressing the OK button.
If it is correct, the Parental Settings menu will Up to five separate timer events can be set be displayed including the following items: and each is displayed in the Timer screen, showing the event number, the channel to be Menu Lock Installation selected, the start time, end time, date and the mode - whether that event is active (and Set Lock Key There you can set/reset locking for the main menu or the installation menu to restrict access.
If timer action occurs while the TV is being TV Setup watched, the TV switches to the selected channel. When timer expires, the TV switches You can use this item to display the TV functions. back to the channel which it is switched from. The digital TV Setup menu screen is accessed from the main menu. Press the M Selected digital channel will be output via Scart-2. You should connect your VCR to Scart2 for recording digital broadcast.
channel company, then insert those to the TV using the following procedure. Navigating the Analogue TV Menu System • Switch off the TV and unplug from the mains. • Insert the CAM, then viewing card to the slot For displaying menu options For navigation that is located in the terminal cover at the left-hand side of the TV (from front view). To confirm choices • The CAM should be correctly inserted, it is impossible to insert fully if reversed.
Analogue TV Menu Map FEATURES SOUND Sleep Timer Language Child Lock Menu Colour Favourite Mode Volume Balance Sound Mode Effect Equalizer 0 Back : Menu Stereo On Off Back : Menu Exit : TV PICTURE Picture Mode Brightness Contrast Colour Sharpness Back : Menu Off English Off Gray Off Exit : TV INSTALL Bright Programming A.P.S. Txt.
Equalizer Analogue TV Menu System Press or button to select Equalizer. Press / button to change the Equalizer setting. In Sound Menu SOUND equalizer menu, the mode can be changed to Flat, Speech, Music, Personal and Jazz. Volume Balance Sound Mode Effect Equalizer 0 Back : Menu Stereo On Off Exit : TV Select the desired frequency by pressing / button and increase or decrease the frequency gain by pressing / button.
Colour Temp Language Press or button to select Colour Temp. Press / to choose from one of these options: Cool, Normal and Warm. Press or button to select Language. Use / button to select the Language. Note: Press • Setting Cool option gives white colours a Use / button to set the Child Lock On or Off. When On is selected, the TV can only be slight blue stress. • Setting Warm option gives white colours a slight red stress. • For normal colours, select Normal option.
VCR Mode Select VCR Mode by pressing / button. Use / buttons to set VCR Mode as On or Off. Hint: If you want to watch a DVD , then you have to set this item as Off. Decoder PROGRAMMING Programme Band Channel Standard Colour System 4 S 30 BG PAL Back : Menu You can use this mode to connect any decoder to your TV. Select Decoder by pressing / button. Press the / buttons to turn it On or Off. Exit : TV Programme Select Programme by pressing Press / / button.
If you want to exit from A.P.S. function, press the TV button. For going back, press M. When you press OK button for starting APS, all stored programs will be erased and the following screen will be displayed: PROGRAMMING Colour System VCR Mode Store PAL Off Back : Menu Exit : TV Colour System Select Colour System by pressing / button. Press / button to change the colour system to PAL, SECAM or AUTO. Program Table P01 Program Table Auto.
Move highlighting it and then press the Select the programme that you want to insert by using the navigation buttons. Press the button is pressed, Program Lock When the menu will be displayed on the screen. After GREEN button. Using navigation buttons, move the selected programme to the decided entering the pin code, desired channel will be locked. The program lock icon will appear next programme space and press the GREEN button again. to the channel name.
H. (Horizontal) Position PC Mode Menu System See the “Connecting the LCD TV to a PC” section for connecting a PC to the TV set. For switching to PC source, press the AV button on your remote control and select PC input. Note that PC mode menu settings are available only while the TV is in PC source. Sound Menu The items in this menu are described at “Sound Menu” section explained in the “Menu System” section. This item shifts the image horizontally to right hand side or left hand side of the screen.
4:3 Displaying TV Information Programme Number, Programme Name, Sound Indicator and Zoom Mode information Use to view a normal picture (4:3 aspect ratio) as this is its original size. are displayed on the screen when a new programme is entered or button is pressed. Mute Function Press button to disable sound. Mute indicator will be displayed in the upper side 16:9 This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the wide TV screen. of the screen.
Teletext Coloured Buttons Teletext system transmits information such as news, sports and weather on your TV. Note that if the signal becomes insufficient, some text errors may occur or the teletext mode may be quitted. Teletext function buttons are listed below: Teletext On-Off / PAT mode Activates teletext mode when pressed once. Pressing this button again will split the screen into two windows, one displaying the teletext and the other displaying the current channel.
No Picture Tips Screen Care Clean the screen with a slightly damp, soft Is the aerial connected properly? Are the plugs connected tightly to the aerial socket? Is the cloth. Do not use abrasive solvents as they may damage the coating layer of the TV aerial cable damaged? Are suitable plugs used to connect the aerial? If you are in doubt, screen. consult your dealer. For your safety, unplug the mains plug when No Picture means that your TV is not receiving a transmission.
Appendix A: PC Input Typical Display Modes The display has a maximum resolution of 1680X1050 (optional), frequency range of 56-75 Hz. The following table is an illustration of some of the typical video display modes. Your TV may not support different resolutions. Supported resolution modes are listed below. If you switch your PC to an unsupported mode, a warning OSD will appear on the screen.
Specifications TV BROADCASTING PAL/SECAM B/G D/K K' I/I' L/L' RECEIVING CHANNELS VHF (BAND I/III) UHF (BAND U) HYPERBAND CABLE TV (S1-S20 / S21-S41) NUMBER OF PRESET CHANNELS 100 CHANNEL INDICATOR On Screen Display RF AERIAL INPUT 75 Ohm (unbalanced) OPERATING VOLTAGE 220-240V AC, 50 Hz. AUDIO German+Nicam Stereo AUDIO OUTPUT POWER (WRMS.
Pin Specifications Signal Input PC RGB Terminal (D-sub 15-pin connector) Pin 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 Input signal R G or sync on green B No connection No connection R.GND G.GND B.GND No connection GND No connection [SDA] H.sync or H/V composite sync V.sync. [V.
Important Instruction For your own safety read following instruction carefully before attempting to connect this unit to the mains supply.
Contents General Properties ................................... 43 Troubleshooting ........................................ 55 About this Manual ..................................... 43 The picture quality is poor (DVD) ............... 55 Disc does not play ..................................... 55 Wrong OSD language ............................... 55 The language for the sound or subtitles on a DVD cannot be changed. ................... 55 Some functions (Angle, Zoom etc) do not work ....................
DVD HOW TO WATCH A DVD When TV set is turned on, press DVD button on Remote Control and press play, or directly press play button at the front panel. If there is no disc inside of the loader , press Open / Close button, place a DVD and press play. General Properties • DVD / VCD / CD / CD-R / CD-RW / MP3 / JPEG / MPEG playback. • PAL playback (according to disc content) • User-friendly multilanguage OSD menu control. • , LPCM audio via coaxial and optical digital audio outputs.
instructions in the literature accompanying the appliance. Notes on Discs On handling discs • To keep the disc clean, handle the disc by its edge. Do not touch the surface. • Do not stick paper or tape on the disc. • If the disc is contaminated with any substance like glue remove before using it.
. DVD MODE Remote Control Buttons 1 Standby On-Of 2 Digits (Press to enter track/chapter/title/ time/etc... numbers directly.) To enter 2-digit numbers 3 4 5 6 7 8 9 10 Cursor Up Cursor Left Play / Pause Stop TV MENU Changes the language of the sound while playing a DVD if supported by the disc. Search Forward Search Back Zooms the picture by 2x, 3x, 4x while playing DVD/VCD/SVCD. Pressing zoom button again disables zoom mode. 11 Press to enter file list mode to list all the files in the disc.
Disc Types Compatible with This Unit: This player can play the following discs. - 46 00-MATSUI-ENG-02-DVD-1597-UK IDTV-1165UK-VGA-(DVD7240-X2TSF-WODIVX)-10054990-50120393.p65 46 25.02.
DVD Playback Basic Play 1. Press on the power button 2. Please insert a disc to the loader. The disc will be automatically loaded and play commences if the disc does not have any menus recorded on it. A menu may appear on the TV screen after a few moments or the film may start immediately after the introduction of the Film Company. This behaviour depends on the disc content and may change. NOTE: Step 3 and 4 is available only when a menu is recorded on the disc. 3.
Press SEARCH on the remote control once during playback. The chapter/title search box is displayed on the screen. You can see the currently playing and total number of chapters in right hand side of the display bar as -- / xx. Enter the number of the chapter using number buttons. The selected chapter is played just after you enter the chapter number. For your convenience: • If the chapter number you entered is between 0 and 9, player will automatically jump to the related chapter.
Some information is displayed on TV screen to indicate the current status of the disc. On the display screen you can find the following information lines: Line 1: Time Counter Mode Line 2: Title Number, Chapter Number, Time Counter Line 3: Audio Number, Audio Format, Number of Output Channels, Audio Language Line 4: Subtitle Number & Subtitle Language Time counter modes can be selected by pressing TIME key consecutively.
The number of recorded angles differs depending on the disc used. “ y/x ” is displayed shortly on the screen during playback. This indicates that the multiangle scene has just started. From that mom enton,the yth angle of total x angles is played and you can change the viewing angle until the end of the multi-angle scene. • In SETUP menu, an ‘ANGLE MARK’ option exists, which, if enabled, will display a continuous angle mark on the screen as long as multiangle scene is available. Press ANGLE during play.
Rapid Advance / Rapid Reverse Press SEARCH/SLOW ( or ) on the remote control during play. • Normal play is resumed when the SELECT button or PLAY/PAUSE ( ) button is pressed. 2x, 4x, 8x, • The speed of advance ( 16x, 32x) or reverse ( 2x, 4x, 8x, 16x, 32x) changes for every press of the or button. Note: No sound will be heard during Rapid advance or Rapid reverse. Skipping Ahead or Back to Chapters Skipping ahead Press SKIP/ FRAME ( ) on the remote control during play.
• If “ All” is displayed, the whole disc will be played again. • If “ Track” is displayed, the current track will be played again. Repeating two specific points between sections. (A –B repeat) Press A-B during play at the point where repeat play is to commence (A). A” is displayed on screen. “ Press A-B again at the point where repeat play is to be concluded (B). AB” is displayed and the repeat-play of the “ selection between points A and B starts. To return to normal play Press A-B again.
Rapid Advance ( Rapid Reverse) MP3/MPEG Track: Press SEARCH/SLOW ( or ) during play to decrease/increase play speed. 32x, 16x, 8x, 4x, 2x, PLAY, Y, 2x, 4x, 8x, 16x, 32x are the play speed modes. Skipping Ahead or Back to Tracks Press SKIP/ FRAME ( / ) during play to jump to the previous/next file. Next file in the current directory will be played. Press SKIP/ FRAME ( / ) during stop mode to jump to the previous/next page of the current directory.
LANGUAGE SETUP Setup Menu Press DISPLAY key on the remote control when the player is not in playback mode. The setup menu-main page appears. To close the setup menu, press DISPLAY key. Main Page In the main page, the first page is selected by default. Select pages using / arrow buttons. When selected, the page will be highlighted and the items of the selected page will be displayed. Press SELECT or arrow button to enter selected page.
- Place a disc onto the tray. • Disc incorrectly loaded. - Ensure that the DVD disc is in the drawer with the label uppermost. • Wrong type of disc. The machine cannot play CD-ROMS etc. • The region code of the DVD must match the player. Wrong OSD language PARENTAL (Parental Level): Video Language Preference - - Preference - Angle Mark 1 G Standby Time 2 Default Downmix 3 Pg 4 Pg 13 Parental Password 5 6 PG -R 7 Nc 12 8 Adult • Select the language in the set-up menu.
Definition of Terms Angle Recorded onto some DVD discs are scenes, which have been simultaneously shot from a number of different angles (the same scene is shot from the front, from the left side, from the right side, etc.). With such discs, the ANGLE button can be used to view the scene from different angles. Chapter Number These numbers are recorded on DVD discs.
Specifications DVD / VCD / CD / CD-R / CD-RW / MP3 / JPEG / MPEG player, - 57 00-MATSUI-ENG-02-DVD-1597-UK IDTV-1165UK-VGA-(DVD7240-X2TSF-WODIVX)-10054990-50120393.p65 57 25.02.
