Specifications

IAQ INSTRUMENTS
Toll Free: 1.800.293.3003 emssales.net
31
Environmental Monitoring Systems
Applications
Confined Space Entry
- waste water treatment plants
- marine and off shore oil wells
- landfill operations
- trenches, silos, railcars
- coal mines
- cruise ships
- sewers and manholes
- tunnels
- Refineries, petrochemicals
plants, offshore drilling
and plant shut downs
- Power plants
- Pulp and paper industry
- Steel mills
QRae
4 Gas Monitor
With Conned
Space Entry Kit
QRAE is a rugged, easy to use, economical, hand-held 4 gas
monitor. It has a built-in robust internal pump with optional
20,000 point datalogging capacity.
Features
Reliable plug-in smart sensors
- Combustible
- Oxygen
- Hydrogen Sulfide
- Carbon Monoxide
Key Features include:
• Patented SPE O
2
TM
Oxygen sensor
• Best EMI/RFI immunity technology for products in its
class, eliminating radio interference
• Easy access to sensors, filter and battery compartment
without exposing electronic components to potential damage
• Big graphic display for easy overview of gas type and
concentration
• Alkaline adapter and Lithium-ion battery pack
• Rugged housing withstands harsh environments
QRae II
PART # PRODUCT DESCRIPTION LIST
PRICE
ems
PRICE
GAS MONITORS
120257
QRAE 4 Gas Monitor for Confined Space Entry Kit
(kit includes: monitor, case, sampling wand, tool kit, four-gas mix in a 34L
cylinder, calibration regulator and tubing)
$875.00 $875.00
120258
QRAE II, LEL/O2/H2S/CO with alkaline batteries (lithium ion rechargeable
batteries also available)
$545.00 $545.00
120259
QRAE PLUS, LEL/O2/H2S/CO, Li-ion battery with charger,software
$1,105.00 $1,105.00
The QRAE II is a full-featured, compact, one- to four-
sensor gas detector for detection of combusibles,
oxygen, hydrogen sulfide, and carbon monoxide.
Key features include easy-to-change, externally
accessed battery packs (available in rechargeable
and alkaline versions), a water-resistant case and
a new state-of-the-art O
2
sensor technology with
extended life.
120257
Gas Monitors/Gas Detection Tubes & Kits
QRae Plus
Compact Multi-gas Detector
for H
2
S, CO, O
2
Combustibles
Key Features include:
• One-to-four plug-in “smart” sensors: Combustible, Oxygen, Hydrogen Sulfide, Carbon Monoxide
• Optional substance-specific toxic sensors: Sulfur Dioxide (SO2), Nitric Oxide (NO), Nitrogen Dioxide
(NO2), Chlorine (Cl2), Hydrogen Cyanide (HCN), Ammonia (NH3), Phosphine (PH3)
• Rechargeable Lithium-ion battery pack provides up to 20 hours (more than 2 work shifts) of
continuous operation
• Rugged housing withstands use in harsh environments with a water and dust resistant case and
strong protective rubber boot
• Highly resistant to radio frequency and other electromagnetic interference
• Strong, built-in sample draw pump with optional collapsible sample-probe
• Also available in diffusion configuration
• One-button calibration with auto-zero capability
• Loud audible alarm
• Bright Visual Alarm
• Interchangeable Lithium-ion and alkaline battery packs
The QRAE Plus is a full-featured, compact,
one-to-four sensor confined space gas
detector. It’s features include easy-to-change,
externally accessed battery packs (available in
both alkaline and rechargeable versions) and
water-resistant case design. The rechargeable,
Lithium-ion battery pack provides up to 20
hours of continuous operation. The QRAE Plus
includes 16,000 datalogging points of storage
capacity for download to PC compatible with
Windows 98, NT, 2000 and XP.
Compact Multi-
gas Detector
for H
2
S, CO, O
2
Combustibles
120258
120259
