Specification

Project Catalog # Type
Prepared by Notes Date
PS502109EN page 1
November 14, 2019 9:05 AM
Top Product Features
• Replaces up to 250W HID or 4-lamp T8 equivalent (128W)
• Standard diffused lens for added protection and glare control
• Ideal for high ceilings up to and over 15ft
• 13 inch wide linear high-bay
• L70 at 60,000 hrs or 19 years
Interactive Menu
• Order Information page 2
• Product Warranty
Dimensional and Mounting Details
LCHB LED
Lensed Commercial LED High-Bay
Typical Applications
Light Commercial • Warehouse • Manufacturing • Gym • Large Open Areas •
Retail
DIMMABLE
23-3/4"
[603mm]
12-5/8"
[321mm]
3-5/8"
[92mm]
LHB-12, 18, 24 LHB-36
3-5/8"
[92mm]
12-5/8"
[321mm]
45-7/8"
[1165mm]
Scale
20’ [6.0m] @ 95˚F (35˚C)
Product Certication
Product Features
