Chapter 6: The “Weighing” application
38
6 The “Weighing” Application
In this chapter we will introduce you to the “Weighing” application. You will find information for practical work with this application,
and about the application-specific settings that are available (you will find information about non-application-specific system settings
in Chapter 5).
6.1 Selecting the application
6
If the “Weighing” application is not already active, touch the «6» key. In the selection
window, touch the symbol for the “Weighing” application. The balance loads the
application and is then ready to be used for weighing.
6.2 Settings for the “Weighing” application
You already learned how to carry out a simple weighing in Chapter 3. As well as the work steps described there (operating the glass
draft shield, taring, a simple weighing, and manually printing the weighing result), your balance provides a large number of
possibilities for adapting the “Weighing” application to your specific needs.
Note: If your settings should not apply to the “Home” profile, first use the «4» key to select the desired user profile.
6.2.1 Overview
7
The application-dependent settings can be accessed with the «7» key. When this key
is pressed, the first of 3 menu pages with application-dependent settings is displayed.
Note: You can change some of the most frequently used settings directly by touching
the corresponding zone in the display (Section 4.2).
The following settings are available for the “Weighing” application:
“Function keys”: Here you can specify which function keys should appear at the
bottom edge of the display. These keys allow direct access to
certain functions (Section 6.2.2).
“SmartTrac”: Selects the display mode for the graphical weighing-in aid or to
show a stopwatch (Section 6.2.3).
“Info field”: Here you can specify which information fields should be display-
ed (Section 6.2.4).
“WeighEntry”: Provides a choice between entering the weight manually or
automatically (Section 6.2.5).
