Specifications

IAQ INSTRUMENTS
Toll Free: 1.800.293.3003 emssales.net
33
Environmental Monitoring Systems
CMS: Chip Measurement System
The CMS combines substance specific measuring Chips with an electronic based Analyzer for an easy-to-use spot-measurement
system. The 10 capillaries in each Chip are filled with a reagent system based on Draeger’s 60+ years of calorimetric chemistry
expertise. The analyzer combines a revolutionary optical system for analyzing the color reaction with a mass flow controller and pump
system that provides unbeatable reproducibility.
Simplified Operation: The CMS is literally as easy to operate as 1-2-3. Making an analysis is as simple as turning the unit “on”
(moving the slide to position 1), then following the plain language instructions on the display to load the Chip and move the slide
selector to positions 2 and 3. Operating the CMS couldn’t be easier because this is the exact same procedure for every Chip! Upon
completion of the analysis, the CMS Analyzer shows the concentration on the display. Any misinterpretation of the results is eliminated
by the unambiguous digital display of the concentration.
IAQ Kit Includes: Analyzer Set, 4 Chips and Nylon Transport Case (includes the following chips: Carbon Dioxide
200-3000 ppm, Carbon Monoxide 5.0-150 ppm, Formaldehyde 0.20-5.0 ppm and Ozone 25.0-1000 ppb)
120215
You Design The Miniwarn....
choose From 20 Different Sensors! Tests for 1-4 gases at a time
*call for available sensors
Easy Operation: The MiniWarn is one tough little instrument, but it’s very easy to operate. The three buttons on the front of the monitor turn
it ON, OFF, acknowledges alarms and access routinely needed data like battery levels. Functions such as calibration and alarm set points
are adjusted through plain language menu commands. These functions are protected by a pass code to prevent accidental or unauthorized
adjustment. In the adjustment modes, the three-buttons act as up, down, and enter buttons to navigate you through the menu. Operation of
the MiniWarn is very intuitive.
120217
MiniWarn Fits your Application
Draeger CMS Measurement Made Easy
Choose from 55 different chips.
Call for available chips.
PART # PRODUCT DESCRIPTION LIST
PRICE
ems
PRICE
GAS MONITORS
120215 Draeger CMS IAQ Kit $2209.00 $2089.00
120217 Draeger MiniWarn Kit $2789.00 $2635.00
BELLOWS PUMP
600170 Draeger ACCURO Bellows Pump with
Tube Breaker
Tubes not included. Call for a complete list.
$379.00 $379.00
DraegerACCURO
Bellows Pump & Tubes
More than 500 substances can be detected and measured using the Dräger-Tube system. Typical applications include the monitoring of workplace air, emission measurements,
quality control, process control and monitoring of compressed air for breathing apparatus, as well as environmental and hazardous substance detection technology.
MORE THAN 500 SUBSTANCES CAN BE DETECTED!
Call for a complete list of available tubes
The accuro gas detector pump is a manually operated bellows pump that draws
a calibrated 100 milliliter sample through the short-term Dräger-Tubes.
Features:
• One-Hand Operation
• Very Low Maintenance
• End-of-Stroke Indicator
• Built-in automatic Stroke Counter
600170
Tubes Not Included.
Gas Monitors/Gas Detection Tubes & Kits
Ultimate Flexibility: You design the MiniWarn, specifically for your application. Choose
from over 20 different intelligent sensors for the four measurement channels, and change
sensors quickly as your needs change. The three battery pack options: NiCd, NiMH, and
Alkaline, are interchangeable allowing for quick change-outs when 24-hour operation is
needed.
