Use Instructions

6
/
11
TECHNICAL
PARAMETERS
Model PocketECG IV
Type P4TR-AA-ADS (LTE version for Verizon)
Powered by A Lithium-ion battery 3.7 V type: PECGB-III (1700 mAh)
Wireless
communication
Verizon version: AT&T version:
B4(AWS1700)
B13(700)
B2
B4(AWS1700)
B12(700)
Power consumption
<2.5 A (in transmission mode)
Working time at least 24 hours
Input impedance >10 MΩ
CMRR >60 dB
Sampling rate 300 Sa/s
Registered signal
band
0.05 Hz to 60 Hz
Input dynamic
range
±5 mV
Acceptable
constant
component
±300 mV
Dimensions 167x79x14.5 mm (without cable)
Weight 161 g
Temperature
operating conditions 0 ⁰C to 43 ⁰C (32 ⁰F to 109 ⁰F)
transport and storage
conditions
-20 ⁰C to 60 ⁰C (-4 ⁰F to 140 ⁰F)
Relative humidity
operating conditions 15 % to 93 %, non-condensing
transport and storage
conditions
up to 93 %, non-condensing
Atmospheric
pressure
operating conditions
700 hPa to 1060 hPa
transport and storage
conditions
7
/
11
WARNINGS
Warning statements alert to situations which, if not
avoided, could result in illness or injury of the
patient. Specific warnings can also be found in
other sections of this instructions for use. All of
them should be obeyed.
• DO remove electrodes, patient lead wires, and
the PocketECG transmitter from the patient
before defibrillation.
• DO maintain a minimum distance of 6 inches
between the transmitter and pacemaker for
patients with a pacemaker. Turn the transmitter
off immediately and provide appropriate patient
care if you suspect the transmitter affected the
peacemaker.
• DO keep the PocketECG transmitter
in the protective pouch with protection class at
least IP02 in all outdoor applications.
• DO keep the device and its accessories in dry
conditions when showering, bathing or washing.
Product is not watertight.
• DO keep the device and its accessories away from
infants and children to avoid danger of
swallowing.
• DO NOT use the device in infants weighing less
than 10 kg.
• DO NOT use the device in intensive care units. It
should not be used with high-frequency surgical
devices or directly on the heart.
• DO NOT use accessories other than those
recommended by the manufacturer. It may be
dangerous to the user and may affect the
electromagnetic compatibility of the PocketECG
transmitter.
• DO NOT plug the device to a different source of
power than intended by the manufacturer. Using
a different power source is hazardous and may
impair the functioning of the equipment or result
in serious injury to the user.
• DO NOT use the device in the presence of
a flammable anesthetic mixture with air or
oxygen or nitrous oxide.
• DO NOT position PocketECG battery charger so
that it is difficult to operate the detachable
power supply cord.
• DO NOT service the device while in use with
a patient, excluding main battery replacement.
• DO NOT attempt to open or service neither the
battery pack nor the transmitter.
• DO NOT disassemble, crush, puncture the
battery, and do not short external contacts or
circuits, dispose of in fire or water or expose to
temperatures higher than 60 ºC (140 ºF). Replace
a Lithium-ion battery only with batteries
specified by the device manufacturer. Recycle or
dispose of used batteries according to the local
regulations or reference guide supplied with your
product.
• DO NOT use the device at gas stations, fuel
depots, chemical plants or where blasting
operations are in progress, or in potentially
explosive atmospheres such as fueling areas, fuel
storehouses, below deck on boats, fuel
or chemical transfer or storage facilities, and
areas where the air contains chemicals or
particles, such as grain, dust, or metal powders.
The user should observe restrictions on the use
of radio equipment in such places. Please be
aware that sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
• DO NOT use the device in a manner such that it is
in direct contact with the body. The device needs
to be worn in such a way that display is facing
away from patient body. PocketECG IV has been
tested and meets FCC RF exposure guidelines
when used with an accessory that contains no
metal and that positions the device in a minimum
of 1.0 cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure
guidelines.
