Use Instructions

8
/
11
NOTIFICATIONS
NOTIFICATION DESCRIPTION ACTION
The device was turned off
for over 12 hours. Would
you like to continue
monitoring?
The PocketECG transmitter
was turned off for over
12 hours.
Make sure, that you have to
stop or continue session, call
a service provider.
ECG Module Error
The ECG module
malfunction.
Turn off and then turn on the
device. If the module still does
not operate correctly, call
a service provider.
Replace Battery
Battery state of charge is
less than or equal to 10 %.
The data are not transmitted
to the remote server.
Replace the battery with the
fully charged.
Insert Battery
The PocketECG transmitter
cannot find the battery.
Insert the battery to the
PocketECG transmitter
Connect Electrodes
Electrodes contact loss. The
ECG signal data are not
transmitted to the remote
server.
Put on the electrodes to your
body.
No Memory Card
The microSD card is not
installed in its compartment
and the session cannot be
initialized.
Install microSD card or replace
damaged one.
No Network
The PocketECG transmitter
cannot connect to the
mobile phone network -
data cannot be transmitted.
Keep the PocketECG
transmitter in the area where
the mobile network is
accessible.
Critically low battery level.
The device will shut down.
Battery state of charge is
2 %, the device will shut
down.
Replace the battery with the
fully charged.
Replace battery before
update
Battery state of charge is
less than or equal to 29 %,
the update will not be
initiated.
Replace the battery with the
fully charged.
Software update in progress
Transmitter software is
being updated.
Do not remove the battery
when the message is visible.
Data synchronization is
required. Make sure that
this device has 3G network
coverage.
Data need to be transmitted
to the remote server.
Ensure that 3G network
coverage is available.
5
/
11
• When the main battery is being removed during
an ongoing session, the transmitter operates
continuously powered from the backup battery
up to 1 minute.
• When the battery gets damaged or is worn out,
follow standard disposal procedure for
Lithium-ion batteries.
CAUTION: If the main battery charge
level is low, replace it with fully charged
one, immediately. If the main battery
remains removed from its compartment
for a period longer than 1 minute, the
transmitter will switch off and the
transmission will be suspended.
7. Charging the main battery
• Plug the charger into the AC mains.
• Check whether all light indicators blink
simultaneously with orange light (the sound is
generated if the battery is not inserted into the
charger within 15 seconds from the charger
powers on).
• Put the battery into the charger and verify
whether the light indicator flashes orange
indicating that the charging is in progress
(the sound is no longer generated).
• Wait until all light indicators of the charger
change color from orange to green indicating that
the battery is fully charged.
• The battery requires ca. 4 hours to be fully
charged.
• If the device is not going to be used for a longer
time period, remove the battery. The battery
reliability may be degraded when left in the
turned off device for a long period of time.
• If the charger generates the sound when the
battery has been already inserted into its cradle,
the battery may be damaged or deeply
discharged.
• To verify whether the deeply discharged battery
may be safely used, keep it in the charger for
5 minutes.
• If the charging process starts within 5 minutes,
the battery tends to operate properly. Otherwise,
remove the battery from the charger because it
is damaged and should be no longer used.
WARNING: Do not use other chargers
than those intended for use with the
battery dedicated for the PocketECG
transmitter to prevent the danger of
battery explosion.
CAUTION: The charging process does not
start if the battery is damaged or has
been deeply discharged (e.g. kept in the
turned off PocketECG transmitter for
a long period of time).
CAUTION: The battery charger can be
supplied only by the AC voltage specified
on the charger label.
CAUTION: The backup battery is
activated only when a recording session
is ongoing.
8. Charging the backup battery
• The backup battery is installed inside the
PocketECG transmitter and cannot be removed.
• The charging of the backup battery is started
automatically.
• The charging of the backup battery is initiated
when the charge level falls below the predefined
minimum level and the main battery powering
the device is fully charged.
