Meijer.com Thank you for choosing Maxxus Infrared Sauna! Index ===================================== Page Important Safety Guides…………………………………………………...… 2 Introduction…………………………………………………………...………… 3 Health & Beauty Benefits……………………………………………………… 3 Highlights……………………………………………………………….……..… 4 Assembly..…………………………………….……………………………..….. 4 Sauna Operation…...…………………………………………………………… 12 Warnings…………………………………………………………………………. 14 Troubleshooting…………………………………………………………….
Meijer.com READ IMPORTANT SAFETY GUIDES BEFORE USING! READ AND FOLLOW ALL INSTRUCTIONS A). Please following all warning labels and markings on the sauna room. B). Do not install any receptacles on the interior or exterior walls of the sauna room. C). No locking devices are installed or shall be installed on the door of the sauna room which could result in entrapment within the sauna room. D). During use, the ceiling vent can be in the opened position. E).
Meijer.com M). Never sleep inside the sauna. N). Do not use any type of cleaning agents on the interior of the sauna. Only wipe down with a cloth and water. O). Do not stack or store any object on top or inside the sauna. P). Do not use the sauna during an electrical storm to avoid risk of shock. Q). Do not attempt to make any repairs yourself. If a problem occurs with the sauna, please contact seller, distributor, or the manufacturer to avoid safety risks.
Meijer.com Highlights a. High quality craftsmanship b. Automatic thermostat for constant temperature c. Timer and buzzer: buzzer sounds 5 minutes before the end of the sauna session d. Digital sensor and thermometer e. Infrared carbon heat emitter panels f. Wiring diagram: Assembly Assembly Requirements a. You will need a philips screwdriver, ladder, and two adults to assemble. b. Do not plug any other appliances into the power supply of the sauna room other than the designated sauna connections/plugs.
Meijer.com 1 2 1- Roof Cover 3 3- Left Back Panel 2- Roof Panel 6 4- Left Side Panel 4 5- Front Panel 6- Right Back Panel 5 7 7- Right Side Panel 8 8- Right Bench 9- Left Bench 10- Right Bench Heating Board 9 11- Left Bench Heating Board 10 13 12- Floor Panel 13- Floor Heater 11 12 FIG-1 NOTE: The pictures and diagrams shown within this owner’s manual are representations of this model. Actual model may vary. 3. 3-person sauna and 4-person sauna models are packed in three cartons.
Meijer.com See FIG 3. FIG 3 5. Placing Floor Panel Align the Right Back Side Panel with the Floor Panel’s corresponding wood pattern; make sure the wood pattern is flowing in the same direction. One person should hold the Right Back Side Panel while the other person continues to the next step. See FIG 4 FIG 4 6. Assembling Right Back Side Panel Align the Left Back Side Panel with the Floor Panel and the Right Back Side Panel.
Meijer.com 7. The Right Back Side Panel will align with the Right Side Panel. tight, use the latches to buckle together. Once they are aligned and fit together snug and Do the same for the Left Back Side Panel and the Left Side Panel. See Figure 6 FIG 6 Assembling Back Side Panels and Side Panels 8. Lay the floor heater on the floor panel as seen in FIG 7.
Meijer.com FIG 9 Inserting Benches FIG 10 Securing Benches with screws 12. Align the Front Panel with the Floor Panel, Right Side Panel, and Left Side Panel. the Left and Right Side Panels respectively. Next, latch the Front Panel with Note: Be cautious with the glass door to avoid breakage. See FIG 11. FIG 11 Assembling Front Panel 13.
Meijer.com . FIG 12 Slip cords/wires through corresponding holes FIG 14 FIG 13 Connecting cords/wires connectors Slip cords/wires through roof 16. The CD Player will already be mounted in its wood housing box. the wires up through the roof. Connect the antenna to the CD player. Then mount the wood housing box to the ceiling of the sauna room. 15.2, FIG 15.3, and FIG 15.4. Note: CD player may not be available on all model sauna rooms 9 Next, feed See FIG 15.
Meijer.com FIG 15.1 CD Player in wood housing FIG 15.2 Connect antenna plug FIG 15.3 Feed the wires up through the roof 17. Connect the CD Player wire harness on the roof. FIG 15.4 Screw wood housing to sauna room See FIG 16 FIG 16 Connecting CD Player connection 18. Locate the Control Panel harness on the roof and make the connection.
Meijer.com 19. Make sure all steps are completed correctly. Plug in the power cord to your wall outlet. the control panel to confirm that the control panel is responding. Turn on the sauna at Turn on the CD Player to confirm that is operates. If the control panel and CD Player respond accordingly, then proceed in putting the Roof Cover onto the Roof Panel. Make sure to pull the power cord through the corresponding hole in the Roof Cover and screw down the Roof Cover. See FIG 18 & 18.
Meijer.com Sauna Operation 1. Precautions a. Please make sure your wall outlet meets the specifications required. Failure to meet the requirements may cause safety risks. The average used temperature range is between 118ºF – b. Set the temperature and time to a comfortable level. 122ºF. The average sauna session is approximately 20 – 30 minutes. You must pre-heat sauna room to the desired temperature before entering.
Meijer.com d. Press the button to turn the light ON. If you want to use the Color Light Therapy System: 1. While the interior light is ON, press and hold down the notice “2n” in the LED display. button for 2 seconds. You will This indicates you are in the “light” mode. If you do not press any buttons for approximately 15 seconds, the “2n” will change back to the Timer mode. 2.
Meijer.com CAUTION: Exit sauna immediately if you feel dizzy, sleepy, or any discomfort. Warnings 1. Safety precautions a. To avoid fire, do not dry clothes or leave any towels in the sauna room. b. Do not install the sauna near water, near a bathtub, near a shower, in a wet basement, or near a swimming pool. c. To prevent burns or electric shocks, do not touch or use metal tools on the protective material covers of the heat emitter panels. d.
Meijer.
Meijer.
Meijer.com Limited LifetimeWarranty *Limited Lifetime Warranty: Golden Designs, Inc. warranties the heating elements and electronics against defects in material and workmanship for the life of the product from the original date of purchase. This sauna is for INDOOR use only. Placing your sauna outdoors will VOID this warranty. Any damage due to exposure to outdoor elements such as rain, snow, sun, wind or extreme temperatures will not be covered by this warranty.
Meijer.com removal - arising directly or indirectly out of the use or inability to use the product. Any implied warranty shall have duration equal of the applicable warranty stated above. Under no circumstances shall Golden Designs, Inc. or any of its representatives be held li able for injury to any person or damage to any property, however arising. Specifications are subject to change without notice or obligation. Legal Remedies This limited warranty gives you specific legal rights.
Meijer.
Meijer.com WARRANTY CARD Congratulations on your purchase of an Infrared Sauna from Golden Designs, Inc. Please take the time to complete the following Warranty Card and mail it back to: Golden Designs, Inc. 1920 Proforma Ave Ontario, CA 91761 Please include a copy of your sales receipt showing date of purchase as this will serve as proof of purchase. Warranty will be VOID if the following warranty card is not mailed back within 60 days of purchase date along with proof of purchase.
