Component List (continued)
Component Suppliers
MAX98089 EV Kit Files
Note: Indicate that you are using the MAX98089 when contacting these component suppliers.
SUPPLIER PHONE WEBSITE
Central Semiconductor Corp. 631-435-1110 www.centralsemi.com
Fairchild Semiconductor 888-522-5372 www.fairchildsemi.com
Hong Kong X’tals Ltd 852-35112388 www.hongkongcrystal.com
KEMET Corp. 864-963-6300 www.kemet.com
Murata Electronics North America, Inc. 770-436-1300 www.murata-northamerica.com
Taiyo Yuden 800-348-2496 www.t-yuden.com
TDK Corp. 847-803-6100 www.component.tdk.com
TOKO America, Inc. 847-297-0070 www.tokoam.com
FILE DESCRIPTION
INSTALL.EXE Installs the EV kit files on your computer
CDM20600.EXE USB driver installer
CDSM2.06.00WHQLCertified.ZIP USB driver
Device Manager Shortcut to device manager
USB_Driver_Help_200.PDF USB driver installation help file
DESIGNATION QTY DESCRIPTION
U14, U17 2
Dual SPDT switches (10 FDFN)
Maxim MAX4906ELB+
Y2 1
13MHz crystal oscillator
(2.5mm x 2.0mm)
Y3 1
16MHz crystal
(3.2mm x 2.5mm)
Y4 1
12MHz crystal
(3.2mm x 2.5mm)
DESIGNATION QTY DESCRIPTION
Y5 1
6MHz crystal (HC49)
Hong Kong X’tals
SSL60000N1HK188F0-0
— 28 Shunts
— 1
PCB: MAX98089 EVALUATION
KIT# (TQFN)
