Specifications

IAQ INSTRUMENTS
Toll Free: 1.800.293.3003 emssales.net
providing environmental products for a safer tomorrow
42
EXTECH
InfraRed Laser Thermometer
Features:
Measures to 600
o
F without contact
Large LCD display with backlighting
Built-in laser pointer to improve aim
oF/oC switchable
Fixed emissivity (0.95) covers 90%
of surface applications
Narrow eld of view
Applications:
Measures surface temperature
of objects that are difcult to
reach or unsafe to contact.
Measures hot spots in electrical
panels and equipment
In-process temperature
measurements.
120330
PART # PRODUCT DESCRIPTION LIST
PRICE
ems
PRICE
PSYCHROMETER / INFRARED LASER THERMOMETERS
120335 Digital Psychrometer RH300 $89.00 $89.00
120330 Mini InfraRed Thermometer w/ Laser Pointer $99.00 $69.00
120270 Fluke Mini InfraRed Laser Thermometer $99.00 $99.00
120332 Extech Temp/Humidity Datalogger $155.00 $149.00
EXTECH
Digital Psychrometer RH300
Simultaneosly display of %RH, Temperature and Dew Point or Wet
Bulb or Probe Temperature
Wet bulb measurements without slinging
Calculates T1-T2 differential using optional probe and T2 dew point
Unique sensor cap design twists to closed position for protection dur-
ing storage
Switchable
o
F/
o
C temperature units with 0.1 resolution
Data Hold freezes current reading on display
Max / Min readings
Auto power off to save batteries
Optional external temperature probe (TP890)
Optional kit RH305 includes RH300, temperature probe,
33% and 75% calibration bottles, and carrying case
Specifications: Range Max
Resolution
Basic
Acuracy
Humidity 10 to 90%RH 0.1%RH
+
-
3%RH
Temperature (internal) -4 to 122
o
F (-20 to 50
o
C) 0.1
o
+
-
1
o
F or
+
-
0.6
o
C
Temperature (external) -4 to 158
o
F (-20 to 70
o
C) 0.1
o
+
-
1
o
F or
+
-
0.6
o
C
Dew Point -90.4 to 122
o
F (-68.0 to
49.9
o
C)
Wet Bulb -6.9 to 122
o
F (-21.6 to 49.9
o
C)
Dimensions 7x1.9x1” (178.5x48.4x24.7mm)
Weight 3.3oz (95g)
62
Fluke
Mini InfraRed
Laser Thermometer
Now Introducing the Fluke 62 Mini!
The Fluke 62 Mini non-contact thermometer is the perfect introduction to
infrared (IR) thermometers for the professional. With the best accuracy in
its class, the Fluke 62 Mini offers quick and reliable surface temperature
readings. This compact and portable tool enables professionals to diagnose
heating and ventilation problems and monitor the temperature of electrical
motors and electrical panels without contact. Rugged enough for industrial
environments with its protective rubber “boot”, the 62 Mini also comes with
a handy nylon holster, keeping quick temperature checks at your fingertips.
Specifications
Backlit display for use in poorly lit areas
Holds temperature readings
Range: 30 to 500 ºC (-20º to 932 ºF)
Distance to spot ratio: 10:1 at 80% energy
Emissivity: Fixed at 0.95
Measurement Accuracy: 10 ºC to 30 ºC (50 ºF to 86 ºF): ± 1 ºC (2 ºF)
Outside 10 ºC to 30 ºC (50 ºF to 86 ºF): ± 1.5 ºC (3 ºF) or ± 1.5 % of
reading, whichever is greater
120335
120270
Psychrometer and
Infrared Laser Thermometers
Audible and visible overrange indicators
Automatic Data Hold
Pocket size meter
Complete with 9V battery
Dimensions: 6.7x1.7x1.6” (170x44x40mm)
Weight: 6.4 oz
Field of View: 6:1
Measurement Accuracy:
+
-
2% of reading
EXTECH
Temperature / Humidity Datalogger
• Multiple Dataloggers can be programmed and data downloaded from one single docking station.
• Records Relative Humidity and Temperature in storage containers, shipping vans, freezers and more
• Program the logger, analyze and store data using Windows 95/98/NT/ME/XP compatible software
• Logs data for days, weeks or months - up to 1 year battery life
• Programmable sampling rate from 1 second to 2 hours
• View both humidity and temperature on LCD display
Compact, powerful and easy to use
Records up to 16,000 readings
120332
