Specification Sheet

PROJECT NAME:_____________________________ CATALOG NUMBER:__________________________
NOTES:______________________________________FIXTURE SCHEDULE:_________________________
Phone: [phone] | Fax: [phone] | Web: www.maxlite.com | E-mail: [e-mail]
MAX17082
Revised: 10/09/18
Page: 1 of 4
LED HIGH BAY LINEAR
ECO SERIES
BLHE
- D U
FAMILY -
WATTAGE
(NOMINAL)
DIMMING
VOLTAGE
CCT OPTIONS
BLHE=
ECO Linear
High Bay
- 090=
135=
162=
90W
135W
162W
D= Dimming U= 120-277V
40=
50=
4000K*
5000K
(OMIT)=
MS=
None
Bi-Level Motion Sensor with Remote
Control Capability
PRODUCT DESCRIPTION:
The Eco High Bay Series is a cost-effective and quality solution for
lighting warehouses, distribution centers, manufacturing facilities,
big box retailers, and other industrial applications. A dimmable
and compact product made of galvanized steel housing and white
electrostatic powder coat nish, it delivers a high lumen output to
replace both 4 or 6 lamp T5HO uorescent highbay or 400W HID
highbay xtures. Cable, pendant and surface mounting options enable
the highbay to be customized to meet virtually any lighting requirement.
FEATURES:
• Dimmable product
• Operating temperature -20°C to 50°C (-4°F to 122°F)
• Suitable for Damp locations
• L70 lumen maintenance of 50,000 hours
• Translucent lens standard to minimize glare
• V hook and 40” chain included
• Additional mounting options available (not included)
• Field installable battery backup unit
• 5 year limited warranty
• Remote control required for commissioning of sensor
MODEL SELECTION (Full list of order codes on pg. 2)
Typical order example: BLHE-090DU50
A
C
B
A
B
C
DIMENSIONS
PRODUCT A B C
BLHE-090DUXX 23.8” 12.6” 3.62”
BLHE-090DUXXMS 29.3” 12.6” 3.62”
BLHE-135DUXX 23.8” 17.3” 3.62”
BLHE-135DUXXMS 29.3” 17.3” 3.62”
BLHE-162DUXX 23.8” 17.3” 3.62”
BLHE-162DUXXMS 29.3” 17.3” 3.62”
*4000K available for 135W and 162W only
0
-
1
0
V
D
I
M
M
I
N
G
