High Performance K56Plus/V.34+/V.42bis 56K BPS Plug & Play Internal Voice/FAX/Data/SVD Modem With Advanced Speakerphone functions User's Manual Contents Section One - Introduction .......................... 1 Section Two - Installation ............................. 1 Section Three - AT Command Set ............... 7 Section Four - S Registers ........................ 14 Section Five - Result Codes ...................... 15 Section Six - Troubleshooting ....................
The information contained in this manual has been validated at the time of this manual's production. The manufacturer reserves the right to make any changes and improvements in the product described in this manual at any time and without notice. Consequently the manufacturer assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the product and the manual. All registered trademarks are the property of their respective owners.
Section One - Introduction This 56 Kbps* Plug and Play FAX/Voice/Data/ SVD Speakerphone Modem connects your computer to all popular high speed modems available today. The modem incorporates “K56Plus” (56Kbps) technology to provide increased download speeds using regular telephone lines. The modem incorporates Plug and Play for ease of installation. It features speakerphone capability for hands-free communication and full-duplex analog/digital simultaneous voice and data (SVD) over a single telephone line.
(e.g., Windows 95), or B) A Plug and Play Revision 1.0a compliant PC. Proceed to Section 2.3 now if you have everything required. If you have neither 2A or 2B above, youneed to install Windows 95 to provide Plug and Play functionality to your PC. 2.3 Hardware Installation Installation of this modem requires opening and manipulating your PC. Exercise caution at all times when working with AC powered and static-sensitive equipment. Turn off and unplug your PC before installation.
7. Connect the telephone cable from the modem's LINE connector to the telephone wall jack. 8. Optionally, connect your telephone to the modem's PHONE connector. 9. Turn your computer on. Your modem is now installed. 2.4 Hardware Configuration (Plug and Play) Your modem is configured using the Plug and Play (PnP) capabilities of your computer.
2.4.1.1 Windows 95 Release 4.00.950 When Windows 95 starts for the first time after card installation, it detects the modem and displays the New Hardware Found dialog box. Under New Hardware Found, when asked to “Select which driver you want to install for your new hardware,” click on “Driver from disk provided by hardware manufacturer.” Click “OK.” The Install From Disk dialog box now instructs you to “Insert the manufacturer's installation disk into the drive selected, and then click OK.
2.4.2 Configuring in a Plug and Play System without Windows 95 When this modem is installed in a Plug and Play system without Windows 95, the computer's BIOS will assign a COM port and IRQ line to the modem. Proceed to Section 2.5, Software Installation/ Configuration. 2.5 Software Installation and Configuration You are now ready to install and configure the communication software. Refer to your software manual for installation procedures.
RJ-11 jack marked “PHONE” or by attaching a microphone to the MIC jack and a speaker to the SPK jack of your sound card. Follow instructions in the FAX/ Voice/Speakerphone software on recording and playback of voice prompts. 2.7 Testing Your Modem After Installation In order to test your modem you should be familiar with your communication software. Load and set up your communication software and enter into “terminal mode.” Make sure that the COM Port and IRQ settings of the modem match the software.
are interested in accessing the modem manually, and not through the included software. Section 4 and 5 contain reference material, and can be skipped. If you have difficulties getting your modem to work, read Section 6 - Troubleshooting to find answers to commonly asked questions and problems. Section Three - AT Command Set 3.1 Executing Commands Commands are accepted by the modem while it is in Command Mode. Your modem is automatically in Command Mode until you dial a number and establish a connection.
B1 B2 B15 B16 Bell mode V.23 originate mode @ 75 bps transmit/ 1200 bps receive V.23 originate mode @ 1200 bps transmit/75 bps receive Selects V.21 at 300 bps Selects Bell 103 at 300 bps L P T W , @ ! ; 0 - 9, A-D, # and * last number redial pulse dialing touch-tone dialing wait for second dial tone pause wait for five seconds of silence flash return to Command Mode after dialing B3 D_ DS=n E_ Dial one of the four telephone numbers (n=0-3) stored in the modem’s nonvolatile memory.
O_ O0 O1 Return to Data Mode Return to Data Mode and initiate an equalizer retrain Q0 Q1 Modem sends responses Modem does not send responses P Q_ Set Pulse dial as default Sr? Read and display value in register r. Sr=n Set register r to value n (n = 0-255). T Set Tone Dial as default V_ V0 V1 Numeric responses Word responses W_ W0 W1 Report DTE speed only Report line speed, error correction protocol, and DTE speed.
&D3 DTR toggle Modem hangs up, returns to the Command Mode after DTR toggle Resets modem after DTR toggle &F_ &F Recall factory default configuration &G_ &G0 &G1 &G2 Guard tone disabled 550 Hz guard tone 1800 Hz guard tone &K_ &K0 &K3 Disable flow control Enable RTS/CTS hardware flow control Enable XON/XOFF software flow control Modem is set up for dial-up operation &D2 &L_ &K4 &L0 &M_ &M0 Asynchronous operation &S_ &S0 &S1 Force DSR Signal High (ON) DSR off in command mode, on in on-line
compression %C1 Enable MNP Class 5 data compression only &Q_ &Q0 &Q5 &Q6 Direct data link only (same as \N1) V.42 data link with fallback options Normal data link only (same as \N0) \A_ \A0 \A1 64-character maximum MNP block size 128-character maximum MNP block size 192-character maximum MNP block size 256-character maximum MNP block size \A2 \A3 \Bn Send a 1/10 second line break to the modem, where n = 1 to 9.
pass XON/XOFF to remote modem or local DTE -C_ -C0 -C1 Data calling tone disabled Data calling tone enabled 3.
+FDTC: +FET: +FET=n +FHNG +FK +FLID= +FLPL +FMDL? +FMFR? +FPHCTO +FPOLL +FPTS: +FPTS= +FREV? +FSPL +FTSI: Report the polled station capabilities Post Page Message Response Transmit Page Punctuation Call Terminations with Status Session Termination Local ID String Document for polling Identify Model Identify Manufacturer Phase C Time Out Indicates polling request Page Transfer Status Page Transfer Status Identify Revision Enable polling Report the Transmit Station ID 3.
-SRM -SSE=n n=0 n=1 Retrieve message Disable DSVD Enable DSVD -SSP -SSR -SSV -STM -STT Set transmission speeds Start sequence response control Data mode event message Time Telephone handset transaction tone control Start Voice View data mode -SVV Section Four - S Registers Your modem has 28 registers, designated S0 through S92. Table 4-1 shows the registers, their functions, and their default values. Some registers can have their values changed by commands.
S37 S38 S42-43 S48 S89 S90 S92 Connection speed 56K dial line rate Reserved LAPM negotiation Sleep mode timer Local phone status Transmit level 0-19 0-16 0 1 7, 128 7 0, 5-255 seconds 10 0=on hook, 1=off hook 6-15/dB 15 Section Five - Result Codes OK 0 CONNECT 1 RING 2 NO CARRIER 3 ERROR 4 CONNECT 1200 5 NO DIALTONE 6 BUSY 7 NO ANSWER 8 CONNECT 300 EC* 40 CONNECT 2400 EC* 10 CONNECT 4800 EC* 11 CONNECT 9600 EC* 12 CONNECT 7200 EC* 24 CONNECT 12000 EC* 25 CONNECT 14400 EC* 13 CONNECT 16800 EC* 86 CONNEC
.2 hm te oto ka”td l“o etm h o ctC e o nrcO tM ap R nIod trQ n s(a sg ie m ttC eOM ap R nIod th rQ n m a tse g isttodem Yo c.o )um r muo cn sw a n io tfa m erku nsotwch aidderyso m su R IrS oQ n m yh d a s,g im tle yr.u n sp e o ctm sive cd rb m a n g itso rfu ye d a h im rtslca e rtodem. MY ya zm h o e skctyia u e o d .rtlciro tndiesm im e sd ra p n sizyp o le h a to id a yn lb ivY se tno e ism .u na h m o fa ce tyr-seo tdesm n iu b A g iyT&aF n pe d rE sNTE oT w h la m R td e h lo fce sya t.
C :sO tp M o r IRQ lines: FAX Group: 4321,, 3, 4, 5, 7, 9, 10, 11, 12, 15 Group III Send/Receive Standard FAX Command set: EIA/TIA-578 Service Class 1, EIA/TIA-SP2388 Service Class 2 Transmit level: -11 dBm +/- 1 dB Receiver Sensitivity: -39 dBm (V.34); -43 dBm (all other protocols) UART: 16550 compatible Data format: 300-115200 bps Power: 0.75 W T e m :u ra tp e r 5 do 5 etge 0 O rC (esp ne g a ir)t Caller ID: Yes PnP: Revision 1.
ThF eCC e a sro a q lrhF e tn u rasA iom a e rftX n rtsim so sb in pe d p o F (rid e pfC yn reiltrC Ru e P S 6ls8 6 a e,t8 3 rc(.)8 c()1 em S F atB C C as C en lt Teh sqiu pime hn abtseetn setadn ofd ucn otC d am o afe la risB h p d g ctw vslh e u p iyts,rlh iu P tF o 1 e a to5 C a n ftrC RT u elshm .a ed ise rtleig sinp e otrdve rieasonap b eo re lota cintgh a na isn m treitfe ro T n ru a d e fin sa lh tcsie q .
NOTC IT E hL:eoaN dumL b (N a esrgs)n ieo e a te d cm trhdnea icd ve linh o p e to b e sco a le rtd o n h ate n ltgp e lo ao e h cftd ono lw e u psh e cp id b to h e d irtyvco eivn o ,eta lrT n de g ihm tr.eo n ola im np tacn co yo yn fsm tidn b o ea ich n e vrftsie q o u se tru e bm yn icjh ltsh e ute L a m n o ttafN dh ud te m cve d ilab sole nsfrxoctee1d00.
