DiamondMax 22 Serial ATA Product Manual, Rev. A 5
*One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment
and formatting.
**During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and
power to operational levels.
Vibration, operating 2–22 Hz: 0.25 Gs, Limited displacement
22–350 Hz: 0.50 Gs
350–500 Hz:: 0.25 Gs
Vibration, nonoperating 5–22 Hz: 2.0 Gs
22–350 Hz: 5.0 Gs
350–500 Hz:: 2.0 Gs
Drive acoustics, sound power
Idle** 2.5 bels (typical)
2.7 bels (max)
Performance Seek
2.9 bels (typical)
3.1 bels (max)
Quiet Seek
Nonrecoverable read errors 1 per 10
14
bits read
Annualized Failure Rate (AFR) 0.34%
Warranty To determine the warranty for a specific drive, use a web browser to access the following
web page:
support.seagate.com/customer/warranty_validation.jsp
Contact start-stop cycles 50,000 at 25°C, 50% rel. humidity
Supports Hotplug operation per the
Serial ATA Revision 2.5 specification
Yes
Drive specification STM31000334AS
