User Instructions

9
Ambient Temperature ( )℃
0 10 20 30 40 50 60 70
20
40
60
80
100
Figure 6.2: Output Derating Curve
TS-700/1000 Series can power most of equipments that need an AC source
which can provide 700W(TS-700)/1000W(TS-1000) continuously. But for
certain load type, the u nit may not work properly.
Figure 6.3: Input Derating Curve
Battery Input Voltage (V)
10.5VDC
21VDC
42VDC
11.5VDC
23VDC
46VDC
15VDC
30VDC
60VDC
20
40
60
80
100
(F)Derating
(HORIZONTAL)
Chas sis
Where, the DC I/P and chassis fix manner as followin g :
1. Company Name : Mean Well Enterprises Co Ltd
2. Model Name : 1GG1HS-191
3. Rating : 150A
4. Torque : 106.2 Ib.in max.
5. Suitable Wire : Cop per wire (tem p rating : 75 C )
6. Intended for termination o nto a Listed ring to ngue connector
7. To Be Sold Only Wi th Inst allation Instr uction s
8. A mounting screw that is f irst inserted throug h the tang and is threaded into the
connector to secure the connector to the tang shal l be torqued to 32 in-lbs minimum
9. Mount ing Screws - Plated Steel . Two provided, siz e M8
Cat.No. (1G G1HS-212)
Wire Range (10-4 AWG
Str Cu Soldered Wires)
Torque (17. 7-26.5 in lb )
(G) Notes on output load:
