Specification Sheet

AXDSP-L SPEC SHEET
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 9/2/20 INSTAXDSP-L
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
Product Info
Specifications
Input Impedance 1M Ohm
Input Channels 4
Input Options High-level or Low-level selectable
Input Type Differential-Balanced
Input Voltage
High Level Range
0 - 28-volts (peak-to-peak)
Input Voltage
Low Level Range
0 - 4.9-volts (peak-to-peak)
Ouput Channels 6
Output Voltage Up to 5-volts RMS
Output Impedance 50 Ohms
Equalizer Type 15 Band Graphic EQ, +/- 10dB
THD <0.03%
Frequency Response 20Hz - 20kHz
Crossover 2-Way low-pass (sub), high pass
(front & rear)
Crossover Type Linkwitz-Riley 24db slope, fixed
Sampling 48kHz
S/N Ratio 105dB @ 5-volts RMS
General
Operating Voltage 10-16-volts DC
Standby Current Draw 7mA
Operation Current Draw 150mA
Adjustments/Controls Application via Bluetooth
Remote Output 12-volts DC (signal sense or w/ ignition)
