Data Sheet

■ Model Encoding
DIP24 package with industry standard pinout
2:1 wide input range
Operating temperature range -40 ~ +90
℃
No minimum load required
Comply to EN55032 radiated Class A without additional
components
High efficiency up to 87%
Protections: Short circuit (Continuous) / Overload /
Input under voltage
3KVDC I/O isolation
3 years warranty
■ Features
File Name:SCWN03,DCWN03-SPEC 2018-01-15
■ Applications
■ Description
S and D series are W isolated and module type DC-DC converter with IPCWN03 CWN03 3 regulated D 24
package. It features international standard pins, a high efficiency up to 8 %, working temperature 7 wide
range -40~+ , KVDC I/P-O/P isolation voltage, 90 3 Compliance to EN55032 radiated Class A without ℃
additional components additional components,, continuous-mode short circuit protection, etc. The models
account for different input voltage and various
4.5~9V, 9~18V, 18~36V and 36~72V 2:1 wide input range,
output voltage, . /5V/12V/15V single output and ±5V/±12V/±15V dual outputs, which are suitable 33V for for
for all kinds of systems, uch as industrial control, telecommunication field, distributed power architecture,
s
and so on.
Output voltage (3 3 5 5. / / / ± /± /±12 15Vdc 12 15Vdc)，
Rated wattage
Input voltage ( )E: 4.5~9Vdc A: 9~18Vdc B: 18~36Vdc C: 36~72Vdc，， ，
Series name
- 12S CWN03 E
S:Single output
D:Dual output
{
3W DIP Package DC-DC Regulated Converter
SCWN03 & DCWN03 series
Telecom datacom system/
Wireless network


Industrial control facility
Instrument
Analyzer
Detector
Data switch
