INFORMATION FOR YOUR SAFETY! THE FCC REGULATION WARNING (for USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Contents Panel & Display Description Front Panel.......................................4 Rear Panel........................................4 Display..............................................5 Memory/Percussion Memory...........................................13 Percussion......................................13 Chord Dictionary...........................14 Setup Power Supply....................................6 Metronome Turning on the Metronome.............14 Selecting the Beat......................
Panel & Display Description Front Panel DIXIELAND 7 13 8 1 10 2 3 11 9 14 12 5 15 4 6 1. POWER ON/OFF Turn the power on and off. 2. A.B.C. Turn the Chord Mode on and off. 3. START/STOP Start or stop playing the song in Song Mode. Start or stop playing the style in Style Mode. 4. SYNC/FILL Turn the SYNC START on and off. Play the FILL 5. RECORDING 10. STORE RECORD: Enter the Record Register the memory. Mode. PLAY: Play back the recorded 11. STYLE Enter the Style Mode. performance. 6.
Panel & Display Description 23 18 17 22 21 16 19 20 16. MEMORY/PERC. Switch the M1-M5/PAD1PAD5's function between memory and percussion. 17. MODULATION Turn the Modulation effect on and off. 18. LESSON/CHORD DICT. Change the Lesson mode. Enter the Chord Dictionary. 21. SUSTAIN Turn the Sustain effect on and off. 19. NUMBER KEYS Select the number or adjust the parameters. 22. METRO Turn the metronome on and off. 20. DSP Turn the DSP effect on and off. 23. PIANO Enter the Piano Mode. Display 1.
Setup This section contains information about setting up your instrument and preparing to play. Please go through this section carefully before turning the power on. Power Supply You can power the unit either by batteries or by power adaptor. Follow the instructions described below. Using Batteries 6 pieces of C size (SUM-2 or R-14) or equivalent alkaline batteries must first be installed into the battery compartment. 1. Open the battery compartment cover located on the bottom cabinet of the unit. 2.
Connections Connecting a pair of Headphones A standard pair of stereo headphones can be connected to the PHONES jack for private practice or late-night playing. The internal stereo speaker system is automatically shut off when a pair of head phones is plugged into this jack. Note： Do not listen with the headphones at high volume for long periods of time. Doing so may cause hearing loss. Connecting an Amplifier Plug an audio cord into the OUTPUT jack.
Playing the Demos The instrument features 80 demo songs. 1. Press the [STYLE] and [VOICE] buttons simultaneously to start playing the demo. 2. Select a demo song. Use the number keys, the [+] button or the [-] button to select the desired demo song. 3. Adjust the volume with the [MASTER VOLUME] buttons. Repeatedly press [MASTER VOL] up or down to increase or decrease the volume. The volume ranges from 0 (no sound) to 9 (Maximum) and the current volume level appears on the display. From 0-9 4.
Playing the Voices Modulation The Modulation function applies a vibrato effect to notes played on the keyboard. Press the [MODULATION] button while playing the keyboard then you will hear the vibrato effect. DSP Effect This function allows you to perform the overall sound in a more realistic effect. The DSP effect is set to ON when keyboard power on. Press the [DSP] button to turn on/off the DSP effect.
Playing the Styles The instrument features 100 styles in a variety of different musical genres. Try selecting some of the different styles (Refer to Style List) and play with the auto accompaniment. Note: The styles (91-99 and 00) are the piano styles. If you don't turn on A.B.C. and play a chord, the auto accompaniment does not work. Selecting a Style 1. Press the [STYLE] button. Enter the STYLE mode. LCD shows “STYLE” and the style number. 2.
Playing the Styles Tempo Each style of the instrument has been programmed with a default tempo; however, this can be changed by using the [TEMPO+] or [TEMPO-] buttons. 1. Use the [TEMPO+] or [TEMPO-] button to change the tempo. The value ranges from 40 to 240. 2. Hold down the [TEMPO] buttons can change the tempo quickly. 3. Press the [TEMPO+] and [TEMPO-] buttons simultaneously to restore the default tempo setting. Chord Fingering 1. Press the [A.B.C] button, “A.B.
Playing the Styles One Touch Setting One Touch Setting is a convenient function that allows you to automatically play a preset voice to match a selected style you have changed. Follow these steps to activate One-Touch Setting. 1. Press the [O.T.S.] button to turn on the One Touch Setting for current style. “O.T.S.”appears. 2. Press one of the ONE TOUCH SETTING buttons [M1][M4]. Voice match the selected style can be instantly recalled with just a single button press. 3. Press the [O.T.S.
Memory/Percussion Press the [MEMORY/PERC.] button to switch the buttons [M1] - [M5] function between memory function to percussion function. The default function is memory when power is turned on. Memory There are 5 memories (M1-M5). 1. While holding the [STORE] button, press one of the MEMORY buttons: [M1] - [M5] to register the panel settings. The new settings will replace the previous memory data. The settings include the number of voice, the number of style, tempo, beat value, sustain effect, etc. 2.
Chord Dictionary If you know the name of a chord but don't know how to play it, you can use the Chord Dictionary function. 1. Press the [CHORD DICT.] button to enter this mode, the LCD displays “ ”, the Chord Type and Chord Notes. 2. In this mode, the key above #G3 are used to assign the Chord Type, the keys above C5 are used to assign the Chord Root. When the Chord Type and Chord Root are confirmed, the LCD will display the Chord and its keyboard position. 3.
Playing the Songs The instrument features 80 songs (Refer to Song List). Each song can be practiced in LESSON mode. Listening to the Songs 1. Press the [SONG] button to enter the song mode. It will play all songs circularly. The display indicates "SONG" and the number of the current song. Press the [SONG] button again, it will stop the song and exit the song mode. 2. In song mode, use the number keys, [+] or [-] button to select a song. From 01-80 3.
Recording and Playback You can record your performance (up to 200 notes), and the accompaniment. 1. Press the [REC] button, the "REC " appears, the beat flashes. 2. Play the notes you want to record or press the [START/STOP] button to start recording. If you want to record your performance accompanied with the style, please turn on the A.B.C, and play the chords on the left of the keyboard. 3. Press the [REC] button again to stop recording. The "REC" disappears. 4.
MIDI Functions By using the MIDI functions you can expand your musical possibilities. This section explains what MIDI is, and what it can do, as well as how you can use MIDI on your instrument. What's MIDI? MIDI (short for Musical Instrument Digital Interface) allows a wide variety of electronic musical instruments, computers and other related devices to connect and communicate with one another.
Troubleshooting Problem The speakers produce a “pop” sound whenever the power is turned ON or OFF. Possible Cause and Solution This is normal and is no cause for alarm. No sound results when the keyboard is played. Make sure the master volume is set at appropriate levels. When using a mobile phone, noise is produced. Using a mobile phone in close proximity to the instrument may produce interference. To prevent this, turn off the mobile phone or use it further away from the instrument.
Voice List No. Name abbr. PIANO 1 2 3 4 5 6 7 8 Acoustic Grand Piano Bright Acoustic Piano Electric Grand Piano Honky-Tonk Piano Rhodes Piano Chorus Piano Harpsichord Clavichord Grand Pno Bright Pno E.
Style List No. Name abbr.
Song List No.
Chord List No.
MIDI Implementation Chart 100 95 75 25 5 0 23 aw_MC37Aerp_Manual_G13_150330 2015 4 1 11:16:15
