Parts List

RW 18 LTX 120
Позиция Количество Номер для заказа Описание PG
1 1 343445960 Holder (f. battery) 24
2 2 343445970 Guide 14
3 1 342021670 Spring clip 11
4 1 343438580 Locking slide 12
5 2 341702050 Screw 11
6 1 343430520 Locking piece 11
7 1 316096720 Handle left cpl. 29
8 1 341117690 grip strap coated 33
9 14 341722900 Self-tap. fill. h. screw 13
10 1 338124500 Indication label,Ultra M 11
11 1 343445980 Motor housing 26
12 1 338129000 Type label,RW 18 LTX 120 11
14 1 316053210 Brush holder compl.,18 V 23
16 1 317004970 Motor compl. 26
17 1 338068590 Leistungsschild 01163000 RW 18 LTX 120 11
18 1 343086100 electronic unit, 18V Stirrer 49
19 1 316096740 Handle right cpl. 29
20 1 343411670 Switch compl. 32
21 1 344098740 Rubber bushing 11
22 1 320050650 Ball bearing 22
23 1 316096750 Bearing Cover cpl. 39
24 1 344113760 Seal 18
25 1 341605440 Intermediate shaft 36
26 1 316096760 Gear-box cpl. 53
27 4 341722910 Self-tap. fill. h. screw 13
28 1 341212400 THREADED CONNECTION 5/8''x16 UN 31
29 1 311011880 Field coil compl.,2 pol. 34
30 1 310012290 Armature compl.,18V 36
95 2 343439680 Cover cap 11
1001 1 338506290 Wiring diagram
