Spec Sheet

10/09/2018
TRINIDAD-III NL CEILING FAN
Spec Sheet
Main Features
 2 year in home warranty
 5 year motor warranty
 1300mm (52”) 3 x ABS blades
 Efficient 30W DC motor
 Quick and easy fan installation
 Summer / Winter reversing settings
 6-Speed remote controller
 Fan OFF/ON
 Easy summer / winter mode setting
 Easy setup pairing between remote & receiver
Product Technical Specifications
Colour/Finish option
Black, White
Blade
ABS (White / Black / Timber-look)
Blade pitch
15˚
Rated input voltage
220-240V~
Rated input frequency
50Hz
Motor power rating
DC 30W
max
Ceiling to Fan Bottom
230mm
Ceiling to Blade
220mm
Gross weight
4.8kg
Net weight
3.7kg
Packaging
Colour box
Packaging size (mm)
705 x 221 x 247mm
Bar Codes
Performance**
**Actual performance may vary.
Optional Accessories (Sold separately)
*This product must be installed by a licensed electrician.
SKU Model
Bar Code
FC590133BB
9312699156137
FC590133WW
9312699156168
FC590133WH
9312699156151
FC590133BK
9312699156144
SPEED
1
2
3
4
5
6 (max)
Airflow (m
3
/hr)
2835
5013
6435
6918
7503
8333
MODEL
600 (mm) EXTENSION RODS
900 (mm) EXTENSION RODS
FC590133BB
FD598600BK
FD598900BK
FC590133WW
FD598600WH
FD598900WH
FC590133WH
FD598600WH
FD598900WH
FC590133BK
FD598600BK
FD598900BK
Visit us @ www.mercator.com.au
