_____MAX1202 Stand-Alone EV Kit

The MAX1202 EV kit provides a proven PC board lay-

out to facilitate evaluation of the MAX1202. It must be

interfaced to appropriate timing signals for proper

operation. Refer to the MAX1202 data sheet for timing

requirements.

Cut JU4 and apply the +5V analog supply between the

+5V pad and the pad marked GND. Connect the

VLOGIC pad to the microprocessor's power supply. Set

JU1 to the 2-3 position (V

= -5V) to allow input sig-

nals between ±4V (Table 1).

_______________General Description

The MAX1202 evaluation system (EV system) is a com-

plete, 8-channel data-acquisition system consisting of a

MAX1202 evaluation kit (EV kit) and a Maxim 3V

68L11D microcontroller (µC) module.

The MAX1202 is a low-power, +5V, 8-channel, 12-bit

analog-to-digital converter (ADC) that connects directly

to 3V and 5V microprocessors (µPs). Windows 3.1™/

Windows 95™ software provides a handy user interface

to exercise the MAX1202’s features.

Order the EV system for comprehensive evaluation of

the MAX1202 using a personal computer. Order the EV

kit if you have already purchased the 68L11D µC mod-

ule with a previous Maxim EV system, or for custom use

in other µC-based systems.

The MAX1202 EV kit and EV system can also be used

to evaluate the MAX1203. Simply order a free sample of

the MAX1203BCPP along with the MAX1202 EV kit. For

3V-only applications, refer to the MAX147 data sheet.

____________________________Features

♦ Proven PC Board Layout

♦ Complete Evaluation System

♦ Convenient On-Board Test Points

♦ Data-Logging Software

♦ 3V/5V Logic Interface

♦ Fully Assembled and Tested

Evaluates: MAX1202/MAX1203

MAX1202 Evaluation Kit

________________________________________________________________

Maxim Integrated Products

19-1197; Rev 0; 3/97

QTY DESCRIPTION

C1–C8, C13 9

C9, C10, C11,

C14, C15

C12 1 4.7µF, 10V tantalum capacitor

J1 1

JU1, JU2 2 3-pin jumper blocks

JU3 1

JU4 0

R1–R8 8

TP1 1 8-pin header

1 Maxim MAX1202BCPP

U2 1 Maxim ICL7660CPA

U3 1 78L05 voltage regulator

2 x 20 right-angle socket

0.1µF ceramic capacitors

0.01µF ceramic capacitors

DESIGNATION

2-pin jumper block

Open

300Ω, 5% resistors

____________________Component List

MAX1202EVL11

___________System Component List

______________Ordering Information

For free samples & the latest literature: http://www.maxim-ic.com, or phone 1-800-998-8800

None 1 PC board

None 1

Software disk,

“MAX1202 EVALUATION KIT”

Windows is a registered trademark of Microsoft Corporation.

1 20-pin socket

PART

MAX1202EVKIT-DIP 0°C to +70°C

TEMP. RANGE BOARD TYPE

Through-Hole

MAX1202EVL11-DIP 0°C to +70°C Through-Hole

PART

MAX1202EVKIT-DIP

68L11DMODULE 1 68L11D µC Module

QTY DESCRIPTION

MAX1202 Evaluation Kit

6811D MODULE

AVAILABLE

Summary of content (7 pages)

PAGE 1
9-1197; Rev 0; 3/97 E MODUL 6811D LE B A IL A AV MAX1202 Evaluation Kit The MAX1202 evaluation system (EV system) is a complete, 8-channel data-acquisition system consisting of a MAX1202 evaluation kit (EV kit) and a Maxim 3V 68L11D microcontroller (µC) module. The MAX1202 is a low-power, +5V, 8-channel, 12-bit analog-to-digital converter (ADC) that connects directly to 3V and 5V microprocessors (µPs). Windows 3.1™/ Windows 95™ software provides a handy user interface to exercise the MAX1202’s features.
PAGE 2
Evaluates: MAX1202/MAX1203 MAX1202 Evaluation Kit ______________MAX1202 EV System The MAX1202 EV system operates from a usersupplied 9V to 15V DC power supply. The Maxim 68L11D 3V µC board uses a MAX667 linear regulator to generate the 3V logic supply. The MAX1202 board uses a 78L05 linear regulator to generate its own 5V analog supply. No level translators are necessary because the MAX1202 VL pin is connected to the 3V logic supply. Quick Start Table 1.
PAGE 3
MAX1202 Evaluation Kit Shutdown Power Cycling The MAX1202 can be shut down between conversions to reduce average supply-current demand. From the “Power” menu, select full power-down (FULLPD) or fast power-down (FASTPD) mode. In fast power-down mode, the bandgap reference remains active. The amount of power saved depends primarily on how long the part is off between conversions. The conversion accuracy depends on the power-up delay, the reference capacitor, and the time in power-down.
PAGE 4
+5V 1 R1 300Ω 1 C1 0.01µF R2 300Ω 2 CH1 3 CH2 C3 0.01µF R4 300Ω 4 CH3 C4 0.01µF R5 300Ω 5 CH4 C5 0.01µF R6 300Ω C6 0.01µF R7 300Ω C7 0.01µF R8 300Ω SHDN 3 15 J1-35 VL CH6 14 13 GND REFADJ VSS SHDN REF C13 0.01µF 11 J1-2 REFADJ J1-4 TP-4 TP-5 TP-6 DOUT +3V C10 0.1µF _______________________________________________________________________________________ VREF C9 0.1µF Figure 1.
PAGE 5
MAX1202 Evaluation Kit Evaluates: MAX1202/MAX1203 1.0" Figure 2. MAX1202 EV Kit Component Placement Guide— Top Silkscreen 1.0" 1.0" Figure 3. MAX1202 EV Kit PC Board Layout—Component Side Figure 4.
PAGE 6
Evaluates: MAX1202/MAX1203 MAX1202 Evaluation Kit Listing 1.
PAGE 7
MAX1202 Evaluation Kit Evaluates: MAX1202/MAX1203 Listing 2.
