Specifications

REMEDIATION & SAFETY PRODUCTS
Toll Free: 1.800.293.3003 emssales.net
51
Environmental Monitoring Systems
The Omniguard 4 is a differential pressure recorder in a completely self-contained package, designed from the beginning to be extremely flexible yet easy
to use. The included accessories, owner’s manual, hose, a spare roll of paper and AC cord, store easily in the lid. There’s no AC adapter to keep track of.
It’s easy to find a convenient spot to place the unit since the Omniguard 4 is not position sensitive and can be hung by a nail. Accurate measurements
continue even if the unit is dropped or moved.
The backlit graphics display provides the easiest setup possible. Pressure is indicated with large easy to read characters and alarm setpoints are always
displayed. Screen icons show the monitoring, printer and audible alarm status with a glance. Detailed information for job setup, feature settings and operating
instructions are available on-screen at any time by pressing the Help key. Troubleshooting topics are also covered.
Pressure readings are time stamped and logged into memory once containment has been established. Audible and visual alarms activate whenever the
pressure reaches the alarm setpoints.
The Omniguard 4 ensures the site inspector that proper containment was maintained. Logs and summary reports can be printed at any time for easy
inspection of the monitoring data. Durable and reliable, the Omniguard 4 is clearly the contractors choice for containment monitoring.
Features
• New case design; operate your Omniguard 4 with the lid closed! A window built into the lid lets you view the
display while the case is closed, ensuring a watertight unit and less dirt. Less dirt, means fewer printer
problems
• New logs let you name and save multiple jobs. Print the current job or any previous job at anytime
• 40+ days of logging capacity!
• New paper feed path allows printing from any position
• Built-in USB and Serial ports. Supports off-site remote monitoring using the optional external modem
• Same great color, bold yellow!
• 20% larger LCD with white LED backlit enhances visibility, near or far
• New side clip lets you hang Omniguard
• Rotating screen
• Multiple screens; enlarged pressure reading or the standard monitoring screen
Cat.# 800201
Features & Applications:
Applications include; pressure drops across fans or filters, flow pressure measurements and positive/
negative pressure measurements in compressed air control systems. Design elements include a very
compact size, one-button operation, automatic power off, magnetic back for hands-free operation and
flexible hose included.
Features:
• One button easy operation
• Not position sensitive
• Compact size fits in pocket or tool box
• Auto-off function
• Displays H2O, PSI, or hPa
• Battery and hoses included
Applications:
• Adjusts fans and blowers
• Setting pressure switches
• Filter monitoring
• Precise draft monitoring
Spec Summary:
Measuring Range: ±4” & ±80” H2O
Overload: 120” H2O
Resolution: 0.001/0.01 in H2O
Accuracy: ±0.01” H2O (<0.4”)
±1.5% of fs (0.4 to 4” H2O)
0.4” + 1% of mv (>4” H2O)
Operating Temperature: 32 to 104°F
Storage Temperature: -4 to 158°F
Battery: 2 x CR2032
Battery Life: Approx. 150 hours
PART # PRODUCT DESCRIPTION LIST
PRICE
ems
PRICE
MANOMETERS AND VANEOMETER
800201 Omniguard 4 Professional Pressure Recorder $1,350.00 $1,199.00
800205 Omniguard 4 Thermal Paper 5/rls
(can be used w/ Omniguard III or 4)
$26.50 $26.50
800211 Testo 506-3 $179.00 $179.00
700101 Vaneometer $29.00 $26.95
700102 Manometer Model 25 Mark II $35.00 $33.50
TESTO 506-3
Mini Digital Manometer
Displays hPa/mbar, mmH2O, mmHg, inH2O, or PSI
800211
700102 700101
Manometers & Vaneometer
4
Omniguard
